lamborghini countach 5000 qvi (1989) electrical system parts diagram

007B - electrical system

Lamborghini Countach 5000 QVi (1989) Electrical System Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 001
MPN: 001623083
WIRING HARNESS
CABLAGGIO POSTERIORE
# 002
MPN: 001623081
WIRING HARNESS
CABLAGGIO CENTRALE
# 003
MPN: 001623294
WIRING HARNESS
CABLAGGIO ANTERIORE
# 004
MPN: 001623288
WIRING HARNESS
Left side injection wiring
# 005
MPN: 001623289
WIRING HARNESS
Control unit wiring
# 006
MPN: 001623287
WIRING HARNESS
Cablaggio iniezione lato des.
# 007
MPN: 001623292
WIRING HARNESS
Complete injection wiring
from £1,728.70
from £1,728.70
