907.01.00 - TYRE PRESSURE CONTROL SYSTEM
Lamborghini Reventon TYRE PRESSURE CONTROL SYSTEM Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 410907273
CONTROL UNIT FOR TYRE PRESSURE CONTROL
from £782.50
from £782.50
# 002
MPN: 8E0907277
aerial
433 MHZ
from £55.40
from £55.40
# 003
MPN: N10653201
HEX COLLARED BOLT
M6X16
from £1.15
from £1.15
# 004
MPN: 4F0907283
SENDER FOR TYRE PRESSURE MONITORING SYSTEM
TPMS SENSOR (USA spec vehicles)
from £63.46
from £63.46
# 005
MPN: 410907731
BRACKET
FRONT
from £26.51
from £26.51
# 006
MPN: 410907732
BRACKET
rear
from £37.84
from £37.84
# 007
MPN: N10653201
HEX COLLARED BOLT
M6X16
from £1.15
from £1.15
# 008
MPN: N01508213
HEXAGON COLLAR NUT
M6
from £0.47
from £0.47
This part replaces part number 008200614 which we have in stock - and 2 more. Click to view details
# 009
MPN: 3W0907323
CLIP
from £4.80
from £4.80
# 010
MPN: N10703301
HEX SOCKET OVAL HEAD COLLARED
M5X35
from £1.25
from £1.25
# 011
MPN: N90991902
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
from £0.55
from £0.55
# 012
MPN: 7PP907275F
TYRE PRESSURE SENSOR
433MHZ
from £54.22
from £54.22
# 013
MPN: 400010502C
STICKER
from £32.34
from £32.34
# 014
MPN: 400601361A
METAL VALVE
REAR-9MM REAR
from £50.17
from £50.17
# 014
MPN: 400601361B
METAL VALVE
FRONT-13MM FRONT
from £46.46
from £46.46
# 015
MPN: N90009504
WASHER
8,4X17X4
from £1.85
from £1.85
