aston martin vanquish (2014) rear closure weatherstrip, volante parts diagram

01-0704-01A - Rear Closure Weatherstrip, Volante

Aston Martin Vanquish (2014) Rear Closure Weatherstrip, Volante Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: ED33-L51452-AB
              WEATHERSTRIP ASSY, TONNEAU
              Includes 2x item 9
              from £111.29
              from £111.29
              WEATHERSTRIP ASSEMBLY, TONNEAU Genuine Aston Martin - New (to order)
              # 2
              MPN: ED33-L51444-AB
              WEATHERSTRIP ASSY, TONNEAU TO BODY, RH
              from £74.29
              from £74.29
              WEATHERSTRIP ASSEMBLY, TONNEAU TO BODY, RH Genuine Aston Martin - New (to order)
              # 3
              MPN: ED33-L51445-AB
              WEATHERSTRIP ASSY, TONNEAU TO BODY, LH
              from £74.29
              from £74.29
              WEATHERSTRIP ASSEMBLY, TONNEAU TO BODY, LH Genuine Aston Martin - New (to order)
              # 4
              MPN: ED33-03828-AC
              WEATHERSTRIP, BODY SIDE / DECKLID, RH
              Includes Item 9 and 11
              from £314.46
              from £314.46
              WEATHERSTRIP, BODY SIDE / DECKLID, RH Genuine Aston Martin - New (to order)
              # 5
              MPN: ED33-03827-AC
              WEATHERSTRIP, BODY SIDE / TONNEAU, LH
              Includes Item 9
              from £252.05
              from £252.05
              WEATHERSTRIP, BODY SIDE / TONNEAU, LH Genuine Aston Martin - New (to order)
              # 6
              MPN: ED33-03829-AC
              SEAL, DECK LID TO REAR QUARTER, LH
              Includes Item 11
              from £430.18
              from £430.18
              SEAL, DECK LID TO REAR QUARTER, LH Genuine Aston Martin - New (to order)
              # 7
              MPN: CD33-C43720-AB
              WEATHERSTRIP, DECKLID
              from £381.30
              from £381.30
              WEATHERSTRIP, DECKLID Genuine Aston Martin - New (to order)
              # 8
              MPN: 70295
              NUT, M6, HEX FLANGED, SELF LOCK.
              NUT, M6, HEX FLANGED, SELF LOCK Genuine Aston Martin - New (to order)
              # 9
              MPN: 6G33-L02564-BA
              FIR TREE, 4MM X 0.76 - 5.94
              Part of 1,4, and 5
              from £0.50
              from £0.50
              FIR TREE FIX Genuine Aston Martin - New (to order)
              # 11
              MPN: 702213
              PIN, PUSH IN
              Part of 4 and 6
              from £0.47
              from £0.47
              PUSH IN PIN Genuine Aston Martin - New (to order)
              # 12
              MPN: ED33-53784-AA
              RETAINER, WEATHERSTRIP
              from £11.14
              from £11.14
              RETAINER, WEATHERSTRIP Genuine Aston Martin - New (to order)
