301.08.00 - SWITCH UNIT
Lamborghini Superleggera (2008) SWITCH UNIT Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 000
MPN: 0R1400452
1 SET: PRESSURE PIPES
from £1,448.67
from £1,448.67
# 001
MPN: 086317831
GROMMET
from £672.42
from £672.42
# 003
MPN: 086325059
SELECTOR MECHANISM
from £2,707.74
from £2,707.74
# 004
MPN: 086325083
1 SET ASSEMBLY PARTS
from £403.70
from £403.70
# 005
MPN: 086325085
CLIP
from £29.57
from £29.57
# 006
MPN: 086325087
INTAKE HOSE
from £1,009.47
from £1,009.47
# 007
MPN: 086325089A
CONNECTION PIECE
UNTIL THE VIN 6LA04009
from £2,130.11
from £2,130.11
# 008
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0- 301-080,0
# 009
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0
# 010
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0
# 011
MPN: 086325111
GOVERNOR
from £310.58
from £310.58
# 012
MPN: 086325585
PRESSURE ACCUMULATOR
from £168.47
from £168.47
This part replaces part number 086325141A - and 1 more. Click to view details
# 013
MPN: 086325147
CLIP
# 014
MPN: 086325153
BRACKET
from £260.67
from £260.67
# 015
MPN: 086325161
OIL CONTAINER
from £266.80
from £266.80
# 016
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0
# 017
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0
# 018
-
1 SET OF VACUUM PIPES
CANNOT BE SOLD SEPARATELY - SEE REF.0
# 019
MPN: 086325179
PRESSURE PIPE
from £23.50
from £23.50
# 020
MPN: 086325181C
VALVE BLOCK
from £3,862.80
from £3,862.80
# 021
MPN: 086325273A
CONNECTION PIECE
ORDER ALSO REF.7
from £143.03
from £143.03
# 022
MPN: 086325293
VALVE
EV1/EV2 - PACKING + LIVES-QPV02
from £811.83
from £811.83
# 023
MPN: 086325295
VALVE
EV3/EV4/EV5 - PACKING + LIVES-PPV02
from £806.72
from £806.72
# 024
MPN: 086325297
VALVE
EVF - PACKING + LIVES
from £889.66
from £889.66
# 025
MPN: 086901137
HYDRAULIC PUMP
from £465.40
from £465.40
# 026
MPN: 086907811
POSITION SENSOR
from £538.12
from £538.12
# 027
MPN: 086919331
PRESSURE SENSOR
from £153.57
from £153.57
# 028
MPN: 408326125
BRACKET
from £15.67
from £15.67
# 029
MPN: 408326127
CLAMP
from £115.95
from £115.95
# 030
MPN: 408326129
INLAY
from £17.76
from £17.76
# 031
MPN: 408326131
PROFILE RUBBER
from £16.51
from £16.51
# 032
MPN: 07L115673
PIPE ASSEMBLY
from £798.18
from £798.18
# 033
MPN: 086325831A
CLIP
from £3.52
from £3.52
# 034
MPN: 086325831B
CLIP
# 035
MPN: 408326131A
PROFILE RUBBER
from £16.00
from £16.00
# 036
MPN: 086010530
STICKER FOR OIL LEVEL
from £5.45
from £5.45
# 037
MPN: 400971850B
CABLE TIES
390
from £0.98
from £0.98
# 038
MPN: 086398199A
OIL DRAIN PLUG WITH SEAL
from £53.62
from £53.62
# 039
MPN: 086325191
BRACKET
from £5.53
from £5.53
# 040
MPN: N91065401
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
M8X14
from £1.09
from £1.09
# 041
MPN: 900000170
CENTR. HYDRAULIC OIL
1.0LTR
from £38.49
from £38.49
