porsche 1982 (928) gears and shafts - 2 - automatic transmission parts diagram

309-005 - GEARS AND SHAFTS - 2 - AUTOMATIC TRANSMISSION

Porsche 1982 (928) GEARS AND SHAFTS - 2 - AUTOMATIC TRANSMISSION Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                  #
                                                                  Part number
                                                                  Description
                                                                  Key
                                                                  Price
                                                                  # 1
                                                                  MPN: 1152720473
                                                                  LOCK RING
                                                                  from £2.67
                                                                  from £2.67
                                                                  LOCK RING Genuine Porsche Part - New (to order)
                                                                  # 2
                                                                  MPN: 0029813110
                                                                  NEEDLE BEARING -
                                                                  from £2.99
                                                                  from £2.99
                                                                  NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                                  # 3
                                                                  MPN: 1162702020
                                                                  FLANGE
                                                                  FLANGE Genuine Porsche Part - New (to order)
                                                                  # 4
                                                                  MPN: 1092720492
                                                                  CUP
                                                                  from £52.53
                                                                  from £52.53
                                                                  CUP Genuine Porsche Part - New (to order)
                                                                  # 5
                                                                  MPN: 1152721692
                                                                  CUP
                                                                  from £8.87
                                                                  from £8.87
                                                                  CUP Genuine Porsche Part - New (to order)
                                                                  # 6
                                                                  MPN: 1162720231
                                                                  PISTON
                                                                  from £24.79
                                                                  from £24.79
                                                                  PISTON Genuine Porsche Part - New (to order)
                                                                  # 7
                                                                  MPN: 1099940035
                                                                  CIRCLIP
                                                                  from £1.10
                                                                  from £1.10
                                                                  CIRCLIP Genuine Porsche Part - New (to order)
                                                                  # 8
                                                                  MPN: 1002700031
                                                                  FREEWHEEL
                                                                  FREEWHEEL Genuine Porsche Part - New (to order)
                                                                  # 9
                                                                  MPN: 1092722226
                                                                  EXTERNAL DISC
                                                                  external disc - 4,5 MM Genuine Porsche Part - New (to order)
                                                                  # 9
                                                                  MPN: 1092722326
                                                                  EXTERNAL DISC
                                                                  from £22.64
                                                                  from £22.64
                                                                  external disc - 5,0 MM Genuine Porsche Part - New (to order)
                                                                  # 10
                                                                  MPN: 1152720025
                                                                  driving disc - 2,0 MM
                                                                  from £20.69
                                                                  from £20.69
                                                                  driving disc - 2,0 MM Genuine Porsche Part - New (to order)
                                                                  # 11
                                                                  MPN: 1092720626
                                                                  EXTERNAL DISC
                                                                  external disc - 3,0 MM Genuine Porsche Part - New (to order)
                                                                  # 11
                                                                  MPN: 1092720826
                                                                  EXTERNAL DISC
                                                                  from £42.68
                                                                  from £42.68
                                                                  external disc - 3,5 MM Genuine Porsche Part - New (to order)
                                                                  # 11
                                                                  MPN: 1092721526
                                                                  EXTERNAL DISC
                                                                  external disc - 2,0 MM Genuine Porsche Part - New (to order)
                                                                  # 12
                                                                  MPN: 1002724124
                                                                  DISC CARRIER
                                                                  from £394.37
                                                                  from £394.37
                                                                  DISC CARRIER Genuine Porsche Part - New (to order)
                                                                  # 13
                                                                  MPN: 1092720367
                                                                  SPRING SEAT
                                                                  SPRING SEAT Genuine Porsche Part - New (to order)
                                                                  # 14
                                                                  MPN: 1009938801
                                                                  SPRING
                                                                  from £0.87
                                                                  from £0.87
                                                                  SPRING Genuine Porsche Part - New (to order)
                                                                  # 16
                                                                  MPN: 1152721373
                                                                  LOCK RING
                                                                  LOCK RING Genuine Porsche Part - New (to order)
                                                                  # 17
                                                                  MPN: 1002721252
                                                                  SPACER WASHER
                                                                  from £7.90
                                                                  from £7.90
                                                                  SPACER WASHER - 0,1 MM Genuine Porsche Part - New (to order)
                                                                  # 17
                                                                  MPN: 1002721352
                                                                  SPACER WASHER
                                                                  from £1.47
                                                                  from £1.47
                                                                  SPACER WASHER - 0,2 MM Genuine Porsche Part - New (to order)
                                                                  # 17
                                                                  MPN: 1002721452
                                                                  SPACER WASHER
                                                                  from £2.61
                                                                  from £2.61
                                                                  SPACER WASHER - 0,5 MM Genuine Porsche Part - New (to order)
                                                                  # 18
                                                                  MPN: N 0123821
                                                                  OUTER RING - 40 X 1,75
                                                                  OUTER RING - 40 X 1,75 Genuine Porsche Part - New (to order)
                                                                  # 19
                                                                  MPN: 1002723920
                                                                  SHAFT
                                                                  SHAFT Genuine Porsche Part - New (to order)
                                                                  # 20
                                                                  MPN: 0029813210
                                                                  NEEDLE BEARING -
                                                                  from £7.52
                                                                  from £7.52
                                                                  NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                                  # 21
                                                                  MPN: 1152723462
                                                                  THRUST WASHER
                                                                  from £5.67
                                                                  from £5.67
                                                                  THRUST WASHER Genuine Porsche Part - New (to order)
                                                                  # 22
                                                                  MPN: 1129940735
                                                                  CIRCLIP
                                                                  from £0.71
                                                                  from £0.71
                                                                  circlip - 125 MM Genuine Porsche Part - New (to order)
                                                                  # 23
                                                                  MPN: 1162701325
                                                                  DRIVE SHAFT
                                                                  from £329.18
                                                                  from £329.18
                                                                  DRIVE SHAFT Genuine Porsche Part - New (to order)
                                                                  # 24
                                                                  MPN: 7222720062
                                                                  THRUST WASHER
                                                                  (A2201,A2202)
                                                                  THRUST WASHER Genuine Porsche Part - New (to order)
                                                                  # 24
                                                                  MPN: 7222720162
                                                                  THRUST WASHER
                                                                  (A2204)
                                                                  THRUST WASHER Genuine Porsche Part - New (to order)
                                                                  # 25
                                                                  MPN: 0029813010
                                                                  NEEDLE BEARING -
                                                                  from £3.14
                                                                  from £3.14
                                                                  NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                                  # 26
                                                                  MPN: 1152720273
                                                                  CIRCLIP
                                                                  from £7.03
                                                                  from £7.03
                                                                  circlip - 130 MM Genuine Porsche Part - New (to order)
                                                                  # 27
                                                                  MPN: 7222700343
                                                                  planet pinion carrier - A >> 005 005797
                                                                  (A2201,A2202)
                                                                  PLANET PINION CARRIER - A >>005 005797 Genuine Porsche Part - New (to order)
                                                                  # 27
                                                                  MPN: 7222701143
                                                                  planet pinion carrier - A 005 005798 >>
                                                                  (A2201)
                                                                  from £684.28
                                                                  from £684.28
                                                                  planet pinion carrier - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 27
                                                                  MPN: 7222701143
                                                                  PLANET PINION CARRIER
                                                                  (A2204)
                                                                  from £684.28
                                                                  from £684.28
                                                                  planet pinion carrier - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 28
                                                                  MPN: 0079813910
                                                                  NEEDLE BEARING - - DISCONTINUED PART
                                                                  (A2201,A2202)
                                                                  from £16.26
                                                                  from £16.26
                                                                  NEEDLE BEARING - - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                  # 28
                                                                  MPN: 0079813910
                                                                  NEEDLE BEARING -
                                                                  (A2204)
                                                                  from £16.26
                                                                  from £16.26
                                                                  NEEDLE BEARING - - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                  # 29
                                                                  MPN: 0049814010
                                                                  NEEDLE BEARING -
                                                                  from £2.42
                                                                  from £2.42
                                                                  NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                                  # 30
                                                                  MPN: 1152723762
                                                                  THRUST WASHER
                                                                  from £1.65
                                                                  from £1.65
                                                                  THRUST WASHER Genuine Porsche Part - New (to order)
                                                                  # 31
                                                                  MPN: 0019811825
                                                                  BALL BEARING
                                                                  BALL BEARING Genuine Porsche Part - New (to order)
                                                                  # 32
                                                                  MPN: 7222720017
                                                                  GEAR
                                                                  GEAR Genuine Porsche Part - New (to order)
                                                                  # 33
                                                                  MPN: 7222700074
                                                                  CENTRIFUGAL GOVERNOR
                                                                  (A2201,A2202)
                                                                  CENTRIFUGAL GOVERNOR Genuine Porsche Part - New (to order)
                                                                  # 33
                                                                  MPN: 7222700074X
                                                                  CENTRIFUGAL GOVERNOR
                                                                  (A2201,A2202)
                                                                  Porsche PART 7222700074X Genuine Porsche Part - New (to order)
                                                                  # 33
                                                                  MPN: 7222700274
                                                                  GOVERNOR
                                                                  (A2204)
                                                                  from £95.33
                                                                  from £95.33
                                                                  GOVERNOR Genuine Porsche Part - New (to order)
                                                                  # 34
                                                                  MPN: 1152700098
                                                                  STRAINER
                                                                  from £2.80
                                                                  from £2.80
                                                                  STRAINER Genuine Porsche Part - New (to order)
                                                                  # 35
                                                                  MPN: 1152721355
                                                                  SEAL RING
                                                                  from £29.84
                                                                  from £29.84
                                                                  SEAL RING Genuine Porsche Part - New (to order)
                                                                  # 36
                                                                  MPN: 92232130107
                                                                  SEAL RING
                                                                  from £62.59
                                                                  from £62.59
                                                                  SEAL RING Genuine Porsche Part - New (to order)
                                                                  # 37
                                                                  MPN: 92230240302
                                                                  spacer ring - A >> 005 005797
                                                                  (A2201,A2202)
                                                                  from £8.10
                                                                  from £8.10
                                                                  SPACER RING - A >>005 005797 Genuine Porsche Part - New (to order)
                                                                  # 37
                                                                  MPN: 92230240400
                                                                  spacer ring - A 005 005798 >>
                                                                  (A2201)
                                                                  from £31.62
                                                                  from £31.62
                                                                  spacer ring - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 37
                                                                  MPN: 92230240400
                                                                  SPACER RING
                                                                  (A2204)
                                                                  from £31.62
                                                                  from £31.62
                                                                  spacer ring - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 38
                                                                  MPN: 92230240100
                                                                  O-ring - A >> 005 005797
                                                                  (A2201,A2202)
                                                                  from £1.83
                                                                  from £1.83
                                                                  O-ring - A >> 005 005797 Genuine Porsche Part - New (to order)
                                                                  # 38
                                                                  MPN: 92230240201
                                                                  O-Ring - A 005 005798 >>
                                                                  (A2201)
                                                                  from £2.27
                                                                  from £2.27
                                                                  O-Ring - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 38
                                                                  MPN: 92230240201
                                                                  O-RING
                                                                  (A2204)
                                                                  from £2.27
                                                                  from £2.27
                                                                  O-Ring - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 39
                                                                  MPN: 7229940035
                                                                  circlip - A 005 005798 >>
                                                                  (A2201)
                                                                  from £2.24
                                                                  from £2.24
                                                                  circlip - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 39
                                                                  MPN: 7229940035
                                                                  CIRCLIP
                                                                  (A2204)
                                                                  from £2.24
                                                                  from £2.24
                                                                  circlip - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 40
                                                                  MPN: 7229930026
                                                                  concave washer - A 005 005798 >>
                                                                  (A2201)
                                                                  from £4.14
                                                                  from £4.14
                                                                  concave washer - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 40
                                                                  MPN: 7229930026
                                                                  CONCAVE WASHER
                                                                  (A2204)
                                                                  from £4.14
                                                                  from £4.14
                                                                  concave washer - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 41
                                                                  MPN: 90023408201
                                                                  fitt washer - A 005 005798 >>
                                                                  (A2201)
                                                                  from £2.18
                                                                  from £2.18
                                                                  fitt washer - A 005 005798 >> Genuine Porsche Part - New (to order)
                                                                  # 41
                                                                  MPN: 90023408201
                                                                  FITT WASHER
                                                                  (A2204)
                                                                  from £2.18
                                                                  from £2.18
                                                                  fitt washer - A 005 005798 >> Genuine Porsche Part - New (to order)
