103 - Rear Bumper and Supports
Ferrari F50 Rear Bumper and Supports Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 63529610
COMPLETE REAR BUMPER
- Not for USA
from £21,425.99
from £21,425.99
This part replaces part number 63529600
# 001
MPN: 64635110
COMPLETE REAR BUMPER
- Valid for USA
from £11,267.97
from £11,267.97
# 002
MPN: 64133100
BUMPER LATERAL FIXING RH BRACKET
from £206.09
from £206.09
# 002
MPN: 64133200
BUMPER LATERAL FIXING LH BRACKET
from £273.11
from £273.11
# 003
MPN: 10902011
SCREW
from £1.08
from £1.08
This part replaces part number 10902411
# 004
MPN: 127494
WASHER
(minimum order quantity = 20)
from £0.52
from £0.52
This part replaces part number 10516470 - and 4 more. Click to view details
# 005
MPN: 12643701
WASHER
Supersession
Supersession
This part replaces part number 12643704 - and 1 more. Click to view details
# 006
MPN: 154121
LH BRACKET
from £91.79
from £91.79
# 006
MPN: 154122
RH BRACKET
from £91.64
from £91.64
# 007
MPN: 13842414
SCREW
Supersession
Supersession
# 008
MPN: 145097
SCREW
from £6.91
from £6.91
# 009
MPN: 102825
NUT
from £0.53
from £0.53
This part replaces part number 95900617
# 010
MPN: 16287524
SCREW
from £0.82
from £0.82
This part replaces part number 16287521
# 011
MPN: 12642024
WASHER
from £0.54
from £0.54
This part replaces part number 12642020 - and 1 more. Click to view details
# 012
MPN: 63596600
COMPLETE REAR GRILL
from £3,823.80
from £3,823.80
# 013
MPN: 186180
NUMBER PLATE LIGHT
from £15.93
from £15.93
This part replaces part number 175204 - and 5 more. Click to view details
# 014
MPN: 10857790
12V 5W BULB
from £1.28
from £1.28
This part replaces part number 101524
# 015
MPN: 64134300
ENERGY ABSORBING SMALL BLOCK
from £64.91
from £64.91
# 016
MPN: 65058000
SPACER
from £3.18
from £3.18
This part replaces part number 64132700
# 017
MPN: 14058411
NUT
from £0.50
from £0.50
# 018
MPN: 12643724
WASHER
from £0.50
from £0.50
This part replaces part number 109684 - and 4 more. Click to view details
# 019
MPN: 65017300
SPACER
from £17.18
from £17.18
# 020
MPN: 64132600
PIN
from £87.94
from £87.94
# 021
MPN: 64178500
CAVALLINO RAMPANTE
from £278.42
from £278.42
# 022
MPN: 60995100
RUBBER RING
from £1.74
from £1.74
# 023
MPN: 12639401
WASHER
from £0.54
from £0.54
# 024
MPN: 61002200
NUT
from £1.08
from £1.08
# 025
MPN: 60097003
PLATE FRAME
- Not for USA
from £16.63
from £16.63
This part replaces part number 60096401 which we have in stock
# 026
MPN: 15688175
SCREW
from £0.53
from £0.53
This part replaces part number 15688108
# 027
MPN: 15644178
SCREW
Supersession
Supersession
# 028
MPN: 64138500
RH REAR FRAME
from £1,222.45
from £1,222.45
# 029
MPN: 64138600
LH REAR FRAME
from £1,850.60
from £1,850.60
# 030
MPN: 10978087
SCREW
from £5.50
from £5.50
# 031
MPN: 166467
WASHER
from £0.50
from £0.50
# 032
MPN: 14496377
WASHER
from £1.07
from £1.07
This part replaces part number 14496309
# 033
MPN: 62471100
BRACKET
from £16.25
from £16.25
# 034
MPN: 64722000
RIVET
from £1.36
from £1.36
# 035
MPN: 10732531
WASHER
from £0.53
from £0.53
# 036
MPN: 11193874
WASHER
from £0.53
from £0.53
This part replaces part number 11193879 which we have in stock
# 037
MPN: 16043324
SCREW
from £0.51
from £0.51
This part replaces part number 16043321
# 038
MPN: 64762800
NEST FOR BUMPER
- Valid for USA
from £3,673.01
from £3,673.01
# 039
MPN: 65054700
RH INSULATION
from £182.44
from £182.44
# 040
MPN: 65054800
LH INSULATION
from £182.44
from £182.44
# 041
MPN: 64640800
REAR PLATE FRAME
- Vale per USA
from £35.91
from £35.91
# 042
MPN: 60987900
NUMBER PLATE RIM
- Valid for USA
from £38.94
from £38.94
# 043
MPN: 62556300
RIVET
- Valid for USA
from £0.71
from £0.71
# 044
MPN: 10902624
SCREW
- Valid for USA
from £0.52
from £0.52
This part replaces part number 10902621
# 045
MPN: 14496424
WASHER
- Valid for USA
Supersession
Supersession
This part replaces part number 14496401 - and 3 more. Click to view details
# 046
MPN: 12646201
WASHER
- Valid for USA
from £0.53
from £0.53
# 047
MPN: 65089500
RH HEAT SHIELD
from £80.61
from £80.61
# 047
MPN: 65089600
LH HEAT SHIELD
from £80.61
from £80.61
# 048
MPN: 13832101
NUT
from £0.51
from £0.51
# 049
MPN: 65126900
LH PROTECTION
from £35.82
from £35.82
This part replaces part number 65122100
# 049
MPN: 65127100
RH PROTECTION
from £35.82
from £35.82
This part replaces part number 65122100
# 050
MPN: 14359274
SCREW
from £1.08
from £1.08
This part replaces part number 168691
