lamborghini diablo vt (1995) tail light rear parts diagram

945.02.00 - TAIL LIGHT REAR

Lamborghini Diablo VT (1995) TAIL LIGHT REAR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 001
                            MPN: 006329830
                            REVERSE LAMP
                            RIGHT
                            Supersession
                            Supersession
                            Genuine Lamborghini (no longer available to order)
                            # 001
                            MPN: 006329831
                            REAR FOG LIGHT
                            LEFT
                            Supersession
                            Supersession
                            Genuine Lamborghini (no longer available to order)
                            # 002
                            MPN: 006617094
                            BULB
                            from £5.62
                            from £5.62
                            BULB Genuine Lamborghini - New (to order)
                            # 003
                            MPN: 008200503
                            NUT
                            from £2.07
                            from £2.07
                            M5 UNI 7473 ZD SELF-LOCKIN GNUT Genuine Lamborghini - New (to order)
                            # 004
                            MPN: 008400506
                            WASHER
                            from £0.53
                            from £0.53
                            FLAT WASHER 5.3X1.5X15 Genuine Lamborghini - New (to order)
                            # 005
                            MPN: 006617095
                            BULB
                            from £6.28
                            from £6.28
                            BULB Genuine Lamborghini - New In stock
                            # 006
                            MPN: 008222801
                            CLIP
                            Supersession
                            Supersession
                            Genuine Lamborghini (no longer available to order)
                            # 007
                            MPN: 008700445
                            SCREW
                            from £0.51
                            from £0.51
                            LOCK SCREW 3.5X16DIN7981/ZG Genuine Lamborghini - New In stock
                            # 008
                            MPN: 006328344
                            LICENCE PLATE LAMP
                            (EUROPE, UK spec vehicles)
                            from £29.12
                            from £29.12
                            NUMBER PLATE LIGHT Genuine Lamborghini - New In stock
                            # 008
                            MPN: 006331461
                            LICENCE PLATE LAMP
                            (USA spec vehicles)
                            from £40.72
                            from £40.72
                            NUMBER PLATE LIGHT Genuine Lamborghini - New (to order)
                            # 009
                            MPN: 009411300
                            LINING
                            RIGHT
                            from £121.23
                            from £121.23
                            RH REAR HEADLIGHT COVER PAN. Genuine Lamborghini - New (to order)
                            RH REAR HEADLIGHT COVER PAN. Genuine Lamborghini - Used In stock
                            # 009
                            MPN: 009411301
                            LINING
                            LEFT
                            from £220.42
                            from £220.42
                            LH REAR HEADLIGHT COVER PAN. Genuine Lamborghini - New (to order)
                            # 009
                            MPN: 009411304
                            LINING
                            RIGHT
                            from £86.12
                            from £86.12
                            RH REAR HEADLIGHT COVER. PAN. Genuine Lamborghini - New (to order)
                            RH REAR HEADLIGHT COVER. PAN. Genuine Lamborghini - Used In stock
                            # 009
                            MPN: 009411305
                            LINING
                            LEFT
                            from £86.12
                            from £86.12
                            LEFT LINING Genuine Lamborghini - New (to order)
                            LEFT LINING Genuine Lamborghini - Used In stock
                            # 011
                            MPN: 006329828
                            TAIL LAMP / BRAKE L.
                            from £55.60
                            from £55.60
                            REAR LIGHT CLUSTER Genuine Lamborghini - New (to order)
                            # 012
                            MPN: 006329829
                            TURNING LIGHT
                            from £49.35
                            from £49.35
                            REAR LIGHT CLUSTER Genuine Lamborghini - New (to order)
                            # 013
                            MPN: 006617091
                            BULB
                            from £7.68
                            from £7.68
                            21W BULB Genuine Lamborghini - New (to order)
                            # 014
                            MPN: 008400607
                            WASHER
                            Supersession
                            Supersession
                            Genuine Lamborghini (no longer available to order)
                            # 015
                            MPN: 008410611
                            WASHER
                            from £0.51
                            from £0.51
                            SNAP RING D.6 DIN 7980 Genuine Lamborghini - New (to order)
                            # 016
                            MPN: 008200603
                            NUT
                            from £0.51
                            from £0.51
                            M6 UNI 5588/5S/Z NUT Genuine Lamborghini - New (to order)
                            # 017
                            MPN: 006319022
                            PLATE
                            from £227.91
                            from £227.91
                            REFLECTOR Genuine Lamborghini - New In stock
                            # 018
                            MPN: 006131546
                            ELECT CABLE
                            (USA spec vehicles)
                            from £29.05
                            from £29.05
                            RH/LH REAR SIDE MARKER WIRING Genuine Lamborghini - New (to order)
                            # 019
                            MPN: 008200503
                            NUT
                            (USA spec vehicles)
                            from £2.07
                            from £2.07
                            M5 UNI 7473 ZD SELF-LOCKIN GNUT Genuine Lamborghini - New (to order)
                            # 020
                            MPN: 008400501
                            WASHER
                            (USA spec vehicles)
                            from £0.51
                            from £0.51
                            WASHER 5.8X18X2 Genuine Lamborghini - New In stock
                            # 021
                            MPN: 009490106
                            GASKET
                            (USA spec vehicles)
                            from £16.61
                            from £16.61
                            SEAL UNDER SIDEMARKER Genuine Lamborghini - New (to order)
                            # 022
                            MPN: 006617092
                            NBULB
                            (USA spec vehicles)
                            Supersession
                            Supersession
                            Genuine Lamborghini (no longer available to order)
                            # 023
                            MPN: 006331782
                            REAR SIDEMARKER (RED)
                            (USA spec vehicles)
                            from £24.27
                            from £24.27
                            This part replaces part number 006320487 - and 1 more. Click to view details
                            REAR SIDE MARKER (RED) Genuine Lamborghini - New In stock
                            REAR SIDE MARKER (RED) Genuine Lamborghini - Used In stock
