lamborghini lp640 roadster (2008) spark plug parts diagram

905.01.00 - SPARK PLUG

Lamborghini LP640 Roadster (2008) SPARK PLUG Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Price
        # 001
        MPN: 410905619
        SPARK PLUG
        from £29.52
        from £29.52
        This part replaces part number 101905602
        # 002
        MPN: 07M905115B
        IGNITION COIL WITH SPARK PLUG CONNECTOR
        from £105.05
        from £105.05
        # 003
        MPN: 07M905377A
        KNOCK SENSOR
        760MM
        from £79.11
        from £79.11
        # 004
        MPN: 07M905377
        KNOCK SENSOR
        430MM
        from £76.35
        from £76.35
        # 005
        MPN: WHT002962
        WASHER
        8,4X14X1,5
        from £0.53
        from £0.53
        This part replaces part number 008400816
        # 006
        MPN: N10518402
        SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
        M8X30
        from £3.85
        from £3.85
        # 007
        MPN: 400971164
        ADAPTER WIRE
        WIRING HARNESS 1-6- 1-6
        from £68.31
        from £68.31
        # 008
        MPN: 400971164
        ADAPTER WIRE
        WIRING HARNESS 7-12- 7-12
        from £68.31
        from £68.31
        # 009
        MPN: 410868630A
        CABLE HOLDER
        from £35.24
        from £35.24
        # 010
        MPN: 07M971087B
        WIRING SET FOR ENGINE
        1-6
        from £726.30
        from £726.30
        # 011
        MPN: 07M971088A
        WIRING SET FOR ENGINE
        7-12
        from £726.30
        from £726.30
        # 012
        MPN: N10648502
        HEXAGON SOCKET HEAD BOLT
        M5X10
        from £0.90
        from £0.90
        This part replaces part number 008700512
        # 013
        MPN: N90247901
        WASHER
        5,3X9X0,6
        from £34.42
        from £34.42
        This part replaces part number 008410503
        # 014
        MPN: 07M905381
        SPEED SENSOR
        480MM
        from £393.41
        from £393.41
        This part replaces part number 001628403
        # 015
        MPN: 07M103899
        FITTED WASHER
        0,2MM
        from £3.34
        from £3.34
        # 015
        MPN: 07M103899A
        FITTED WASHER
        0,4MM
        from £5.31
        from £5.31
        This part replaces part number 001628602
        # 016
        MPN: 07M905387
        PROTECTIVE PIPE
        6,8X400MM
        from £0.62
        from £0.62
