porsche 1990 (928) throttle control parts diagram

702-005 - throttle control

Porsche 1990 (928) THROTTLE CONTROL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                        #
                                        Part number
                                        Description
                                        Key
                                        Price
                                        # 1
                                        MPN: 91142311102
                                        ACCELERATOR PEDAL - DISCONTINUED PART
                                        ACCELERATOR PEDAL - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                        # 1
                                        MPN: 91142311103
                                        Accelerator Pedal
                                        from £28.27
                                        from £28.27
                                        accelerator pedal - D - MJ 1976>> Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 90016901402
                                        SECURING CLIP - DISCONTINUED PART
                                        securing clip - S 8 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 90016901401
                                        SECURING CLIP
                                        from £3.69
                                        from £3.69
                                        securing clip - S 8 Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: 99907200509
                                        HEX. NUT - M 6 X 12 - DISCONTINUED PART
                                        hex. nut - M6X12 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: 99907200501
                                        SCREW, HEX. HD. - M 6 X 12
                                        from £2.58
                                        from £2.58
                                        screw, hex. hd. - M6X12 Genuine Porsche Part - New In stock
                                        # 5
                                        MPN: 92842311900
                                        PUSH ROD
                                        from £27.84
                                        from £27.84
                                        PUSH ROD Genuine Porsche Part - New (to order)
                                        # 6
                                        MPN: 91142314700
                                        BALL SOCKET
                                        Supersession
                                        Supersession
                                        Genuine Porsche Part (no longer available to order)
                                        # 9
                                        MPN: 92842302103
                                        BRACKET
                                        from £39.32
                                        from £39.32
                                        bracket - F 92-88100 657>> Genuine Porsche Part - New (to order)
                                        # -
                                        -
                                        NUT - M 6 - DISCONTINUED PART
                                        # -
                                        -
                                        NUT - M 6
                                        # -
                                        -
                                        SPRING WASHER - B 6
                                        # 11
                                        MPN: 92842325005
                                        RELAY LEVER
                                        from £50.76
                                        from £50.76
                                        relay lever - F 92-88100 657>> Genuine Porsche Part - New (to order)
                                        # 12
                                        MPN: 99916603402
                                        RETAINER PLATE
                                        from £3.54
                                        from £3.54
                                        retainer plate - D - MJ 1989>> - MJ 1989 Genuine Porsche Part - New (to order)
                                        # 13
                                        MPN: 92842302308
                                        ACCELERATOR CABLE
                                        from £66.38
                                        from £66.38
                                        ACCELERATOR CABLE Genuine Porsche Part - New (to order)
                                        # 14
                                        MPN: 91142314700
                                        BALL SOCKET
                                        Supersession
                                        Supersession
                                        Genuine Porsche Part (no longer available to order)
                                        # 15
                                        MPN: 99916604602
                                        FUSE
                                        FUSE Genuine Porsche Part - New (to order)
                                        # 16
                                        MPN: N 01100514
                                        HEX. NUT - BM 5 - DISCONTINUED PART
                                        hex. nut - M 5 - See technical information - GR. X NR. 15 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 16
                                        MPN: 90007609101
                                        HEX. NUT - BM 5
                                        from £1.00
                                        from £1.00
                                        hex. nut - M 5 - See technical information - GR. X NR. 15 Genuine Porsche Part - New In stock
                                        # 17
                                        MPN: 99992400240
                                        BUSHING
                                        from £2.44
                                        from £2.44
                                        bushing - D >> - MJ 1981 Genuine Porsche Part - New (to order)
                                        # 18
                                        MPN: 90023404101
                                        FITT WASHER - 10 X 16 X 1,3
                                        from £1.04
                                        from £1.04
                                        fitt washer - 10 X 16 X 1,3 - lock washer - 8 Genuine Porsche Part - New (to order)
                                        # 19
                                        MPN: 92842304106
                                        BOWDEN CABLE - FOR - CONTROL PRESSURE
                                        (PR:249)
                                        from £200.93
                                        from £200.93
                                        BOWDEN CABLE - FOR - CONTROL PRESSURE Genuine Porsche Part - New (to order)
                                        # 20
                                        MPN: 99970196040
                                        SEAL RING
                                        from £7.20
                                        from £7.20
                                        SEAL RING Genuine Porsche Part - New (to order)
                                        # 21
                                        MPN: 92842314100
                                        BRACKET
                                        (PR:249)
                                        from £4.21
                                        from £4.21
                                        BRACKET Genuine Porsche Part - New (to order)
                                        # 22
                                        MPN: 99951235502
                                        HOSE CLAMP - DISCONTINUED PART
                                        (PR:249)
                                        HOSE CLAMP - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                        # 22
                                        MPN: 99951235501
                                        HOSE CLAMP
                                        (PR:249)
                                        from £2.41
                                        from £2.41
                                        HOSE CLAMP Genuine Porsche Part - New (to order)
                                        # 23
                                        MPN: 92842314300
                                        BRACKET
                                        (PR:249)
                                        from £2.34
                                        from £2.34
                                        BRACKET Genuine Porsche Part - New (to order)
                                        # 24
                                        MPN: 99970211950
                                        RUBBER GROMMET
                                        (PR:249)
                                        from £3.60
                                        from £3.60
                                        Rubber grommet - for - 901.612.053.00 Genuine Porsche Part - New (to order)
                                        # 25
                                        MPN: N 0102107
                                        SCREW, HEX. HD. - M 6 X 10
                                        SCREW, HEX. HD. - M 6 X 12 Genuine Porsche Part - New (to order)
                                        # 26
                                        MPN: N 0115247
                                        WASHER - A 6,4 - DISCONTINUED PART
                                        Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                        # 26
                                        MPN: N 01152427
                                        Washer - A 6,4
                                        from £0.47
                                        from £0.47
                                        Washer - R 6,6 Genuine Porsche Part - New In stock
                                        WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                        # 27
                                        MPN: 92842327700
                                        SEALING SLEEVE
                                        (PR:249)
                                        from £7.73
                                        from £7.73
                                        SEALING SLEEVE Genuine Porsche Part - New (to order)
                                        # 28
                                        MPN: 92860611100
                                        KICKDOWN SWITCH
                                        (PR:249)
                                        from £49.29
                                        from £49.29
                                        KICKDOWN SWITCH Genuine Porsche Part - New (to order)
                                        # 29
                                        MPN: 92861341900
                                        SPRING WASHER
                                        (PR:249)
                                        from £1.17
                                        from £1.17
                                        SPRING WASHER Genuine Porsche Part - New (to order)
                                        # 30
                                        MPN: 92861342100
                                        SLOTTED NUT - M 28 X 1,5
                                        (PR:249)
                                        from £17.81
                                        from £17.81
                                        SLOTTED NUT - M 28 X 1,5 Genuine Porsche Part - New (to order)
                                        # 31
                                        MPN: 92842390102
                                        BOWDEN CABLE
                                        (PR:249)
                                        BOWDEN CABLE Genuine Porsche Part - New (to order)
                                        # 32
                                        MPN: 477723601
                                        NIPPLE
                                        (PR:249)
                                        from £54.74
                                        from £54.74
                                        NIPPLE Genuine Porsche Part - New (to order)
                                        # -
                                        -
                                        VERTICAL PEDAL ADJUSTMENT - 15 MM
                                        # -
                                        -
                                        BUMP STOP
                                        # -
                                        -
                                        PUSH ROD
                                        LHD
                                        # -
                                        -
                                        PUSH ROD
                                        RHD
                                        # -
                                        -
                                        BALL SOCKET
                                        # -
                                        -
                                        hex. nut - M 5 - See technical information - GR. X NR. 15 - Discontinued part
                                        # -
                                        -
                                        hex. nut - M 5 - See technical information - GR. X NR. 15
                                        # -
                                        -
                                        VERTICAL PEDAL ADJUSTMENT - 30 MM
                                        # -
                                        -
                                        BUMP STOP
                                        # -
                                        -
                                        PUSH ROD
                                        LHD
