046 - Rear Suspension
Maserati GranCabrio MC Centenario Rear Suspension Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 000
MPN: 980139916
RH REAR SUSPENSION KIT
from £845.48
from £845.48
This part replaces part number 900027751
# 000
MPN: 980139918
LH REAR SUSPENSION KIT
from £126.00
from £126.00
This part replaces part number 900027752 - and 1 more. Click to view details
# 000
MPN: 980139921
RH REAR SUSPENSION KIT
from £1,407.52
from £1,407.52
# 000
MPN: 980139923
LH REAR SUSPENSION KIT
from £800.23
from £800.23
# 001
-
RIGHT REAR HUB CARRIER. CPL. CODE NOT AVAILABLE INDIVIDUALLY, ORDER COMPLETE SUSPENSION KIT CODE
# 001
-
PORTAMOZZO POSTERIORE SX. CPL. CODICE NON DISPONIBILE SINGOLARMENTE, ORDINARE CODICE KIT SOSPENSIONE COMPLETA
# 002
-
RIGHT UPPER REAR LEVER. CPL. CODE NOT AVAILABLE INDIVIDUALLY, ORDER COMPLETE SUSPENSION KIT CODE
# 002
-
LEFT REAR UPPER LEVER. CPL. CODE NOT AVAILABLE INDIVIDUALLY, ORDER COMPLETE SUSPENSION KIT CODE
# 003
MPN: 980139890
REAR SUSPENSION BUSH KIT
from £185.32
from £185.32
This part replaces part number 208703 - and 1 more. Click to view details
# 004
MPN: 15541334
VITE
from £3.25
from £3.25
# 005
MPN: 194444
ROSETTA
from £1.90
from £1.90
# 006
MPN: 198043
SPACER THICKNESS MM. 0,50
from £3.25
from £3.25
# 006
MPN: 198044
SPACER THICKNESS MM. 0,75
from £3.17
from £3.17
# 006
MPN: 198045
SPACER THICKNESS MM 1,00
from £3.09
from £3.09
# 006
MPN: 198046
SPACER THICKNESS MM. 1,75
from £2.46
from £2.46
# 006
MPN: 198047
SPACER THICKNESS MM. 3,00
from £2.46
from £2.46
# 007
MPN: 14496721
ROSETTA
from £0.47
from £0.47
# 008
MPN: 102825
NUT
from £0.47
from £0.47
This part replaces part number 15506221
# 009
MPN: 245240
NUT
from £4.14
from £4.14
# 010
-
RIGHT REAR LOWER LEVER. CPL CODE NOT AVAILABLE INDIVIDUALLY, ORDER COMPLETE SUSPENSION KIT CODE
# 010
-
LEVA INFERIORE POSTERIORE SX. CPL. CODIO, NON DISPONIBILE SINGOLARMENTE. ORDINARE CODICE KIT SOSPENSIONE COMPLETA
# 012
MPN: 260766
ECCENTRIC SCREW
from £16.53
from £16.53
# 013
MPN: 194445
ROSETTA
from £2.38
from £2.38
# 014
MPN: 198038
SPACER THICKNESS MM. 0,50
from £3.25
from £3.25
# 014
MPN: 198039
DISTANZIALE SPESSOREMM. 0,75
from £3.17
from £3.17
# 014
MPN: 198040
SPACER THICKNESS MM 1,00
from £3.09
from £3.09
# 014
MPN: 198041
SPACER THICKNESS MM. 1,75
from £2.54
from £2.54
# 014
MPN: 198042
SPACER THICKNESS MM. 3.00
from £3.41
from £3.41
# 015
MPN: 240877
ROSETTA
from £3.97
from £3.97
# 016
MPN: 203795
NUT
from £1.24
from £1.24
This part replaces part number 183417 - and 1 more. Click to view details
# 017
MPN: 245240
NUT
from £4.14
from £4.14
# 017
MPN: 247308
HANDLING NUT USE ONLY FOR PRE-TIGHTENING
from £7.69
from £7.69
# 018
MPN: 276636
COMPLETE TIE ROD FOR CONVERGENCE ADJUSTMENT
from £175.87
from £175.87
This part replaces part number 262362
# 019
MPN: 203657
NUT
from £1.35
from £1.35
# 020
MPN: 12626224
ROSETTA
from £0.54
from £0.54
# 021
MPN: 203657
NUT
from £1.35
from £1.35
# 022
MPN: 12626224
ROSETTA
from £0.54
from £0.54
# 023
MPN: 216711
BARRA STABILIZZATRICE POSTERIORE 0=21
from £91.66
from £91.66
# 023
MPN: 244020
BARRA STABILIZZATRICE POSTERIORE 0=20
from £149.52
from £149.52
# 024
MPN: 216731
TAMPONE PER BARRA D=21
from £9.31
from £9.31
# 024
MPN: 244021
TAMPONE PER BARRA D=20
from £10.65
from £10.65
# 025
MPN: 191221
BUFFER HOLDING PLATE
from £25.69
from £25.69
# 026
MPN: 104030
NUT
from £0.47
from £0.47
# 027
MPN: 14496524
ROSETTA D. 8.40-17 X1.6
from £0.47
from £0.47
# 028
MPN: 259572
TIRANTE SFERICO LATO SX
from £52.98
from £52.98
This part replaces part number 162619
# 028
MPN: 259573
RIGHT SIDE SPHERICAL TIE ROD.
from £48.67
from £48.67
This part replaces part number 162620 which we have in stock
# 029
MPN: 102742
NUT
from £0.47
from £0.47
# 030
MPN: 12601474
ROSETTA D.10,50-21X 1,0
from £0.54
from £0.54
# 031
MPN: 228958
HEADLIGHT ALIGNMENT POTENTIOMETER TIE ROD
from £35.64
from £35.64
# 032
MPN: 102741
NUT
from £0.47
from £0.47
This part replaces part number 12575421
# 033
MPN: 14498824
ROSETTA D.6.4-16.3X1
from £0.47
from £0.47
# 034
MPN: 205608
VITE
from £40.76
from £40.76
# 035
MPN: 204008
PRIGIONIERO
from £36.80
from £36.80
# 036
MPN: 240877
ROSETTA
from £3.97
from £3.97
# 037
MPN: 203795
NUT
from £1.31
from £1.31
This part replaces part number 183417 - and 1 more. Click to view details
# 038
MPN: 204010
Dado cieco
from £4.20
from £4.20
# 039
MPN: 386600416
JOINT PROTECTION
from £3.74
from £3.74
# 040
MPN: 386600416
JOINT PROTECTION
from £3.74
from £3.74
# 041
MPN: 222203
DISTANZIALE
from £13.80
from £13.80
# 042
MPN: 150738
MOLLETTA
from £0.47
from £0.47
# 043
MPN: 231274
STAFFA
from £6.98
from £6.98
# 044
MPN: 206881
AIR DIVERTER LEFT REAR LOWER LEVER.
from £17.13
from £17.13
# 044
MPN: 206882
AIR DIVERTER LOWER RIGHT LEVER.
from £17.13
from £17.13
# 045
MPN: 14064414
VITE
from £1.35
from £1.35
# 046
MPN: 14498804
ROSETTA D. 6,40-16.3 X1
from £0.71
from £0.71
# 047
MPN: 15896211
NUT
Supersession
Supersession
