301.20.00 - SELECTOR MECHANISM OUTER
Lamborghini LP550-2 Coupe (2013) SELECTOR MECHANISM OUTER Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 086301299
DOWEL SLEEVE
6,4X9X9
from £3.93
from £3.93
# 002
MPN: 01E941521A
SWITCH FOR REVERSING LIGHT
M14X1,5 2 PIN 1J0 973 702
from £38.31
from £38.31
# 003
-
HEXAGON BOLT
# 004
-
HEXAGON BOLT
# 005
MPN: 086311681D
SWITCH UNIT
from £1,033.25
from £1,033.25
This part replaces part number 086311681B
# 018
MPN: 086398211C
REPAIR SET FOR COUPLING ROD
from £201.90
from £201.90
# 019
MPN: 086398211A
REPAIR KIT FOR RELAY LEVER
from £359.69
from £359.69
# 020
MPN: 086398211B
REPAIR KIT FOR GEARSTICK
CANNOT BE SOLD SEPARATELY
from £385.63
from £385.63
