porsche 1989 (928) starter - battery parts diagram

902-000 - STARTER - BATTERY

Porsche 1989 (928) STARTER - BATTERY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 92860410304
                STARTER
                STARTER - 1,5 KW Genuine Porsche Part - New (to order)
                # 1
                MPN: 928604103DX
                STARTER - 1,5 KW - DISCONTINUED PART
                STARTER Genuine Porsche Part - New (to order)
                # 1
                MPN: 928604103EX
                STARTER - 1,5 KW
                from £569.63
                from £569.63
                STARTER Genuine Porsche Part - New (to order)
                # 2
                MPN: 90006712402
                SCREW, CHEESE HD. - M 10 X 35
                from £1.40
                from £1.40
                screw, cheese hd. - M 10X35 Genuine Porsche Part - New (to order)
                # 3
                MPN: 90002701602
                LOCK RING - B 10 - DISCONTINUED PART
                LOCK RING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                # 3
                MPN: 90002701603
                LOCK RING - B 10
                from £0.65
                from £0.65
                LOCK RING - B 12 Genuine Porsche Part - New (to order)
                # 5
                MPN: 90007602502
                HEX. NUT - M 8 - DISCONTINUED PART
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 5
                MPN: 90007606402
                hex. nut - M 8
                from £0.59
                from £0.59
                hex. nut - SW 13 M 8 Genuine Porsche Part - New (to order)
                # 6
                MPN: 92861110501
                BATTERY - 12V - 72 AH - DISCONTINUED PART
                BATTERY - 12V - 72 AH - DISCONTINUED PART Genuine Porsche Part - New (to order)
                # 6
                MPN: 92861117302
                battery - 12V - 72AH
                battery - 12V - 72AH Genuine Porsche Part - New (to order)
                # 6
                MPN: 92861117503
                battery - 12V - 75AH
                battery - 12V - 75AH Genuine Porsche Part - New (to order)
                # 6
                MPN: 99961105320
                BATTERY - 12V - 50 AH - D - MJ 1988>>
                (PR:637)
                from £160.61
                from £160.61
                battery - 50 AH - D >> - MJ 2002 Genuine Porsche Part - New (to order)
                # 7
                -
                SEE GROUP - 9/02/12
                # 8
                -
                SEE GROUP - 9/02/12
                # -
                -
                Pole covering - battery - D >> - MJ 1989
                # -
                -
                Pole covering - battery - D - MJ 1990>>
                # -
                -
                FASTENERS - BATTERY
                # -
                -
                BRACKET
                # -
                -
                SCREW, CHEESE HD. - M 8 X 25
                # -
                -
                SCREW, CHEESE HD. - M 8 X 25
                # -
                -
                WASHER
                # -
                -
                bracket - D - MJ 1988>>
                (PR:637)
                # -
                -
                screw, cheese hd. - M 8 X 25 - D - MJ 1988>> - Discontinued part
                (PR:637)
                # -
                -
                screw, cheese hd. - M 8 X 25 - D - MJ 1988>>
                (PR:637)
                # -
                -
                Washer - D - MJ 1988>>
                (PR:637)
