103-004 - CYLINDER HEAD - VALVES
Porsche 1987 (944) CYLINDER HEAD - VALVES Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 95110437402
CYLINDER HEAD GASKET
from £50.23
from £50.23
# 1
MPN: 95110437450
CYLINDER HEAD GASKET - FOR - RECOND. CYLINDER HEADS
from £67.51
from £67.51
# 2
MPN: 94410401303
CYLINDER HEAD
from £2,060.83
from £2,060.83
# 4
MPN: 91110118200
SEALING CAP
from £7.72
from £7.72
# 5
MPN: N 0119181
SEALING CAP - DISCONTINUED PART
# 5
MPN: N 0119185
SEALING CAP
from £0.47
from £0.47
# 6
MPN: 99906213902
STUD - BM 8 X 26
from £3.20
from £3.20
# 7
MPN: 90003601402
SEALING CAP
from £2.34
from £2.34
# 8
MPN: 92810564105
INTAKE VALVE
from £92.15
from £92.15
# 9
MPN: 92810564206
EXHAUST VALVE
from £122.72
from £122.72
# -
-
sleeve - for - valve guide seal
# 10
MPN: 92810461117
VALVE SEAT (INTAKE) - OVERSIZE 0.25 MM
from £14.57
from £14.57
# 11
MPN: 92810461214
VALVE SEAT (EXHAUST) - OVERSIZE 0.25 MM
from £30.04
from £30.04
# 12
MPN: 94410432751
valve guide - 1ST oversize
from £7.56
from £7.56
# 13
MPN: 92810460107
VALVE GUIDE SEAL
from £3.13
from £3.13
# 14
MPN: 94410546502
WASHER - 0,5 MM
from £2.28
from £2.28
# 14
MPN: 94410546503
WASHER - 1,0 MM
from £2.28
from £2.28
# 14
MPN: 94410546504
WASHER - 1,5 MM
from £2.37
from £2.37
# 15
MPN: 94410546302
WASHER
from £2.28
from £2.28
# 16
MPN: 94410590701
SET OF VALVE SPRINGS
from £22.40
from £22.40
# 17
MPN: 94410546703
SPRING SEAT
from £2.28
from £2.28
# 18
MPN: 92810522110
VALVE COLLET
from £0.86
from £0.86
# 19
MPN: 92810531202
HYDRAULIC TAPPET
from £47.63
from £47.63
# 21
MPN: 94410422800
THREADED PLUG - DISCONTINUED PART
# 21
MPN: 94410422801
THREADED PLUG
from £5.90
from £5.90
# 22
MPN: 92810521500
COVER
from £7.73
from £7.73
# 23
MPN: 92810520500
BRACKET
from £3.20
from £3.20
# 24
MPN: 90007501602
SCREW, HEX. HD. - M 6 X 22 - DISCONTINUED PART
# 24
MPN: 90007501603
SCREW, HEX. HD. - M 6 X 22
from £0.86
from £0.86
# 25
MPN: N 0115247
WASHER - A 6,4 - DISCONTINUED PART
# 25
MPN: N 01152427
Washer - A 6,4
from £0.47
from £0.47
# 26
MPN: 92810616701
GASKET
from £2.37
from £2.37
# 27
MPN: 92810471302
UNION
from £20.36
from £20.36
# 28
MPN: 90002500702
WASHER - A 8,4 - DISCONTINUED PART
# 28
MPN: 90002500703
Washer - A 8,4
from £0.84
from £0.84
# 29
MPN: 90007502909
SCREW, HEX. HD. - M 8 X 25 - DISCONTINUED PART
# 29
MPN: 90007502903
SCREW, HEX. HD. - M 8 X 25
from £1.61
from £1.61
# 30
MPN: N 0101134
SCREW, HEX. HD.
from £1.61
from £1.61
# 31
MPN: 94410441501
TRANSPORTATION SHACKLE
from £4.93
from £4.93
# 32
MPN: N 01224111
spring washer - M 8 X 22 - Discontinued part
# 33
MPN: 94410430503
GASKET
from £3.25
from £3.25
# 33
MPN: 94410430503
gasket - (asbestos free)
from £3.25
from £3.25
# 34
MPN: 94410432300
INTERMEDIATE FLANGE
from £28.87
from £28.87
# 35
MPN: 94410430203
GASKET
from £3.17
from £3.17
# 35
MPN: 94410430203
gasket - (asbestos free)
from £3.17
from £3.17
# 36
MPN: 94410430801
COOLING WATER SOCKET
from £42.02
from £42.02
# 37
MPN: N 0147252
SCREW, CHEESE HD. - M 8 X 25 - DISCONTINUED PART
# 37
MPN: 90006701803
SCREW, CHEESE HD. - M 8 X 25
from £1.11
from £1.11
# 38
MPN: N 0147252
SCREW, CHEESE HD. - M 8 X 25 - DISCONTINUED PART
# 38
MPN: 90006701803
SCREW, CHEESE HD. - M 8 X 25
from £1.11
from £1.11
# 39
MPN: N 0447321
bolt, with hex. socket - hd. - M 8 X 75
from £1.87
from £1.87
# 40
MPN: 94410422900
WASHER
from £2.34
from £2.34
# 41
MPN: 99907604302
HEX. NUT - M 12 X 1,5
from £2.37
from £2.37
# 42
MPN: 94410713900
Pressure relief valve - Discontinued part
from £508.95
from £508.95
# 42
MPN: 94410713900
PRESSURE RELIEF VALVE
from £508.95
from £508.95
# 43
MPN: 99921803502
THREADED PIN - M 6 X 20
from £3.20
from £3.20
# 44
MPN: 92810526200
PIN
from £2.02
from £2.02
