6.1B - Instruments & Controls
Aston Martin V8 Virage (2000) Instruments & Controls Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 38-62235
SPEEDOMETER, MPH
Up to July 1995
from £415.19
from £415.19
# 1
MPN: 38-64932
Speedometer, MPH (VDO)
From July 1995 Up to Nov 1995
# 1
MPN: 691780
SEALSTRIP
Use with 38-64931/2
from £3.31
from £3.31
# 1
MPN: 38-56088
Speedometer, MPH (Caerbont)
From November 1995
# 1
MPN: 38-62236
SPEEDOMETER, KPH
Up to July 1995
from £904.14
from £904.14
# 1
MPN: 38-64931
Speedometer, KPH (VDO)
From July 1995 Up to Nov 1995
# 1
MPN: 38-56089
SPEEDOMETER, KPH (CAERBONT)
From November 1995
from £589.67
from £589.67
# 2
MPN: 38-62241
TACHOMETER
Up to November 1995
from £519.24
from £519.24
# 2
MPN: 38-56090
TACHOMETER
From November 1995
from £482.21
from £482.21
# 3
MPN: 38-62238
WATER TEMPERATURE GAUGE
Up to November 1995
from £190.73
from £190.73
# 3
MPN: 38-56082
WATER TEMPERATURE GAUGE
From November 1995
from £148.00
from £148.00
# 4
MPN: 38-62254
Fuel gauge, leaded, For long fuel tank sender
Up to (V) 60080
# 4
MPN: 38-62237
Fuel gauge, unleaded, For long fuel tank sender
Up to (V) 60080
from £222.54
from £222.54
# 4
MPN: 38-64333
Fuel gauge, leaded, For modified long tank sender
Up to (V) 60080 (Part of kit 38-64331)
# 4
MPN: 38-64332
FUEL GAUGE, UNLEADED, FOR MODIFIED LONG TANK SENDER
Up to (V) 60080 (Part of kit 38-64330)
# 4
MPN: 38-64323
Fuel gauge, leaded, For short fuel tank sender
From (V) 60081 Up to Nov 1995
# 4
MPN: 38-64322
Fuel gauge, unleaded, For short fuel tank sender
From (V) 60081 Up to Nov 1995
from £222.54
from £222.54
# 4
MPN: 38-56085
FUEL GAUGE
From November 1995
from £161.55
from £161.55
# 5
MPN: 38-62240
OIL TEMPERATURE GAUGE
Up to November 1995
from £184.40
from £184.40
# 5
MPN: 38-56083
OIL TEMPERATURE GAUGE
From November 1995
from £148.00
from £148.00
# 5
MPN: 38-62239
OIL PRESSURE GAUGE
Up to November 1995
# 6
MPN: 38-56084
OIL PRESSURE GAUGE
From November 1995
from £268.71
from £268.71
# 7
MPN: 38-62255
VOLTMETER
Up to November 1995
from £328.05
from £328.05
# 7
MPN: 38-56087
VOLTMETER
From November 1995
from £148.00
from £148.00
# 8
MPN: 38-62243
CLOCK
Up to November 1995
from £324.61
from £324.61
# 8
MPN: 38-56095
CLOCK
From November 1995
from £298.46
from £298.46
# -
-
Ambient temperature gauge
# 9
MPN: 38-62260
INTERFACE ECU
Up to (V) 60080
from £904.26
from £904.26
# 9
MPN: 38-64335
INTERFACE ECU FOR MODIFIED LONG FUEL TANK SENDER
Up to (V) 60080 (Part of kits:38-64330/1
# 9
MPN: 38-64321
INTERFACE ECU
From (V) 60081 Up to Oct 1995
from £2,331.27
from £2,331.27
# 9
MPN: 38-74187
INTERFACE ECU
From Oct 1995 Up to Nov 1995
# 9
MPN: 38-74452
INTERFACE ECU
From November 1995
from £4,521.91
from £4,521.91
# -
-
ADHESIVE TAPE, 1/2 WIDE
Interface attach
# -
-
Warning lamp symbol set
# 10
MPN: 37-62791
WARNING LAMP BULB HOLDER
from £6.05
from £6.05
# 11
MPN: 38-62681
BULB COVER, GREEN, SMALL
from £1.60
from £1.60
# -
-
WOOD TRIM, INSTRUMENT CENTRE DASH
RHD
# -
-
WOOD TRIM, INSTRUMENT CENTRE DASH
LHD
# -
-
INSTRUMENT METAL PLATE
# -
-
WASHER, PLAIN, M5
Instrument metal plate to wood trim
# -
-
WASHER, SHAKEPROOF, M5
Instrument metal plate to wood trim
# -
-
NUT, M5
Instrument metal plate to wood trim
# -
-
SEAL STRIP
# 12
MPN: 83-62852
INSTRUMENT METAL PLATE
from £7.83
from £7.83
# -
-
SCREW, NO 4 X 1/4
Instrument metal plate to wood trim
# 13
MPN: 83-62850
SPACER PLATE, FOR WARNING LAMPS
Warning lamps to wood trim
from £2.56
from £2.56
# 14
MPN: 83-62851
SPACER, ROUND
Warning lamps to wood trim
from £2.11
from £2.11
# -
-
Wood trim, main instruments - without driver's airbag
Up to (V) 60090
# -
-
Wood trim, main instruments - with driver's airbag
Up to (V) 60090
# -
-
WOOD TRIM, MAIN INSTRUMENTS
All cars from (V) 60091
# -
-
WINGNUT, M5
Wood trim to dash
# -
-
SCREW, M5 X 25
Wood trim to dash
# -
-
WASHER, PLAIN, M5
Wood trim to dash
# 15
MPN: 37-62464
SWITCH, HOOD OPEN/CLOSE
from £36.33
from £36.33
# 16
MPN: 37-54987
SWITCH, SIDE/HEAD
from £152.71
from £152.71
# -
-
WOOD TRIM, DASH SIDE
RHD
# -
-
WOOD TRIM, DASH SIDE
LHD
# -
-
WASHER, PLAIN, M5
# -
-
NUT, M5
# -
-
SCREW, M3 X 8, BLACK, COUNTERSUNK HEAD
# 17
MPN: 37-64037
SWITCH, DIMMER, INSTRUMENT PANEL
from £223.21
from £223.21
# 18
MPN: 37-62465
KNOB, DIMMER SWITCH
from £4.36
from £4.36
# 19
MPN: 83-62666
BRACKET, DIMMER CONTROL MODULE
RHD
from £5.19
from £5.19
# 19
MPN: 83-62667
BRACKET, DIMMER CONTROL MODULE
LHD
from £3.97
from £3.97
# -
-
ADHESIVE TAPE, 50MM WIDE, DIMMER CONTROL
From (V) 60091
# -
-
SELF-ADHESIVE TAPE, 50MM WIDE, DIMMER CONTROL
# 20
MPN: 83-62676
BRACKET, DIMMER CONTROL POTENTIOMETER
from £38.21
from £38.21
# -
-
CLIP, NO 6
Bracket fixing to dash
# -
-
SCREW, NO. 6 X 1/2
Bracket fixing to dash
# 21
MPN: 37-64046
COLUMN SWITCH, MULTI-FUNCTION
from £289.24
from £289.24
# 22
MPN: 25-62289
Ignition Switch Assembly
from £69.61
from £69.61
# -
-
RADIO/CASSETTE PLAYER
# -
-
RADIO/CASSETTE PLAYER
# -
-
RADIO/CASSETTE PLAYER
From Feb 1994
# -
-
RADIO/CASSETTE PLAYER
USA & Canadian cars
# -
-
Radio/CD player, Optional fitment
From (V) 60178
# -
-
Radio/CD player, Optional fitment
From (V) 60092 Up to (V) 60191
# -
-
Radio/CD player, Optional fitment
From (V) 60192 Up to (V) 60211
# -
-
Radio/CD player, Optional fitment
From (V) 60212
# -
-
Radio/CD player, Optional fitment
USA & Canadian cars
# -
-
Amplifier, Optional fitment
Up to (V) 60177
# -
-
Amplifier, Optional fitment
From (V) 60178
# -
-
SCREW, PK, NO 6 X 3/8, OPTIONAL FITMENT
Amplifier attach - (not new amp)
# -
-
WASHER, PLAIN, NO 6, CHROME, OPTIONAL FITMENT
Amplifier attach - (not new amp)
# 23
MPN: 89-50251
AIR CONDITIONING CONTROL UNIT
# 24
MPN: 37-51413
SWITCH, HEATED FRONT SCREEN
from £25.55
from £25.55
# 25
MPN: 37-51413
SWITCH, HEATED REAR SCREEN
from £25.55
from £25.55
# 26
MPN: 37-50331
SWITCH, FRONT FOG LAMPS
from £31.79
from £31.79
# 27
MPN: 37-62854
SWITCH, REAR FOG LAMPS
from £38.78
from £38.78
# 28
MPN: 37-50331
SWITCH, SEAT HEATER
from £31.79
from £31.79
# 29
MPN: 37-62602
SWITCH PANEL, SELF ADHESIVE
See also 6.3D
from £27.57
from £27.57
# -
-
BULB, 12V 2W, PANEL ILLUMINATION
# -
-
Bulb retaining clip
# 30
MPN: 37-62463
SWITCH, WINDOW LIFT RH
from £57.16
from £57.16
# 30
MPN: 37-62639
SWITCH, WINDOW LIFT LH
from £72.85
from £72.85
# -
-
WASHER, PLAIN, M5
Switches attach
# -
-
NUT, NYLOC, M5
Switches attach
# -
-
SWITCH,'SPORT' MODE
Automatic cars only
# -
-
SPEAKER
# 31
MPN: 37-52075
SPEAKER MOUNTING RING
from £2.40
from £2.40
# -
-
SCREW, M4 X 20
Speaker fixing
# -
-
WASHER, PLAIN, M4
Speaker fixing
# 32
MPN: 37-61181
SEAT SWITCH
Up to (V) 60142 (Black connector)
from £705.66
from £705.66
# 32
MPN: 37-64560
SEAT SWITCH
From (V) 60143 (Grey connector)
from £349.87
from £349.87
# 33
MPN: 83-61465
BRACKET, SEAT SWITCH
from £7.63
from £7.63
# -
-
NUT, NYLOC, M5
Seat switch to bracket
# -
-
WASHER, SHAKEPROOF, M5
Seat switch to bracket
# 34
MPN: 37-62853
SWITCH, DOOR MIRROR
from £354.28
from £354.28
# 35
MPN: 37-23417
Fuse box, without fuses
from £15.71
from £15.71
# -
-
FUSE, 7.5 AMP, BROWN
# -
-
FUSE, 10 AMP, RED
# -
-
FUSE, 15 AMP, BLUE
# -
-
FUSE, 20 AMP, YELLOW
# -
-
FUSE, 25 AMP, CLEAR
# -
-
Fuse, 30 amp, green
# 36
MPN: 37-15367B
BUTTON, ENGRAVED 'BOOT'
from £5.38
from £5.38
# 37
MPN: 37-15367F
BUTTON, ENGRAVED 'FUEL'
from £5.17
from £5.17
# 38
MPN: 37-15369
SWITCH UNIT, BOOT OPEN
from £39.30
from £39.30
# 39
MPN: 696316
LOCKNUT, BRASS
from £1.83
from £1.83
# -
-
BEZEL, BLACK
# 40
MPN: 37-62934
BUTTON, BOOT OPEN SWITCH, (CAR SYMBOL)
from £9.78
from £9.78
# -
-
SWITCH UNIT, FUEL FLAPS
# -
-
Switch, lumbar control (part of 695135 lumbar kit)
Up to (V) 60144
# -
-
BEZEL, LUMBAR CONTROL SWITCH
# -
-
Switch, lumbar control, RH (seat symbol)
From (V) 60137 (Oct 1994)
# -
-
SWITCH, LUMBAR CONTROL, LH (SEAT SYMBOL)
From (V) 60137 (Oct 1994)
# -
-
SWITCH, LUMBAR CONTROL (ARROWS SYMBOL)
From Feb 1995
# 41
-
BONNET RELEASE HANDLE
See section 7
# 42
MPN: 695296
DOOR PULL
from £10.94
from £10.94
# -
-
WOOD TRIM, DOOR RH
Also fitted to Virage
# -
-
WOOD TRIM, DOOR LH
Also fitted to Virage
# -
-
SCREW, NO.6 X 3/8 IN., CHROME
Wood trim attach
# -
-
WOOD TRIM, RADIO AND AIR CONDITIONING CONTROL UNIT
# 43
MPN: 97-26457
LABEL, ODOMETER DISCREPANCY
USA cars
from £5.55
from £5.55
# -
-
SPECIAL MARKER PEN FOR LABEL
USA cars
# 44
MPN: 37-62936
BUTTON, ENGRAVED 'FUEL' (PETROL PUMP SYMBOL)
from £32.83
from £32.83
-part-diagram-6.2.webp "ASTON MARTIN V8 VIRAGE (2000) LAMPS & BULBS PARTS DIAGRAM")
-part-diagram-6.3a.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3b.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3c.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3d.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3e.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3f.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.4a.webp "ASTON MARTIN V8 VIRAGE (2000) WINDSCREEN WIPERS PARTS DIAGRAM")
-part-diagram-6.4b.webp "ASTON MARTIN V8 VIRAGE (2000) WINDSCREEN & HEADLAMP WASHERS PARTS DIAGRAM")
-part-diagram-7.1.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS FRAME PARTS DIAGRAM")
-part-diagram-7.10a.webp "ASTON MARTIN V8 VIRAGE (2000) SEAT BELTS, EUROPE, SALOON & VOLANTE PARTS DIAGRAM")
-part-diagram-7.10b.webp "ASTON MARTIN V8 VIRAGE (2000) SEAT BELTS, USA, SALOON PARTS DIAGRAM")
-part-diagram-7.2a.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS SUPERSTRUCTURE, FRONT PARTS DIAGRAM")
-part-diagram-7.2b.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS SUPERTRUCTURE, REAR PARTS DIAGRAM")
-part-diagram-7.3a.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, SALOON PARTS DIAGRAM")
-part-diagram-7.3b.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.3c.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, SALOON PARTS DIAGRAM")
-part-diagram-7.4a.webp "ASTON MARTIN V8 VIRAGE (2000) DOORS, SALOON PARTS DIAGRAM")
-part-diagram-7.4b.webp "ASTON MARTIN V8 VIRAGE (2000) DOORS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.4c.webp "ASTON MARTIN V8 VIRAGE (2000) DOOR LOCKING PARTS DIAGRAM")
-part-diagram-7.4d.webp "ASTON MARTIN V8 VIRAGE (2000) WEATHER SEALS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.5.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, FRONT PARTS DIAGRAM")
-part-diagram-7.6.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, BONNET PARTS DIAGRAM")
-part-diagram-7.7a.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, REAR PARTS DIAGRAM")
-part-diagram-7.7b1.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS PARTS DIAGRAM")
-part-diagram-7.7b2.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS PARTS DIAGRAM")
-part-diagram-7.7b3.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, FASCIA & CENTRE CONSOLE PARTS DIAGRAM")
-part-diagram-7.8a1.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, SALOON PARTS DIAGRAM")
-part-diagram-7.8a2.webp "ASTON MARTIN V8 VIRAGE (2000) DASH HOUSING, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a3.webp "ASTON MARTIN V8 VIRAGE (2000) CENTRE CONSOLE, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a4.webp "ASTON MARTIN V8 VIRAGE (2000) HEADER RAIL, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a5.webp "ASTON MARTIN V8 VIRAGE (2000) REAR TRIM, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8b1.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, SEAT FITTINGS & EUROPEAN SEATS PARTS DIAGRAM")
-part-diagram-7.8b2.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, USA SEAT BELTS PARTS DIAGRAM")
-part-diagram-7.8c.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS PARTS DIAGRAM")
-part-diagram-7.9a.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD FRAME ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9b.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD HYDRAULIC SYSTEM PARTS DIAGRAM")
-part-diagram-7.9c1.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9c2.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9d.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9e.webp "ASTON MARTIN V8 VIRAGE (2000) DROPPING REAR QUARTER LIGHT PARTS DIAGRAM")
-part-diagram-8.1.webp "ASTON MARTIN V8 VIRAGE (2000) ENGINE COMPARTMENT INSTALLATION PARTS DIAGRAM")
-part-diagram-8.2a.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR INSTALLATION PARTS DIAGRAM")
-part-diagram-8.2b.webp "ASTON MARTIN V8 VIRAGE (2000) SENSORS, SWITCHES, SOLENOIDS, MOTORS ETC PARTS DIAGRAM")
-part-diagram-9.1.webp "ASTON MARTIN V8 VIRAGE (2000) OPTIONAL EQUIPMENT PARTS DIAGRAM")
-part-diagram-9.2.webp "ASTON MARTIN V8 VIRAGE (2000) TOOLS & SUNDRIES PARTS DIAGRAM")
-part-diagram-9.3.webp "ASTON MARTIN V8 VIRAGE (2000) GASKET SETS PARTS DIAGRAM")
-part-diagram-1.1.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER BLOCK PARTS DIAGRAM")
-part-diagram-1.2.webp "ASTON MARTIN V8 VIRAGE (2000) CRANKSHAFT, PISTONS & RODS PARTS DIAGRAM")
-part-diagram-1.3a.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER HEAD, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-1.3b.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER HEAD, VOLATE FROM VIN 69225 PARTS DIAGRAM")
-part-diagram-1.4a.webp "ASTON MARTIN V8 VIRAGE (2000) TIMING CASE, WATER PUMP & SPROCKETS PARTS DIAGRAM")
-part-diagram-1.4b.webp "ASTON MARTIN V8 VIRAGE (2000) BELTS & CHAINS PARTS DIAGRAM")
-part-diagram-1.5.webp "ASTON MARTIN V8 VIRAGE (2000) OIL PUMP & SUMP PARTS DIAGRAM")
-part-diagram-1.6a.webp "ASTON MARTIN V8 VIRAGE (2000) OIL COOLING SYSTEM, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.6b.webp "ASTON MARTIN V8 VIRAGE (2000) OIL COOLING SYSTEM, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.7a1.webp "ASTON MARTIN V8 VIRAGE (2000) WATER COOLING SYSTEM, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.7a2.webp "ASTON MARTIN V8 VIRAGE (2000) WATER COOLING SYSTEM, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.7b1.webp "ASTON MARTIN V8 VIRAGE (2000) RADIATOR FAN COWL, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.7b2.webp "ASTON MARTIN V8 VIRAGE (2000) RADIATOR FAN COWL, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.8.webp "ASTON MARTIN V8 VIRAGE (2000) ENGINE MOUNTINGS PARTS DIAGRAM")
-part-diagram-1.9a.webp "ASTON MARTIN V8 VIRAGE (2000) IGNITION COIL, DISTRIBUTOR & STARTER MOTOR PARTS DIAGRAM")
-part-diagram-1.9b.webp "ASTON MARTIN V8 VIRAGE (2000) GENERATOR PARTS DIAGRAM")
-part-diagram-2.1a.webp "ASTON MARTIN V8 VIRAGE (2000) THROTTLE LINKAGE & CONTROLS, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.1b.webp "ASTON MARTIN V8 VIRAGE (2000) THROTTLE LINKAGE & CONTROLS, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-2.2a.webp "ASTON MARTIN V8 VIRAGE (2000) INLET MANIFOLDS & PLENUM PARTS DIAGRAM")
-part-diagram-2.2b1.webp "ASTON MARTIN V8 VIRAGE (2000) AIR FILTERS, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.2b2.webp "ASTON MARTIN V8 VIRAGE (2000) AIR FILTERS, VOLANTE, VIN 69224 ON PARTS DIAGRAM")
-part-diagram-2.3.webp "ASTON MARTIN V8 VIRAGE (2000) SECONDARY AIR INJECTION SYSTEM PARTS DIAGRAM")
-part-diagram-2.4.webp "ASTON MARTIN V8 VIRAGE (2000) VACUUM SYSTEM PARTS DIAGRAM")
-part-diagram-2.5a.webp "ASTON MARTIN V8 VIRAGE (2000) ELECTRONIC FUEL INJECTION, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.5b.webp "ASTON MARTIN V8 VIRAGE (2000) ELECTRONIC FUEL INJECTION, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-2.6.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-2.7a.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, EARLY CARS PARTS DIAGRAM")
-part-diagram-2.7b.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, VOLANTE, 1993 TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.7c.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-3.10.webp "ASTON MARTIN V8 VIRAGE (2000) HYPOID UNIT PARTS DIAGRAM")
-part-diagram-3.11.webp "ASTON MARTIN V8 VIRAGE (2000) HYPOID MOUNTING PARTS DIAGRAM")
-part-diagram-3.12.webp "ASTON MARTIN V8 VIRAGE (2000) DRIVESHAFT & HUB ASSEMBLY PARTS DIAGRAM")
-part-diagram-3.1a.webp "ASTON MARTIN V8 VIRAGE (2000) TORQUE CONVERTER, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.1b.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC PARTS DIAGRAM")
-part-diagram-3.2a.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.2b.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, APPROX VIN 60043 TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-3.2c.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, FROM APPROX VIN 60193 PARTS DIAGRAM")
-part-diagram-3.3a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED SELECTOR ASSEMBLY, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.3b1.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED SELECTOR ASSEMBLY, VOLANTE, APPROX VIN 60043 ON PARTS DIAGRAM")
-part-diagram-3.3b2.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED SELECTOR, GEAROX LINKAGE, VOLANTE, APPROX VIN 60043 ON PARTS DIAGRAM")
-part-diagram-3.4a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED GEARCASE & GEARTRAIN PARTS DIAGRAM")
-part-diagram-3.4b.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED GEARCASE & GEARTRAIN PARTS DIAGRAM")
-part-diagram-3.5a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED VALVE BODY, SUMP & PROPSHAFT PARTS DIAGRAM")
-part-diagram-3.5b.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED VALVE BODY, SUMP & PROPSHAFT PARTS DIAGRAM")
-part-diagram-3.6.webp "ASTON MARTIN V8 VIRAGE (2000) CLUTCH & FLYWHEEL PARTS DIAGRAM")
-part-diagram-3.7.webp "ASTON MARTIN V8 VIRAGE (2000) CLUTCH HYDRAULICS PARTS DIAGRAM")
-part-diagram-3.8.webp "ASTON MARTIN V8 VIRAGE (2000) MANUAL GEARBOX, CASING & SELECTOR PARTS DIAGRAM")
-part-diagram-3.9.webp "ASTON MARTIN V8 VIRAGE (2000) MANUAL GEARBOX, GEARTRAIN & PROPSHAFT PARTS DIAGRAM")
-part-diagram-4.1.webp "ASTON MARTIN V8 VIRAGE (2000) REAR SUSPENSION PARTS DIAGRAM")
-part-diagram-4.2.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT SUSPENSION PARTS DIAGRAM")
-part-diagram-4.3a.webp "ASTON MARTIN V8 VIRAGE (2000) STEERING COLUMN PARTS DIAGRAM")
-part-diagram-4.3a.1.webp "ASTON MARTIN V8 VIRAGE (2000) STEERING COLUMN, 1993 ON PARTS DIAGRAM")
-part-diagram-4.4.webp "ASTON MARTIN V8 VIRAGE (2000) POWER STEERING PARTS DIAGRAM")
-part-diagram-5.1a.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT BRAKES PARTS DIAGRAM")
-part-diagram-5.1b.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT BRAKES, VOLANTE ONLY PARTS DIAGRAM")
-part-diagram-5.2.webp "ASTON MARTIN V8 VIRAGE (2000) REAR BRAKES PARTS DIAGRAM")
-part-diagram-5.3.webp "ASTON MARTIN V8 VIRAGE (2000) HANDBRAKE PARTS DIAGRAM")
-part-diagram-5.4.webp "ASTON MARTIN V8 VIRAGE (2000) PEDAL GEAR PARTS DIAGRAM")
-part-diagram-5.5a.webp "ASTON MARTIN V8 VIRAGE (2000) WHEELS & TYRES PARTS DIAGRAM")
-part-diagram-5.5b.webp "ASTON MARTIN V8 VIRAGE (2000) WHEELS & TYRES, VOLANTE ONLY PARTS DIAGRAM")
-part-diagram-6.1a.webp "ASTON MARTIN V8 VIRAGE (2000) INSTRUMENTS & CONTROLS PARTS DIAGRAM")
