aston martin one-77 (2011) wheels & tyres parts diagram

04.0000 - Wheels & Tyres

Aston Martin One-77 (2011) Wheels & Tyres Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Key
      Price
      # 1
      MPN: 12023-03-0200-AA
      WHEEL, FRONT 7 SPOKE POLISHED
      20 x 9J ET 43.8
      from £2,844.05
      from £2,844.05
      FRONT WHL-7 SPOKE-POL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0200-BA
      WHEEL, FRONT 7 SPOKE DBS SILVER
      20 x 9J ET 43.8
      WHEEL, FRONT 7 SPOKE DBS SILVER Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0200-CA
      WHEEL, FRONT 7 SPOKE DBS SILVER DIAMOND TURNED
      20 x 9J ET 43.8
      from £3,062.77
      from £3,062.77
      7SPKE FRONT WHEEL DBS Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0200-DA
      WHEEL, FRONT 7 SPOKE SATIN SILVER
      20 x 9J ET 43.8
      from £2,853.92
      from £2,853.92
      7SPKE FRONT WHEEL SAT Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0200-FA
      WHEEL, FRONT 7 SPOKE MATT GREY DIAMOND TURNED
      20 x 9J ET 43.8
      from £2,844.05
      from £2,844.05
      7SPKE FRONT WHEEL MATT Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0200-HA
      WHEEL, FRONT 7 SPOKE GOLD DIAMOND TURNED
      20 x 9J ET 43.8
      from £2,883.45
      from £2,883.45
      FRONT WHL-7SPKE GLD DT Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-AA
      WHEEL, FRONT 10 SPOKE POLISHED LH
      20 x 9J ET 43.8
      from £3,001.53
      from £3,001.53
      RIM-FR-10-SPOKE Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-BA
      WHEEL, FRONT 10 SPOKE POLISHED RH
      20 x 9J ET 43.8
      from £3,001.53
      from £3,001.53
      10 SPKE FRONT WHEEL POL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-EA
      WHEEL, FRONT 10 SPOKE DBS SILVER DIAMOND TURNED LH
      20 x 9J ET 43.8
      from £2,962.15
      from £2,962.15
      10 SPKE FRONT LH WHEEL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-FA
      WHEEL, FRONT 10 SPOKE DBS SILVER DIAMOND TURNED RH
      20 x 9J ET 43.8
      from £3,050.74
      from £3,050.74
      10 SPKE FRONT RH WHEEL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-LA
      WHEEL, FRONT 10 SPOKE MATT GREY DIAMOND TURNED LH
      20 x 9J ET 43.8
      from £3,066.67
      from £3,066.67
      10 SPKE FRONT LH WHEEL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-MA
      WHEEL, FRONT 10 SPOKE MATT GREY DIAMOND TURNED RH
      20 x 9J ET 43.8
      from £3,066.67
      from £3,066.67
      10 SPKE FRONT RH WHEEL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-RA
      WHEEL, FRONT 10 SPOKE GOLD DIAMOND TURNED LH
      20 x 9J ET 43.8
      from £3,001.53
      from £3,001.53
      10 SPKE FRONT LH WHEEL Genuine Aston Martin - New (to order)
      # 1
      MPN: 12023-03-0202-SA
      WHEEL, FRONT 10 SPOKE GOLD DIAMOND TURNED RH
      20 x 9J ET 43.8
      from £2,962.15
      from £2,962.15
      10 SPOKE FRONT RH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-AA
      WHEEL, REAR 7 SPOKE POLISHED
      20 x 12.5J ET 66
      from £2,942.49
      from £2,942.49
      REAR WHL-7SPKE POLSHD Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-BA
      WHEEL, REAR 7 SPOKE DBS SILVER
      20 x 12.5J ET 66
      WHEEL, REAR 7 SPOKE DBS SILVER Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-CA
      WHEEL, REAR 7 SPOKE DBS SILVER DIAMOND TURNED
      20 x 12.5J ET 66
      from £3,108.00
      from £3,108.00
      7SPKE REAR WHEEL DBS SIL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-DA
      WHEEL, REAR 7 SPOKE SATIN SILVER
      20 x 12.5J ET 66
      from £2,883.45
      from £2,883.45
      7SPKE REAR WHEEL SATIN Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-FA
      WHEEL, REAR 7 SPOKE MATT GREY DIAMOND TURNED
      20 x 12.5J ET 66
      from £2,952.31
      from £2,952.31
      7SPKE REAR WHEEL MATT Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0201-HA
      WHEEL, REAR 7 SPOKE GOLD DIAMOND TURNED
      20 x 12.5J ET 66
      from £2,952.31
      from £2,952.31
      7SPKE REAR WHEEL GLD DT Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-AA
      WHEEL, REAR 10 SPOKE POLISHED LH
      20 x 12.5J ET 66
      from £3,070.41
      from £3,070.41
      10 SPK REAR WHEEL POL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-BA
      WHEEL, REAR 10 SPOKE POLISHED RH
      20 x 12.5J ET 66
      from £3,070.41
      from £3,070.41
      10 SPKE REAR WHEEL POL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-EA
      WHEEL, REAR 10 SPOKE DBS SILVER DIAMOND TURNED LH
      20 x 12.5J ET 66
      from £3,139.32
      from £3,139.32
      10 SPKE REAR LH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-FA
      WHEEL, REAR 10 SPOKE DBS SILVER DIAMOND TURNED RH
      20 x 12.5J ET 66
      from £3,139.32
      from £3,139.32
      10 SPKE REAR RH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-LA
      WHEEL, REAR 10 SPOKE MATT GREY DIAMOND TURNED LH
      20 x 12.5J ET 66
      from £3,139.32
      from £3,139.32
      10 SPKE REAR LH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-MA
      WHEEL, REAR 10 SPOKE MATT GREY DIAMOND TURNED RH
      20 x 12.5J ET 66
      from £3,139.32
      from £3,139.32
      10 SPKE REAR RH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-RA
      WHEEL, REAR 10 SPOKE GOLD DIAMOND TURNED LH
      20 x 12.5J ET 66
      from £3,139.32
      from £3,139.32
      10 SPKE REAR LH WHEEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 12023-03-0203-SA
      WHEEL, REAR 10 SPOKE GOLD DIAMOND TURNED RH
      20 x 12.5J ET 66
      from £3,050.74
      from £3,050.74
      10 SPKE REAR RH WHEEL Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-AA
      BADGE, WHEEL CENTRE
      Polished
      from £88.95
      from £88.95
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-BA
      BADGE, WHEEL CENTRE
      Silver
      from £144.94
      from £144.94
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-CA
      BADGE, WHEEL CENTRE
      Satin silver
      from £148.46
      from £148.46
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-DA
      BADGE, WHEEL CENTRE
      MATT GREY
      from £88.95
      from £88.95
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-EA
      BADGE, WHEEL CENTRE
      GOLD
      from £88.95
      from £88.95
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 3
      MPN: AY93-1A096-FA
      BADGE, WHEEL CENTRE
      Sand blast
      from £88.95
      from £88.95
      BADGE-WHEEL CENTRE Genuine Aston Martin - New (to order)
      # 4
      MPN: AY93-360671-AA
      TRANSMITTER AND VALVE ASSEMBLY
      433 MHZ
      from £778.95
      from £778.95
      ONE-77 TPMS SNSR 433 Genuine Aston Martin - New (to order)
      # 4
      MPN: AY93-360671-BA
      TRANSMITTER AND VALVE ASSEMBLY
      315 MHZ
      from £778.93
      from £778.93
      ONE-77 TPMS SNSR 315 Genuine Aston Martin - New (to order)
      # 5
      MPN: 4G43-1K024-BA
      NUT, WHEEL
      NUT, WHEEL Genuine Aston Martin - New (to order)
      # 6
      MPN: No longer available
      TYRE, FRONT, 255/35ZR20 (97Y)
      Refer to Pirelli
      TYRE, FRONT, 255/35ZR20 (97Y) Genuine Aston Martin - New (to order)
      # 7
      MPN: 12023-12-1038-AA
      TYRE, REAR, 335/30ZR20 (104Y)
      While stocks last. After, refer to Pirelli
      from £1,526.74
      from £1,526.74
      REAR TYRE-335/30/20 Genuine Aston Martin - New (to order)
      # -
      -
      WEIGHT, WHEEL BALANCE
