lamborghini revuelto coupe (2024) steering column parts diagram

419.02.00 - Steering Column

Lamborghini Revuelto Coupe (2024) STEERING COLUMN Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 001
            -
            Steering Column
            NO REPLACEMENT PART - INCLUDED IN REF 2
            # 002
            MPN: 4K0419506K
            Steering Column
            from £598.86
            from £598.86
            Steering Column Genuine Lamborghini - New (to order)
            # 003
            MPN: 8B3905861
            STEERING COLUMN LOCK
            from £121.07
            from £121.07
            This part replaces part number 3Q0905861C
            STEERING COLUMN LOCK Genuine Lamborghini - New (to order)
            # 004
            -
            CLIP
            NO REPLACEMENT PART - INCLUDED IN REF 2
            # 005
            MPN: 4M0419378C
            RETAINING LEVER
            from £5.11
            from £5.11
            HANDLE GRIFF MVLS Q7/B9 Genuine Lamborghini - New (to order)
            # 006
            MPN: 47A419753A
            INTERMEDIATE STEERING SHAFT
            from £1,514.15
            from £1,514.15
            INTERMEDIATE STEERING SHAFT Genuine Lamborghini - New (to order)
            # 007
            MPN: 47C419753A
            INTERMEDIATE STEERING SHAFT
            from £2,036.02
            from £2,036.02
            INTERMEDIATE STEERING SHAFT Genuine Lamborghini - New (to order)
            # 008
            MPN: N10017304
            HEXAGON COLLAR NUT
            M5
            from £1.08
            from £1.08
            HEXAGON FLANGE NUT M5 Genuine Lamborghini - New In stock
            shouldered hex. nut Genuine Porsche Part - New (to order)
            # 009
            MPN: N10430103
            HEXAGON SOCKET FLAT HEAD BOLT
            M5X16
            from £0.56
            from £0.56
            HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
            # 010
            MPN: N10739301
            FILLISTER HD. BOLT
            M6X10
            from £0.61
            from £0.61
            OVAL HEAD BOLT Genuine Lamborghini - New (to order)
            FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
            # 011
            MPN: N10765801
            SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD
            M8X30
            from £1.00
            from £1.00
            SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD Genuine Lamborghini - New (to order)
            # 012
            MPN: N10518405
            SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.
            M8X30
            from £1.90
            from £1.90
            TRIPLE SQUARE BOLTM8X30 Genuine Lamborghini - New In stock
            CYLINDER HEAD SCREW WITH TORX Genuine Porsche Part - New (to order)
