941.04.00 - Headlights
Lamborghini Diablo VT (1999) HEADLIGHTS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 0063005070
CARBON GUARDS
RIGHT (USA spec vehicles)
from £230.39
from £230.39
# 001
MPN: 0063005071
CARBON GUARDS
LEFT (USA spec vehicles)
from £357.39
from £357.39
# 001
MPN: 0063005072
CARBON GUARDS
RIGHT (EUROPE, UK spec vehicles)
from £559.17
from £559.17
# 001
MPN: 0063005073
CARBON GUARDS
LEFT (EUROPE, UK spec vehicles)
from £832.71
from £832.71
# 002
MPN: 0063002160
headlamp
RIGHT (USA spec vehicles)
from £1,054.26
from £1,054.26
# 002
MPN: 0063002162
headlamp
LEFT (USA spec vehicles)
from £1,054.26
from £1,054.26
# 002
MPN: 0063004644
headlamp
RIGHT (EUROPE spec vehicles)
from £695.01
from £695.01
# 002
MPN: 0063004645
headlamp
LEFT (EUROPE spec vehicles)
from £385.83
from £385.83
# 002
MPN: 0063004650
headlamp
RIGHT (UK spec vehicles)
from £594.29
from £594.29
# 002
MPN: 0063004651
headlamp
LEFT (UK spec vehicles)
from £594.29
from £594.29
# 003
MPN: 006329450
BULB
from £17.74
from £17.74
# 004
MPN: 006334454
CEILING LAMP
from £1,479.32
from £1,479.32
# 005
MPN: 006329698
BULB
from £4.94
from £4.94
# 006
MPN: 006338122
BULB
Supersession
Supersession
# 007
MPN: 006337066
CEILING LAMP
from £10.82
from £10.82
# 008
MPN: 006617092
BULB
Supersession
Supersession
# 009
MPN: 008200503
NUT
(USA spec vehicles)
from £2.20
from £2.20
# 010
MPN: 008400501
WASHER
(USA spec vehicles)
from £0.51
from £0.51
# 011
MPN: 006617092
BULB
(USA spec vehicles)
Supersession
Supersession
# 012
MPN: 006329897
BULB
from £1.74
from £1.74
# 013
MPN: 006329832
TURNING LIGHT
from £14.28
from £14.28
# 014
MPN: 006331781
F. SIDEMAR. (ORANGE)
(USA spec vehicles)
from £21.94
from £21.94
This part replaces part number 006320486 - and 1 more. Click to view details
# 015
MPN: 009444202
ADJ/SCREW
from £7.38
from £7.38
# 016
MPN: 009444152
Frame
from £85.31
from £85.31
# 017
MPN: 009444201
ADJ/SCREW
from £7.05
from £7.05
# 018
MPN: 008200606
NUT
Supersession
Supersession
# 019
MPN: 008400606
WASHER
Supersession
Supersession
# 020
MPN: 006329695
BULB
from £10.59
from £10.59
# 021
MPN: 006329688
FOG LAMP
from £305.29
from £305.29
# 022
MPN: 006329689
FLASH LIGHT
from £293.08
from £293.08
# 023
MPN: 006331779
LEFT FRONT LAMP
LEFT
from £183.73
from £183.73
# 023
MPN: 006331780
RIGHT FRONT LAMP
RIGHT
from £200.43
from £200.43
# 024
MPN: 006617094
BULB
from £5.45
from £5.45
# 025
MPN: 006329696
BULB
from £1.29
from £1.29
# 026
MPN: 008700304
SCREW
from £0.51
from £0.51
# 027
MPN: 001627472
DIM-DIP E.C.U.
from £85.89
from £85.89
# 027
MPN: 001627472
DIM-DIP E.C.U.
NOT FOR THIS MODEL
from £85.89
from £85.89
# 028
MPN: 006132696
SUPPORT
from £21.29
from £21.29
# 028
MPN: 006132696
SUPPORT
NOT FOR THIS MODEL
from £21.29
from £21.29
# 029
MPN: 006329695
BULB
from £10.59
from £10.59
# 030
MPN: 0041003907
BRACKET
from £110.31
from £110.31
# 031
MPN: 0041003904
BRACKET
from £84.94
from £84.94
# 032
MPN: 008700660
SCREW
(EUROPE, UK spec vehicles)
from £0.51
from £0.51
# 032
MPN: 008700663
SCREW
(USA spec vehicles)
from £0.51
from £0.51
# 033
MPN: 008410810
WASHER
Supersession
Supersession
# 034
MPN: 008100830
SCREW
Supersession
Supersession
# 035
MPN: 008400814
WASHER
Supersession
Supersession
# 036
MPN: 0041003905
LH BRACKET
LEFT
from £34.11
from £34.11
# 036
MPN: 0041003906
RH BRACKET
RIGHT
from £34.11
from £34.11
# 037
MPN: 008220606
FASTENING CLIP
