lamborghini countach lpi 800-4 (2022) hydraulics control unit parts diagram

325.01.00 - HYDRAULICS CONTROL UNIT

Lamborghini Countach LPI 800-4 (2022) HYDRAULICS CONTROL UNIT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Price
            # 001
            -
            GEAR SELECTOR
            # 001
            MPN: 0CE301247B
            GEAR SELECTOR
            from £13,860.21
            from £13,860.21
            # 002
            MPN: 470398189
            SEAL
            from £488.52
            from £488.52
            # 003
            -
            SHAFT OIL SEAL
            # 003
            MPN: 0CE311556
            SHAFT OIL SEAL
            45X62X10
            from £95.11
            from £95.11
            # 004
            -
            CYLINDER FITTING SCREW WITH INNER MULTIPOINT HEAD
            # 005
            -
            CUP WASHER
            # 006
            MPN: 470398135B
            OIL DRAIN PLUG
            from £148.29
            from £148.29
            # 007
            MPN: 900000140
            CENTR. HYDRAULIC OIL
            from £68.99
            from £68.99
            # 008
            MPN: 470398048
            GASKET SET
            from £1,011.64
            from £1,011.64
            # 009
            -
            SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD
            # 010
            -
            SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD
            # 011
            -
            CENTRING PIN
