lamborghini gallardo coupe (2008) a/c compressor parts diagram

260.01.00 - A/C COMPRESSOR

Lamborghini Gallardo Coupe (2008) A/C COMPRESSOR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 07L145787
GUARD PLATE
(EUROPE spec vehicles)
from £106.12
from £106.12
HEAT SHIELD CLIMA-COMPRESOR Genuine Lamborghini - New (to order)
HEAT SHIELD CLIMA-COMPRESOR Genuine Lamborghini - Used In stock
# 002
MPN: N10585002
HEXAGON BOLT
M8X110X41 (EUROPE spec vehicles)
from £3.86
from £3.86
HEXAGON HEAD BOLT Genuine Lamborghini - New (to order)
# 003
MPN: 03L260817
CENTRE SLEEVE
11,15X6,5 (EUROPE spec vehicles)
from £1.30
from £1.30
This part replaces part number 07K260817
CENTERING SLEEVE Genuine Lamborghini - New In stock
# 004
MPN: 07L260885H
BRACKET FOR A/C COMPRESSOR
(EUROPE spec vehicles)
from £226.71
from £226.71
SUPP. COMPRESSORE Genuine Lamborghini - New (to order)
# 005
MPN: 07L260095B
INPUT SHAFT
(EUROPE spec vehicles)
from £1,893.75
from £1,893.75
DRIVE SHAFT Genuine Lamborghini - New (to order)
DRIVE SHAFT Genuine Lamborghini - Used In stock
# 006
MPN: N10458902
SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (COMBINATION)
M8X90X41 (EUROPE spec vehicles)
from £2.51
from £2.51
This part replaces part number N10458901
PAN HEAD BOLT WITH Genuine Lamborghini - New (to order)
# 007
MPN: 4E0260805AS
A/C COMPRESSOR
(EUROPE spec vehicles)
from £1,154.91
from £1,154.91
COMPRESSOR Genuine Lamborghini - New (to order)
# 008
MPN: N01152527
WASHER
8,4X16X1,6 (EUROPE spec vehicles)
from £0.54
from £0.54
This part replaces part number N01152520
WASHER 8.4X16X1.6 Genuine Lamborghini - New In stock
# 009
MPN: 079260753B
GROMMET
(EUROPE spec vehicles)
from £8.54
from £8.54
GROMMET 34.00X8.40-11.00 Genuine Lamborghini - New (to order)
# 010
MPN: 400145145
BRACKET FOR CONNECTOR HOUSING
(EUROPE spec vehicles)
from £4.57
from £4.57
BRACKET Genuine Lamborghini - New (to order)
BRACKET Genuine Lamborghini - Used In stock
