aston martin cygnet (2012) tailgate panels & fixings parts diagram

01.0302.01 - Tailgate Panels & Fixings

Aston Martin Cygnet (2012) Tailgate Panels & Fixings Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # 1
                                      MPN: AY2Y-40616-AE
                                      PANEL, POP OUTER, TAILGATE
                                      from £1,033.95
                                      from £1,033.95
                                      TAILGATE OUTER Genuine Aston Martin - New (to order)
                                      # 2
                                      MPN: AY2Y-40656-AB
                                      BRACKET, POP PANEL, RH
                                      from £8.41
                                      from £8.41
                                      TGATE ATTACH BRACKET RH Genuine Aston Martin - New (to order)
                                      # 3
                                      MPN: AY2Y-40657-AB
                                      BRACKET, POP PANEL, LH
                                      from £8.41
                                      from £8.41
                                      TGATE ATTACH BRACKET LH Genuine Aston Martin - New (to order)
                                      # 4
                                      MPN: 703143
                                      BOLT, M6X12
                                      from £1.07
                                      from £1.07
                                      SCRW & WSHR-M6 X 12 Genuine Aston Martin - New (to order)
                                      # 5
                                      MPN: 702943
                                      RIVET, 3.2X12.5, BLIND AL DOME HEAD
                                      from £0.47
                                      from £0.47
                                      RIVET-3.2X6.5 BLACK Genuine Aston Martin - New (to order)
                                      # 6
                                      MPN: AY2Y-43524-AB
                                      HANDLE, TAILGATE POP PANEL
                                      from £26.00
                                      from £26.00
                                      TAILGATE HANDLE Genuine Aston Martin - New (to order)
                                      # 7
                                      MPN: AY2Y-40636-AA
                                      GASKET, TAILGATE HANDLE
                                      from £4.07
                                      from £4.07
                                      GASKET TG-HANDLE Genuine Aston Martin - New (to order)
                                      # 8
                                      MPN: AY2Y-40637-AA
                                      GASKET, TAILGATE PANEL
                                      from £4.07
                                      from £4.07
                                      GASKET TG PANEL Genuine Aston Martin - New (to order)
                                      # 9
                                      MPN: AY2Y-43525-AB
                                      MOUNTING PLATE, HANDLE SWITCH
                                      from £5.21
                                      from £5.21
                                      SWITCH MOUNTING PLATE Genuine Aston Martin - New (to order)
                                      # 10
                                      MPN: 702211
                                      BOLT, M5X8
                                      from £0.47
                                      from £0.47
                                      SCREW M5X8.0X0.80 PN Genuine Aston Martin - New (to order)
                                      # 11
                                      MPN: 7G43-10609E-AA-PK
                                      NUT, U TYPE
                                      Pack of 10
                                      from £5.08
                                      from £5.08
                                      CLIP SPG M6 PK OF 10 Genuine Aston Martin - New In stock
                                      FRONT UNDERTRAY CLIP Genuine Ferrari Part - New (to order)
                                      # 12
                                      MPN: AY2Y-442K03-AE
                                      SPOILER, REAR
                                      from £333.02
                                      from £333.02
                                      T/GATE SPOILER Genuine Aston Martin - New (to order)
                                      # 13
                                      MPN: AY2Y-33615-AA
                                      CLIP, SPOILER ATTACHMENT
                                      from £0.51
                                      from £0.51
                                      SPOILER CLIP Genuine Aston Martin - New (to order)
                                      # 14
                                      MPN: AY2A-13554-AB
                                      Finisher Assy, Tailgate, SATIN
                                      FINISHER ASSEMBLY TAILGATE, SATIN Genuine Aston Martin - New (to order)
                                      # 14
                                      MPN: AY2Y-13554-BB
                                      FINISHER ASSY, TAILGATE, BRIGHT
                                      from £116.40
                                      from £116.40
                                      T/GATE FIN BRIGHT Genuine Aston Martin - New (to order)
                                      # 15
                                      MPN: 703149
                                      SCREW
                                      from £0.47
                                      from £0.47
                                      SCREW M6X16 PAN Genuine Aston Martin - New (to order)
                                      # 16
                                      MPN: 6G33-5467838-AA
                                      RIVNUT
                                      from £0.47
                                      from £0.47
                                      RIVNUT M6 Genuine Aston Martin - New (to order)
                                      # 17
                                      MPN: 905409144
                                      Bump Stop, Upper Tailgate
                                      Bump Stop, Upper Tailgate Genuine Aston Martin - New (to order)
                                      # 18
                                      MPN: 90541009142
                                      Bump Stop, Lower Tailgate
                                      Bump Stop, Lower Tailgate Genuine Aston Martin - New (to order)
                                      # 19
                                      MPN: 4G43-16C694-AB
                                      NYLON SPACER
                                      WASHER, NYLON Genuine Aston Martin - New (to order)
