002 - CRANK
Maserati GranCabrio MC Centenario Crank Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 272395
CRANKSHAFT IN THE ORDER SPECIFY THE NO. VEHICLE SERIAL NUMBER
Supersession
Supersession
# 002
MPN: 268864
SEMICUSCINETTO SUPERIORE BLU
from £12.66
from £12.66
# 002
MPN: 268865
SEMICUSCINETTO SUPERIORE GIALLO
from £12.17
from £12.17
# 002
MPN: 268866
SEMICUSCINETTO SUPERIORE VERTE - STENDA*
from £11.57
from £11.57
# 003
MPN: 268869
SEMICUSCINETTO INFERIORE BLU
from £11.86
from £11.86
# 003
MPN: 268870
SEMICUSCINETTO INFERIORE GIALLO
from £11.57
from £11.57
# 003
MPN: 268871
SEMICUSCINETTO INFERIORE VERDE - STANDARD
from £11.57
from £11.57
# 004
MPN: 261727
ANELLO DI RASAMENTO
from £5.69
from £5.69
# 005
MPN: 261727
ANELLO DI RASAMENTO
from £5.69
from £5.69
# 006
MPN: 257518
SMORZATORE TORSIONALE
from £373.57
from £373.57
This part replaces part number 225848
# 007
MPN: 192106
ROSETTA
from £3.01
from £3.01
# 008
MPN: 196216
DAMPER FIXING SCREW
from £21.08
from £21.08
This part replaces part number 192005 - and 1 more. Click to view details
SCREW FOR DAMPER FIXING (196216) Genuine Ferrari Part - Used In stock
Removed from 458 engine 199088
Removed from 458 engine 199088
SCREW FAST.TORS.DAMPER TO CRANKSH Genuine Maserati Part - Used In stock
Removed from 4200 engine 81090
Removed from 4200 engine 81090
# 009
MPN: 188717
FRONT CRANKSHAFT SEAL
from £16.03
from £16.03
This part replaces part number 186883
# 010
MPN: 200323
SEAL RING
from £20.59
from £20.59
# 011
MPN: 186201
LINGUETTA
from £0.50
from £0.50
# 012
MPN: 268163
BIELLA E CAPPELLO CPL. WE//' ORDINE SPECIFICARE IL NR. DI MATRICOLA DELIA VETTURA
from £107.74
from £107.74
# 013
MPN: 284372
PISTONE CPL DI SEGMENTI BANCATA DX.
from £224.49
from £224.49
# 013
MPN: 284373
PISTONE CPL DI SEGMENTI BANCATA SX.
from £224.49
from £224.49
# 014
MPN: 206411
SEAL RING 1A THROAT
from £62.88
from £62.88
# 015
MPN: 206412
SEAL RING 2A THROAT
from £62.88
from £62.88
# 016
MPN: 212820
OIL SCRAPER RING 3A THROAT
from £62.88
from £62.88
# 017
MPN: 178890
STOPPING RING
from £3.33
from £3.33
# 018
MPN: 198260
SPINOTTO
from £20.70
from £20.70
# 019
MPN: 224504
BOCCOLA
from £7.08
from £7.08
# 020
MPN: 218371
VITE SERRAGGIO BIELLA
from £20.30
from £20.30
# 021
MPN: 261718
SEMICUSCINETTO BIELLA ROSSO - STANDARD
from £10.03
from £10.03
# 021
MPN: 261719
SEMICUSCINETTO BIELLA BLU
from £10.03
from £10.03
# 021
MPN: 261720
SEMICUSCINETTO BIELLA NERO
from £10.03
from £10.03
# 022
MPN: 243339
CANNA CILINDRI
from £273.66
from £273.66
# 023
MPN: 186251
Guarnizione
from £1.28
from £1.28
# 024
MPN: 236813
PISTONS COOLING NOZZLE
from £4.39
from £4.39
# 025
MPN: 11181474
ROSETTA
from £0.47
from £0.47
# 026
MPN: 14302921
VITE
from £0.51
from £0.51
# 027
MPN: 224608
SPINA CENTRAGGIO
from £1.96
from £1.96
# 029
MPN: 14325540
TAPPO FILETTATO
from £4.28
from £4.28
