0137 - VEHICLE ECUs
Ferrari 812 Superfast (RHD) VEHICLE ECUs Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 310778
PASSIVE START ANTENNA
from £4.06
from £4.06
# 001
MPN: 322184
PASSIVE START ANTENNA
-Applicable for J-
from £32.15
from £32.15
# 002
MPN: 341225
PASSIVE START ANTENNA FASTENER BRACKET
from £12.72
from £12.72
# 003
MPN: 14303024
SCREW
-M4 X 12-
from £0.53
from £0.53
This part replaces part number 14303021 - and 1 more. Click to view details
# 004
MPN: 12601074
WASHER
from £0.54
from £0.54
This part replaces part number 12601070 which we have in stock
# 005
MPN: 85691900
SCREW
-M5 X 8-
from £0.53
from £0.53
# 006
MPN: 14059111
NUT
from £0.47
from £0.47
# 007
MPN: 342031
DASHBOARD NODE
from £364.36
from £364.36
# 008
MPN: 330829
COMPL. BRACKET
from £24.60
from £24.60
# 009
MPN: 85833700
SCREW
-M5 X 14-
from £0.47
from £0.47
# 010
MPN: 328097
PASSIVE START ECU
-Not for J-
from £201.98
from £201.98
This part replaces part number 310779
# 010
MPN: 328098
PASSIVE START ECU
-Applicable for J-
from £201.98
from £201.98
This part replaces part number 317012
# 011
MPN: 14059211
NUT
from £0.47
from £0.47
# 012
MPN: 336380
PARKING SENSOR NODE ECU
from £77.09
from £77.09
# 013
MPN: 14059211
NUT
from £0.47
from £0.47
# 014
MPN: 338729
AIRBAG ECU
Supersession
Supersession
# 015
MPN: 14059211
NUT
from £0.47
from £0.47
# 016
MPN: 323147
COMPL. AIRBAG ECU BRACKET
from £20.50
from £20.50
# 017
MPN: 16286124
SCREW
-M6 X 20-
from £0.47
from £0.47
# 018
MPN: 340875
A/C BLACK BOX
Supersession
Supersession
# 019
MPN: 330826
COMPL. AC BLACK BOX FASTENER BRACKET
-Not for GD-
from £36.54
from £36.54
# 019
MPN: 340720
COMPL. AC BLACK BOX FASTENER BRACKET
-Applicable for GD-
from £25.01
from £25.01
# 020
MPN: 14059211
NUT
from £0.47
from £0.47
# 021
MPN: 320089
RAIN AND TWILIGHT SENSOR
-No longer supplied- -Replaced by 786808-
from £125.57
from £125.57
# 021
MPN: 786808
RAIN AND TWILIGHT SENSOR
from £69.06
from £69.06
# 022
MPN: 334011
MAGNERIDE SUSPENSION ECU
from £354.52
from £354.52
# 023
MPN: 14059111
NUT
from £0.47
from £0.47
# 024
MPN: 330821
COMPL. RH INTERNAL BRACKET
from £15.17
from £15.17
# 025
MPN: 330823
COMPL. LH EXTERNAL BRACKET
-Not for GD-
from £29.45
from £29.45
# 025
MPN: 340912
COMPL. LH EXTERNAL BRACKET
-Applicable for GD-
from £21.33
from £21.33
# 026
MPN: 84583500
PLATE
from £0.67
from £0.67
# 027
MPN: 14059211
NUT
from £0.47
from £0.47
# 028
MPN: 328221
VEHICLE LIFT ECU
-Version with lifter-
from £294.44
from £294.44
# 029
MPN: 261704
CAP CONNECTOR
-Version with lifter-
from £26.99
from £26.99
# 030
MPN: 330810
COMPL. LIFT SYSTEM ECU MOUNTING BRACKET
from £35.68
from £35.68
# 031
MPN: 326645
LIFT SYSTEM ECU RETAINER BRACKET
-Version with lifter-
from £7.08
from £7.08
# 032
MPN: 160472
NUT
-Version with lifter-
from £1.23
from £1.23
# 033
MPN: 231617
SCREW
-M6 X 18- -Version with lifter-
from £0.47
from £0.47
This part replaces part number 14433124
# 034
MPN: 264097
VOLTAGE STABILIZER
-Applicable for HELE-
from £189.65
from £189.65
# 035
MPN: 12578111
NUT
-Applicable for HELE-
from £0.47
from £0.47
# 036
MPN: 315386
ADAPTIVE HEADLIGHT NODE ECU
-AFS-
from £90.22
from £90.22
# 037
MPN: 287268
NODE MOUNTING BRACKET
-AFS-
from £12.30
from £12.30
# 038
MPN: 11625824
SCREW
-M6 X 18- -AFS-
from £0.47
from £0.47
# 039
MPN: 294559
PWM COMMAND SIGNAL FOR FUEL PUMPS
from £115.92
from £115.92
# 040
MPN: 292632
COMPL. PWM ECU FASTENER BRACKET
from £12.47
from £12.47
# 041
MPN: 295945
COMPL. PWM ECU PROTECTION COVER
from £22.96
from £22.96
This part replaces part number 292634 - and 2 more. Click to view details
# 042
MPN: 11625824
SCREW
-M6 X 18-
from £0.47
from £0.47
# 043
MPN: 14059111
NUT
from £0.47
from £0.47
# 044
MPN: 85692300
SCREW
-M5 X 20-
from £0.47
from £0.47
This part replaces part number 83914200
# 045
MPN: 334012
ACTIVE AERO CONTROL UNIT
from £358.24
from £358.24
# 046
MPN: 330820
ECU COMPARTMENT COVER BRACKET
-Not for GD-
from £74.55
from £74.55
# 046
MPN: 340913
ECU COMPARTMENT COVER BRACKET
-Applicable for GD-
from £45.93
from £45.93
# 047
MPN: 14059111
NUT
from £0.47
from £0.47
# 048
MPN: 14059211
NUT
from £0.47
from £0.47
# 049
MPN: 304001
DCT GEARBOX ECU
-Unprogrammed- -Applicable up to Ass. No. 154835-
from £1,087.07
from £1,087.07
This part replaces part number 279430
# 049
MPN: 330778
DCT GEARBOX ECU
-Unprogrammed- -Applicable from Ass. No. 154836-
from £492.04
from £492.04
# 050
MPN: 14059111
NUT
from £0.47
from £0.47
# 051
MPN: 330828
PARKING CAMERA ECU PROTECTIVE COVER
-Version with front and rear digital cameras-
from £20.92
from £20.92
# 052
MPN: 85692000
SCREW
-M5 X 10- -Version with front and rear digital cameras-
from £0.53
from £0.53
# 053
MPN: 331381
PARKING CAMERA ECU
-Version with front and rear digital cameras-
from £647.92
from £647.92
# 054
MPN: 314834
FRONT DIGITAL CAMERA VIDEO CABLE
-Version with front and rear digital cameras-
from £124.62
from £124.62
# 055
MPN: 14303024
SCREW
-M4 X 12- -Version with front and rear digital cameras-
from £0.51
from £0.51
This part replaces part number 14303021 - and 1 more. Click to view details
# 056
MPN: 314815
TPMS ECU/ANTENNA
-Not for J-
from £185.74
from £185.74
# 056
MPN: 314817
TPMS ECU/ANTENNA
-Applicable for J-
from £337.70
from £337.70
# 057
MPN: 195646
CLIP
from £0.75
from £0.75
# 058
MPN: 231617
SCREW
-M6 X 18- -AFS-
from £0.47
from £0.47
This part replaces part number 14433124
# 059
MPN: 14059111
NUT
from £0.47
from £0.47
# 060
MPN: 335916
TPMS BRACKET
from £10.25
from £10.25
# 061
MPN: 256323
SCREW
-M5 X 16-
from £0.47
from £0.47
# 062
MPN: 337737
IGNITION ECU
-Unprogrammed-
from £929.01
from £929.01
# 063
MPN: 338526
RH MOTRONIC FASTENER BRACKET
from £30.76
from £30.76
# 064
MPN: 338527
LH MOTRONIC FASTENER BRACKET
from £30.76
from £30.76
# 065
MPN: 339174
MOTRONIC CENTRAL FASTENER BRACKET
from £23.49
from £23.49
# 066
MPN: 339487
CONNECTOR FASTENER BRACKET
from £21.24
from £21.24
# 067
MPN: 313125
ION ECU
-Unprogrammed-
from £797.95
from £797.95
# 068
MPN: 340412
ECM REAR CALLIPER CONTROL UNIT
from £261.70
from £261.70
# 069
MPN: 16296924
SCREW
-M6 X 14-
from £0.47
from £0.47
This part replaces part number 289834
# 070
MPN: 12647624
WASHER
from £0.51
from £0.51
This part replaces part number 12647611
# 071
MPN: 231617
SCREW
-M6 X 18-
from £0.47
from £0.47
This part replaces part number 14433124
# 072
MPN: 256323
SCREW
-M5 X 16-
from £0.47
from £0.47
# 073
MPN: 341831
COMPL. HATCH CONNECTOR BRACKET
from £36.53
from £36.53
This part replaces part number 336558 - and 1 more. Click to view details
# 074
MPN: 14303024
SCREW
-M4 X 12-
from £0.51
from £0.51
This part replaces part number 14303021 - and 1 more. Click to view details
# 075
MPN: 12601074
WASHER
from £0.53
from £0.53
This part replaces part number 12601070 which we have in stock
# 076
MPN: 330811
COMPL. CVB ECU MOUNTING BRACKET
from £14.36
from £14.36
# 077
MPN: 231616
SCREW
-M6 X 14-
from £0.47
from £0.47
This part replaces part number 14305724 which we have in stock
-part-diagram-0138.webp "FERRARI 812 SUPERFAST (RHD) ANTI-THEFT SYSTEM PARTS DIAGRAM")
-part-diagram-0139.webp "FERRARI 812 SUPERFAST (RHD) INFOTAINMENT SYSTEM PARTS DIAGRAM")
-part-diagram-0140.webp "FERRARI 812 SUPERFAST (RHD) AUDIO SPEAKER SYSTEM PARTS DIAGRAM")
-part-diagram-0141.webp "FERRARI 812 SUPERFAST (RHD) TELEMETRY PARTS DIAGRAM")
-part-diagram-0142.webp "FERRARI 812 SUPERFAST (RHD) ADHESIVE LABELS AND PLAQUES PARTS DIAGRAM")
-part-diagram-0999.webp "FERRARI 812 SUPERFAST (RHD) COLOUR CODES PARTS DIAGRAM")
-part-diagram-0000.webp "FERRARI 812 SUPERFAST (RHD) SPARE ASSEMBLY UNITS PARTS DIAGRAM")
-part-diagram-0001.webp "FERRARI 812 SUPERFAST (RHD) CRANKCASE PARTS DIAGRAM")
-part-diagram-0002.webp "FERRARI 812 SUPERFAST (RHD) CRANKSHAFT - CONNECTING RODS AND PISTONS PARTS DIAGRAM")
-part-diagram-0003.webp "FERRARI 812 SUPERFAST (RHD) RIGHT HAND CYLINDER HEAD PARTS DIAGRAM")
-part-diagram-0004.webp "FERRARI 812 SUPERFAST (RHD) LEFT HAND CYLINDER HEAD PARTS DIAGRAM")
-part-diagram-0005.webp "FERRARI 812 SUPERFAST (RHD) TIMING SYSTEM - TAPPETS PARTS DIAGRAM")
-part-diagram-0006.webp "FERRARI 812 SUPERFAST (RHD) TIMING SYSTEM - DRIVE PARTS DIAGRAM")
-part-diagram-0007.webp "FERRARI 812 SUPERFAST (RHD) INJECTION - IGNITION SYSTEM PARTS DIAGRAM")
-part-diagram-0008.webp "FERRARI 812 SUPERFAST (RHD) SECONDARY AIR SYSTEM PARTS DIAGRAM")
-part-diagram-0009.webp "FERRARI 812 SUPERFAST (RHD) FUEL TANK, FUEL SYSTEM PUMPS AND PIPES PARTS DIAGRAM")
-part-diagram-0010.webp "FERRARI 812 SUPERFAST (RHD) FUEL TANK AND FILLER NECK PARTS DIAGRAM")
-part-diagram-0011.webp "FERRARI 812 SUPERFAST (RHD) EVAPORATIVE EMISSIONS CONTROL SYSTEM PARTS DIAGRAM")
-part-diagram-0012.webp "FERRARI 812 SUPERFAST (RHD) INTAKE MANIFOLD PARTS DIAGRAM")
-part-diagram-0013.webp "FERRARI 812 SUPERFAST (RHD) AIR INTAKE PARTS DIAGRAM")
-part-diagram-0014.webp "FERRARI 812 SUPERFAST (RHD) PRE-CATALYTIC CONVERTERS AND CATALYTIC CONVERTERS PARTS DIAGRAM")
-part-diagram-0015.webp "FERRARI 812 SUPERFAST (RHD) SILENCERS PARTS DIAGRAM")
-part-diagram-0016.webp "FERRARI 812 SUPERFAST (RHD) GEARBOX OIL LUBRICATION AND COOLING SYSTEM PARTS DIAGRAM")
-part-diagram-0017.webp "FERRARI 812 SUPERFAST (RHD) LUBRICATION SYSTEM: TANK PARTS DIAGRAM")
-part-diagram-0018.webp "FERRARI 812 SUPERFAST (RHD) COOLING - OIL PUMP PARTS DIAGRAM")
-part-diagram-0019.webp "FERRARI 812 SUPERFAST (RHD) COOLING - HEADER TANK AND PIPES PARTS DIAGRAM")
-part-diagram-0020.webp "FERRARI 812 SUPERFAST (RHD) COOLING - RADIATORS AND AIR DUCTS PARTS DIAGRAM")
-part-diagram-0021.webp "FERRARI 812 SUPERFAST (RHD) TRANSMISSION HOUSING PARTS DIAGRAM")
-part-diagram-0022.webp "FERRARI 812 SUPERFAST (RHD) TRANSMISSION PIPE PARTS DIAGRAM")
-part-diagram-0023.webp "FERRARI 812 SUPERFAST (RHD) COMPLETE PEDAL BOARD ASSEMBLY PARTS DIAGRAM")
-part-diagram-0024.webp "FERRARI 812 SUPERFAST (RHD) GEARBOX HOUSING PARTS DIAGRAM")
-part-diagram-0025.webp "FERRARI 812 SUPERFAST (RHD) SERVO BRAKE SYSTEM PARTS DIAGRAM")
-part-diagram-0026.webp "FERRARI 812 SUPERFAST (RHD) BRAKE SYSTEM PARTS DIAGRAM")
-part-diagram-0027.webp "FERRARI 812 SUPERFAST (RHD) FRONT BRAKE CALLIPERS PARTS DIAGRAM")
-part-diagram-0028.webp "FERRARI 812 SUPERFAST (RHD) REAR BRAKE CALLIPERS PARTS DIAGRAM")
-part-diagram-0029.webp "FERRARI 812 SUPERFAST (RHD) ELECTRIC STEERING BOX PARTS DIAGRAM")
-part-diagram-0030.webp "FERRARI 812 SUPERFAST (RHD) STEERING CONTROL PARTS DIAGRAM")
-part-diagram-0031.webp "FERRARI 812 SUPERFAST (RHD) FRONT SUSPENSION - SHOCK ABSORBER AND BRAKE DISC PARTS DIAGRAM")
-part-diagram-0032.webp "FERRARI 812 SUPERFAST (RHD) FRONT SUSPENSION - ARMS PARTS DIAGRAM")
-part-diagram-0033.webp "FERRARI 812 SUPERFAST (RHD) REAR SUSPENSION - SHOCK ABSORBER AND BRAKE DISC PARTS DIAGRAM")
-part-diagram-0034.webp "FERRARI 812 SUPERFAST (RHD) REAR SUSPENSION - ARMS PARTS DIAGRAM")
-part-diagram-0035.webp "FERRARI 812 SUPERFAST (RHD) WHEELS PARTS DIAGRAM")
-part-diagram-0036.webp "FERRARI 812 SUPERFAST (RHD) VEHICLE LIFT SYSTEM PARTS DIAGRAM")
-part-diagram-0037.webp "FERRARI 812 SUPERFAST (RHD) BATTERY PARTS DIAGRAM")
-part-diagram-0038.webp "FERRARI 812 SUPERFAST (RHD) ALTERNATOR - STARTER MOTOR PARTS DIAGRAM")
-part-diagram-0039.webp "FERRARI 812 SUPERFAST (RHD) AC SYSTEM COMPRESSOR PARTS DIAGRAM")
-part-diagram-0040.webp "FERRARI 812 SUPERFAST (RHD) AC SYSTEM - WATER AND FREON PARTS DIAGRAM")
-part-diagram-0041.webp "FERRARI 812 SUPERFAST (RHD) EVAPORATOR UNIT PARTS DIAGRAM")
-part-diagram-0042.webp "FERRARI 812 SUPERFAST (RHD) DASHBOARD AIR DUCTS PARTS DIAGRAM")
-part-diagram-0043.webp "FERRARI 812 SUPERFAST (RHD) TOOLS AND ACCESSORIES PROVIDED WITH VEHICLE PARTS DIAGRAM")
-part-diagram-0100.webp "FERRARI 812 SUPERFAST (RHD) BODYSHELL - EXTERNAL TRIM PARTS DIAGRAM")
-part-diagram-0101.webp "FERRARI 812 SUPERFAST (RHD) GREENHOUSE PARTS DIAGRAM")
-part-diagram-0102.webp "FERRARI 812 SUPERFAST (RHD) STRUCTURES AND ELEMENTS, FRONT OF VEHICLE PARTS DIAGRAM")
-part-diagram-0103.webp "FERRARI 812 SUPERFAST (RHD) STRUCTURES AND ELEMENTS, CENTRE OF VEHICLE PARTS DIAGRAM")
-part-diagram-0104.webp "FERRARI 812 SUPERFAST (RHD) STRUCTURES AND ELEMENTS, REAR OF VEHICLE PARTS DIAGRAM")
-part-diagram-0105.webp "FERRARI 812 SUPERFAST (RHD) CHASSIS COMPLETION PARTS DIAGRAM")
-part-diagram-0106.webp "FERRARI 812 SUPERFAST (RHD) FLAT UNDERTRAY AND WHEELHOUSES PARTS DIAGRAM")
-part-diagram-0107.webp "FERRARI 812 SUPERFAST (RHD) INSULATION PARTS DIAGRAM")
-part-diagram-0108.webp "FERRARI 812 SUPERFAST (RHD) PASSENGER COMPARTMENT MATS PARTS DIAGRAM")
-part-diagram-0109.webp "FERRARI 812 SUPERFAST (RHD) LUGGAGE COMPARTMENT MATS PARTS DIAGRAM")
-part-diagram-0110.webp "FERRARI 812 SUPERFAST (RHD) HEADLINER TRIM AND ACCESSORIES PARTS DIAGRAM")
-part-diagram-0111.webp "FERRARI 812 SUPERFAST (RHD) FRONT LID AND OPENING MECHANISM PARTS DIAGRAM")
-part-diagram-0112.webp "FERRARI 812 SUPERFAST (RHD) REAR LID AND OPENING MECHANISM PARTS DIAGRAM")
-part-diagram-0113.webp "FERRARI 812 SUPERFAST (RHD) FUEL FILLER FLAP AND CONTROLS PARTS DIAGRAM")
-part-diagram-0114.webp "FERRARI 812 SUPERFAST (RHD) DOORS - SUBSTRUCTURE AND TRIM PARTS DIAGRAM")
-part-diagram-0115.webp "FERRARI 812 SUPERFAST (RHD) DOORS - OPENING MECHANISMS AND HINGES PARTS DIAGRAM")
-part-diagram-0116.webp "FERRARI 812 SUPERFAST (RHD) DOORS - POWER WINDOW AND REAR VIEW MIRROR PARTS DIAGRAM")
-part-diagram-0117.webp "FERRARI 812 SUPERFAST (RHD) FRONT BUMPER PARTS DIAGRAM")
-part-diagram-0118.webp "FERRARI 812 SUPERFAST (RHD) REAR BUMPER PARTS DIAGRAM")
-part-diagram-0119.webp "FERRARI 812 SUPERFAST (RHD) REAR ACTIVE AERO PARTS DIAGRAM")
-part-diagram-0120.webp "FERRARI 812 SUPERFAST (RHD) SCREENS, WINDOWS AND SEALS PARTS DIAGRAM")
-part-diagram-0121.webp "FERRARI 812 SUPERFAST (RHD) FRONT SEAT - SEAT BELTS, GUIDES AND ADJUSTMENT PARTS DIAGRAM")
-part-diagram-0122.webp "FERRARI 812 SUPERFAST (RHD) FRONT SEAT - TRIM AND ACCESSORIES PARTS DIAGRAM")
-part-diagram-0123.webp "FERRARI 812 SUPERFAST (RHD) RACING SEAT PARTS DIAGRAM")
-part-diagram-0124.webp "FERRARI 812 SUPERFAST (RHD) INTERIOR TRIM PARTS DIAGRAM")
-part-diagram-0125.webp "FERRARI 812 SUPERFAST (RHD) TUNNEL - SUBSTRUCTURE AND ACCESSORIES PARTS DIAGRAM")
-part-diagram-0126.webp "FERRARI 812 SUPERFAST (RHD) DASHBOARD PARTS DIAGRAM")
-part-diagram-0127.webp "FERRARI 812 SUPERFAST (RHD) DASHBOARD FASTENINGS PARTS DIAGRAM")
-part-diagram-0128.webp "FERRARI 812 SUPERFAST (RHD) GLOVE COMPARTMENT PARTS DIAGRAM")
-part-diagram-0129.webp "FERRARI 812 SUPERFAST (RHD) AIRBAGS PARTS DIAGRAM")
-part-diagram-0130.webp "FERRARI 812 SUPERFAST (RHD) DASHBOARD AND TUNNEL INSTRUMENTS PARTS DIAGRAM")
-part-diagram-0131.webp "FERRARI 812 SUPERFAST (RHD) HEADLIGHTS AND TAILLIGHTS PARTS DIAGRAM")
-part-diagram-0132.webp "FERRARI 812 SUPERFAST (RHD) SHIELDS - EXTERNAL TRIM PARTS DIAGRAM")
-part-diagram-0133.webp "FERRARI 812 SUPERFAST (RHD) WINDSCREEN WIPER, WINDSCREEN WASHER AND HORNS PARTS DIAGRAM")
-part-diagram-0134.webp "FERRARI 812 SUPERFAST (RHD) MAIN WIRING HARNESSES PARTS DIAGRAM")
-part-diagram-0135.webp "FERRARI 812 SUPERFAST (RHD) VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM PARTS DIAGRAM")
-part-diagram-0136.webp "FERRARI 812 SUPERFAST (RHD) ELECTRONIC MANAGEMENT (SUSPENSION) PARTS DIAGRAM")
