lamborghini revuelto coupe (2024) window glasses parts diagram

845.01.00 - WINDOW GLASSES

Lamborghini Revuelto Coupe (2024) WINDOW GLASSES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 001
        MPN: 47B8450990P0
        WINDSCREEN
        WITHOUT PRIMER
        from £3,344.14
        from £3,344.14
        WINDSHIELD GLASS Genuine Lamborghini - New (to order)
        # 002
        MPN: 47B8451150P0
        WITHOUT PRIMER
        WITHOUT PRIMER-LEFT
        from £1,564.53
        from £1,564.53
        SIDE WINDOW Genuine Lamborghini - New (to order)
        # 002
        MPN: 47B8451160P0
        WITHOUT PRIMER
        WITHOUT PRIMER-RIGHT
        from £1,564.53
        from £1,564.53
        SIDE WINDOW Genuine Lamborghini - New (to order)
        # 003
        MPN: 47B845201
        DOOR WINDOW
        LEFT
        from £417.46
        from £417.46
        VETRO PORTA ANT. Genuine Lamborghini - New (to order)
        # 003
        MPN: 47B845202
        DOOR WINDOW
        RIGHT
        from £417.46
        from £417.46
        VETRO PORTA ANT. Genuine Lamborghini - New (to order)
        # 004
        MPN: 47B8452990P0
        WITHOUT PRIMER
        WITHOUT PRIMER-LEFT
        from £2,563.99
        from £2,563.99
        SIDE WINDOW Genuine Lamborghini - New (to order)
        # 004
        MPN: 47B8453000P0
        WITHOUT PRIMER
        WITHOUT PRIMER-RIGHT
        from £2,563.99
        from £2,563.99
        SIDE WINDOW Genuine Lamborghini - New (to order)
        # 005
        MPN: 47B8455010P0
        WITHOUT PRIMER
        WITHOUT PRIMER
        from £3,234.45
        from £3,234.45
        REAR WINDOW GLASS Genuine Lamborghini - New (to order)
        # 006
        -
        INTERIOR MIRROR
        SEE ILLUSTRATION : 857.01
        # 007
        -
        COVER
        SEE ILLUSTRATION : 868.01
        # 008
        -
        COVER
        SEE ILLUSTRATION : 868.01
        # 009
        MPN: 81A955555B
        SENSOR FOR AIR HUMIDITY, RAIN AND LIGHT DETECTION
        from £130.02
        from £130.02
        RAIN SENSOR RLFS SENSOR Genuine Lamborghini - New (to order)
        # 010
        MPN: 47B980281
        TRIM
        from £317.10
        from £317.10
        TRIM Genuine Lamborghini - New (to order)
        # 011
        MPN: 4L0907671
        RETAINING SPRING
        from £3.10
        from £3.10
        RETAINING SPRING Genuine Lamborghini - New (to order)
