lamborghini diablo vt (1996) left head accessories parts diagram

103.06.00 - LEFT HEAD ACCESSORIES

Lamborghini Diablo VT (1996) LEFT HEAD ACCESSORIES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                  #
                                                                  Part number
                                                                  Description
                                                                  Key
                                                                  Price
                                                                  # 001
                                                                  MPN: 001731535
                                                                  TUBE
                                                                  TUBE Genuine Lamborghini - New (to order)
                                                                  # 002
                                                                  MPN: 008300610
                                                                  PRISONER
                                                                  from £15.81
                                                                  from £15.81
                                                                  STUD 6X1X16 8G UNI5911 Z. Genuine Lamborghini - New (to order)
                                                                  # 003
                                                                  MPN: 008200605
                                                                  DICE
                                                                  from £1.79
                                                                  from £1.79
                                                                  M6 NCM 70 URAMA SIMMON NUT Genuine Lamborghini - New In stock
                                                                  # 004
                                                                  MPN: 008832003
                                                                  GIRDLE
                                                                  from £28.32
                                                                  from £28.32
                                                                  FASC.19-28 H.12 Genuine Lamborghini - New In stock
                                                                  # 005
                                                                  MPN: 001730064
                                                                  JUNCTION
                                                                  from £15.08
                                                                  from £15.08
                                                                  SOLENOID VALVE/COOLANT OUTLET PIPE UNION Genuine Lamborghini - New (to order)
                                                                  # 006
                                                                  MPN: 008700852
                                                                  WHEAT
                                                                  from £0.54
                                                                  from £0.54
                                                                  SCREW M8X8 UNI 5923 8G/F Genuine Lamborghini - New (to order)
                                                                  # 007
                                                                  MPN: 001120857
                                                                  PIPE UNION
                                                                  from £97.89
                                                                  from £97.89
                                                                  COVER MOUNTING UNION Genuine Lamborghini - New (to order)
                                                                  # 007
                                                                  MPN: 001134281
                                                                  PIPE UNION
                                                                  from £130.71
                                                                  from £130.71
                                                                  RH/LH HEAD COVER CONNECTION Genuine Lamborghini - New (to order)
                                                                  # 008
                                                                  MPN: 008300650
                                                                  PRISONER
                                                                  from £7.71
                                                                  from £7.71
                                                                  SPECIAL STUD M6X51 Genuine Lamborghini - New (to order)
                                                                  # 009
                                                                  MPN: 008410602
                                                                  WASHER
                                                                  from £29.00
                                                                  from £29.00
                                                                  WASHER 12X6.4X0.5 DIN 137/B Genuine Lamborghini - New In stock
                                                                  # 010
                                                                  MPN: 008300613
                                                                  PRISONER
                                                                  from £3.13
                                                                  from £3.13
                                                                  STUD M6X14 UNI 5911 8G/Z Genuine Lamborghini - New (to order)
                                                                  # 011
                                                                  MPN: 008400606
                                                                  WASHER
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 012
                                                                  -
                                                                  STUD
                                                                  NOT FOR THIS MODEL
                                                                  # 012
                                                                  MPN: 001128397
                                                                  STUD
                                                                  from £22.63
                                                                  from £22.63
                                                                  LH/RH UPPER COVER BOLT Genuine Lamborghini - New (to order)
                                                                  # 013
                                                                  -
                                                                  RING
                                                                  NOT FOR THIS MODEL
                                                                  # 013
                                                                  MPN: 008602801
                                                                  RING
                                                                  from £2.44
                                                                  from £2.44
                                                                  RING 28 MM OR Genuine Lamborghini - New In stock
                                                                  # 014
                                                                  MPN: 001128555
                                                                  STOPPER
                                                                  Lamborghini PART 001128555 Genuine Lamborghini - New (to order)
                                                                  # 014
                                                                  MPN: 001136032
                                                                  STOPPER
                                                                  from £8.91
                                                                  from £8.91
                                                                  26X1.5 HOLE PLUG Genuine Lamborghini - New (to order)
                                                                  # 015
                                                                  MPN: 008300651
                                                                  PRISONER
                                                                  from £7.62
                                                                  from £7.62
                                                                  SPECIAL STUD M6X24 Genuine Lamborghini - New (to order)
                                                                  # 016
                                                                  MPN: 008300637
                                                                  PRISONER
                                                                  from £9.15
                                                                  from £9.15
                                                                  SPECIAL STUD M6X28 Genuine Lamborghini - New (to order)
                                                                  # 017
                                                                  MPN: 001120813
                                                                  SEAL
                                                                  from £53.19
                                                                  from £53.19
                                                                  L H UPPER COVER/HEAD GASKET (longer gasket) Genuine Lamborghini - New (to order)
                                                                  # 018
                                                                  MPN: 008606201
                                                                  RING
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 019
                                                                  MPN: 001133383
                                                                  TUBE
                                                                  from £111.45
                                                                  from £111.45
                                                                  OIL VENT COVER ASSEMBLY Genuine Lamborghini - New (to order)
                                                                  # 020
                                                                  MPN: 001114502
                                                                  COVER
                                                                  from £121.25
                                                                  from £121.25
                                                                  HEAD CLOSING COVER Genuine Lamborghini - New (to order)
                                                                  # 021
                                                                  MPN: 008400620
                                                                  WASHER
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 022
                                                                  MPN: 008300601
                                                                  PRISONER
                                                                  from £5.27
                                                                  from £5.27
                                                                  STUD M6X20 UNI 5911/8G/ZD Genuine Lamborghini - New (to order)
                                                                  # 023
                                                                  MPN: 008100807
                                                                  QUICKLY
                                                                  from £0.58
                                                                  from £0.58
                                                                  SCREW M8X40 UNI 5737/8G ZD Genuine Lamborghini - New In stock
                                                                  # 024
                                                                  MPN: 008410806
                                                                  WASHER
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 025
                                                                  MPN: 008400806
                                                                  WASHER
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 027
                                                                  MPN: 008402609
                                                                  WASHER
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 028
                                                                  MPN: 001132417
                                                                  SEAL
                                                                  from £164.30
                                                                  from £164.30
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  LH HEAD GASKET Eurospares Approved Part - New In stock
                                                                  # 029
                                                                  MPN: 008603501
                                                                  RING
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 030
                                                                  MPN: 008604701
                                                                  RING
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 031
                                                                  MPN: 008400802
                                                                  WASHER
                                                                  from £1.06
                                                                  from £1.06
                                                                  COPPER WASHER 8.4X16X1.5 Genuine Lamborghini - New In stock
                                                                  # 032
                                                                  MPN: 008100839
                                                                  QUICKLY
                                                                  Supersession
                                                                  Supersession
                                                                  Genuine Lamborghini (no longer available to order)
                                                                  # 033
                                                                  MPN: 001121254
                                                                  SEAL
                                                                  from £5.36
                                                                  from £5.36
                                                                  FLANGE SEAL Genuine Lamborghini - New In stock
                                                                  # 034
                                                                  MPN: 001734153
                                                                  TUBE
                                                                  from £426.03
                                                                  from £426.03
                                                                  FLYWHEEL SIDE HEAD COOLANT OUT LET UNION Genuine Lamborghini - New (to order)
                                                                  # 035
                                                                  -
                                                                  head
                                                                  SEE ILLUSTRATION: 109.06
                                                                  # 036
                                                                  -
                                                                  head
                                                                  SEE ILLUSTRATION: 109.06
