porsche 1984 (928) camshaft - 2 - valve parts diagram

103-005 - CAMSHAFT - 2 - VALVE

Porsche 1984 (928) CAMSHAFT - 2 - VALVE Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                            #
                                            Part number
                                            Description
                                            Key
                                            Price
                                            # 2
                                            MPN: 92810518703
                                            camshaft - D - MJ 1983>> - MJ 1983
                                            cylinders 1-4 (2811,2812)
                                            from £630.13
                                            from £630.13
                                            camshaft - D - MJ 1983>> - MJ 1983 Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 92810521100
                                            camshaft - D - MJ 1984>>
                                            cylinders 1-4 (2821,2822)
                                            from £761.83
                                            from £761.83
                                            camshaft - D - MJ 1984>> Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 92810520300
                                            camshaft - D >> - MJ 1984
                                            cylinders 1-4 (2819,2820)
                                            from £114.98
                                            from £114.98
                                            camshaft - D >> - MJ 1984 Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 92810518803
                                            camshaft - Cylinders 5 - 8 - D - MJ 1983>> - MJ 1983
                                            (2811,2812)
                                            from £787.18
                                            from £787.18
                                            CAMSHAFT - CYLINDERS 5 - 8 - D - MJ 1983>>- MJ 1983 Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 92810521200
                                            camshaft - D - MJ 1984>>
                                            cylinders 5-8 (2821,2822)
                                            camshaft - D - MJ 1984>> Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 92810520400
                                            camshaft - D >> - MJ 1984
                                            cylinders 5-8 (2819,2820)
                                            from £591.96
                                            from £591.96
                                            camshaft - D >> - MJ 1984 Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 92810531106
                                            HYDRAULIC TAPPET - DISCONTINUED PART
                                            HYDRAULIC TAPPET - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 92810531108
                                            HYDRAULIC TAPPET
                                            from £207.51
                                            from £207.51
                                            HYDRAULIC TAPPET Genuine Porsche Part - New (to order)
                                            # 5
                                            MPN: 92810515303
                                            COVER
                                            from £71.14
                                            from £71.14
                                            COVER Genuine Porsche Part - New (to order)
                                            # 6
                                            MPN: 92810518902
                                            GASKET
                                            from £4.01
                                            from £4.01
                                            GASKET Genuine Porsche Part - New (to order)
                                            # 7
                                            MPN: N 0115247
                                            WASHER - A 6,4 - DISCONTINUED PART
                                            Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                            # 7
                                            MPN: N 01152427
                                            Washer - A 6,4
                                            from £0.47
                                            from £0.47
                                            Washer - R 6,6 Genuine Porsche Part - New In stock
                                            WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                            # 8
                                            MPN: 90007501602
                                            SCREW, HEX. HD. - M 6 X 22 - DISCONTINUED PART
                                            SCREW, HEX. HD. - M 6 X 22 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 8
                                            MPN: 90007501603
                                            SCREW, HEX. HD. - M 6 X 22
                                            from £0.86
                                            from £0.86
                                            SCREW, HEX. HD. - M 6 X 22 Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 90007534102
                                            Bolt with washer - M 6 X 25 Z1 - Discontinued part
                                            Bolt with washer - M6 X 25 - Discontinued part Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 90007534101
                                            Bolt with washer - M 6 X 25 Z1
                                            from £0.78
                                            from £0.78
                                            Bolt with washer - M6 X 25 Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 99970160240
                                            O-RING - 50 X 5
                                            from £8.40
                                            from £8.40
                                            O-Ring - 50 X 5 - See technical information - GRP.1 NR.5 Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: 92810518400
                                            SEAL RING - DISCONTINUED PART
                                            SEAL RING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: 92810518401
                                            SEAL RING
                                            from £2.56
                                            from £2.56
                                            SEAL RING Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 92810513604
                                            FLANGE MOUNTING
                                            LEFT
                                            from £99.41
                                            from £99.41
                                            FLANGE MOUNTING Genuine Porsche Part - New (to order)
                                            # 13
                                            MPN: 92810511904
                                            CAMSHAFT BEARING
                                            RIGHT
                                            from £49.14
                                            from £49.14
                                            CAMSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 14
                                            MPN: 90011705000
                                            FEATHER SPRING
                                            from £1.60
                                            from £1.60
                                            feather spring - D - MJ 1980>> Genuine Porsche Part - New (to order)
                                            # 15
                                            MPN: 92810513101
                                            SPACER BUSHING
                                            LEFT
                                            SPACER BUSHING Genuine Porsche Part - New (to order)
                                            # 16
                                            MPN: 92810513902
                                            spacer bushing - M >> 82G 00071 - M >> 82G 05066
                                            right (2821,2822)
                                            from £35.29
                                            from £35.29
                                            SPACER BUSHING - M >>82G 00071 - M >>82G 05066 Genuine Porsche Part - New (to order)
                                            # 16
                                            MPN: 92810513904
                                            spacer bushing - M 82G 00072 >> - M 82G 05067 >> - Discontinued part
                                            right (2821,2822)
                                            SPACER BUSHING - M 82G 00072 >>- M 82G 05067 >>- DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 16
                                            MPN: 92810513905
                                            spacer bushing - M 82G 00072 >> - M 82G 05067 >>
                                            right (2821,2822)
                                            from £69.17
                                            from £69.17
                                            SPACER BUSHING - M 82G 00072 >>- M 82G 05067 >> Genuine Porsche Part - New (to order)
                                            # 17
                                            MPN: 92810554302
                                            DRIVE GEAR
                                            from £30.76
                                            from £30.76
                                            DRIVE GEAR Genuine Porsche Part - New (to order)
                                            # 18
                                            MPN: 99970159240
                                            O-RING - 23 X 2
                                            from £2.34
                                            from £2.34
                                            O-RING - 23 X 2 Genuine Porsche Part - New (to order)
                                            # 19
                                            MPN: 92810514302
                                            SPACER TUBE
                                            from £23.89
                                            from £23.89
                                            SPACER TUBE Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: 99911328240
                                            seal - M >> 82G 00071 - M >> 82G 05066
                                            (2821,2822)
                                            from £19.62
                                            from £19.62
                                            seal - M >> 82G 00071 - M >> 82G 05066 Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: 99911334940
                                            seal - M 82G 00072 >> - M 82G 05067 >>
                                            (2821,2822)
                                            from £19.73
                                            from £19.73
                                            seal - M 82G 00072 >> - M 82G 05067 >> Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 92810554510
                                            CAMSHAFT SPROCKET - DISCONTINUED PART
                                            CAMSHAFT SPROCKET - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 92810554514
                                            CAMSHAFT SPROCKET
                                            from £237.32
                                            from £237.32
                                            CAMSHAFT SPROCKET Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 92810556500
                                            WASHER
                                            from £4.33
                                            from £4.33
                                            WASHER Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: N 0104707
                                            SCREW, HEX. HD. - M 10 X 70 - DISCONTINUED PART
                                            SCREW, HEX. HD. - M 10 X 70 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: N 0104701
                                            SCREW, HEX. HD. - M 10 X 70
                                            from £3.43
                                            from £3.43
                                            SCREW, HEX. HD. - M 10 X 70 Genuine Porsche Part - New (to order)
                                            # 24
                                            MPN: 90007422408
                                            SCREW, HEX. HD. - M 10 X 95
                                            from £7.73
                                            from £7.73
                                            SCREW, HEX. HD. - M 10 X 95 Genuine Porsche Part - New (to order)
                                            # 25
                                            MPN: 92810519912
                                            gasket - Discontinued part
                                            gasket - Discontinued part Genuine Porsche Part - New (to order)
                                            # 25
                                            MPN: 92810519913
                                            gasket - (asbestos free)
                                            gasket - (asbestos free) Genuine Porsche Part - New (to order)
                                            # 26
                                            MPN: 90006721402
                                            SCREW, CHEESE HD. - BM 8 X 35 - DISCONTINUED PART
                                            SCREW, CHEESE HD. - M 8 X 35 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 26
                                            MPN: 90006721401
                                            SCREW, CHEESE HD. - BM 8 X 35
                                            from £2.77
                                            from £2.77
                                            SCREW, CHEESE HD. - M 8 X 35 Genuine Porsche Part - New (to order)
                                            # 27
                                            MPN: 90021900930
                                            THREADED PLUG - M 18 X 1,5
                                            from £7.97
                                            from £7.97
                                            threaded plug - M 18 X 1,5 - D - MJ 1980>> Genuine Porsche Part - New (to order)
                                            # 28
                                            MPN: 90012314030
                                            SEAL RING - A 18 X 22
                                            from £1.28
                                            from £1.28
                                            SEAL RING - A 8 X 22 Genuine Porsche Part - New In stock
