porsche 2014 (991-1 r/gt3/rs) coolant pump coolant pump housing parts diagram

105-000 - Coolant pump Coolant pump housing

Porsche 2014 (991-1 R/GT3/RS) Coolant pump Coolant pump housing Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                          #
                                                          Part number
                                                          Description
                                                          Key
                                                          Price
                                                          # 1
                                                          MPN: 9A110603901
                                                          COOLANT PUMP (COMPLETE)
                                                          COOLANT PUMP (COMPLETE)
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 1
                                                          MPN: 0PB121010C
                                                          COOLANT PUMP (COMPLETE)
                                                          A175, A176
                                                          from £370.09
                                                          from £370.09
                                                          This part replaces part number 9A110603901 - and 1 more. Click to view details
                                                          COOLANT PUMP Genuine Porsche Part - New (to order)
                                                          # 1
                                                          MPN: 9A110603990
                                                          COOLANT PUMP HOUSING (COMPLETE) D >>- 18.09.2017
                                                          DGGA
                                                          from £424.92
                                                          from £424.92
                                                          Water pump housing Genuine Porsche Part - New (to order)
                                                          # 1
                                                          MPN: 9A110603991
                                                          COOLANT PUMP HOUSING (COMPLETE) D - 19.09.2017>>
                                                          DGGA, DGGB, DNS, DSD
                                                          from £694.82
                                                          from £694.82
                                                          Water pump housing Genuine Porsche Part - New (to order)
                                                          # 2
                                                          MPN: 9A110611190
                                                          WATER GUIDE HOUSING
                                                          WATER GUIDE HOUSING
                                                          WATER GUIDE HOUSING Genuine Porsche Part - New (to order)
                                                          # 2
                                                          MPN: 9A110611191
                                                          Water guide housing D >>- 15.11.2016
                                                          Water guide housing D >>- 15.11.2016
                                                          from £200.04
                                                          from £200.04
                                                          WATER GUIDE HOUSING Genuine Porsche Part - New (to order)
                                                          # 2
                                                          MPN: 9A110611195
                                                          WATER GUIDE HOUSING USE ONLY IN CONJUNCTION WITH: 9A1.106.150.95 9A1.106.225.97 999.707.710.40 D >>- 25.03.2017
                                                          WATER GUIDE HOUSING Genuine Porsche Part - New (to order)
                                                          # 2
                                                          MPN: 9A110611196
                                                          WATER GUIDE HOUSING USE ONLY IN CONJUNCTION WITH: 9A1.106.150.95 9A1.106.225.97 999.707.710.40 D - 27.03.2017>>
                                                          DGGA, DGGB, DNS, DSD
                                                          WATER GUIDE HOUSING Genuine Porsche Part - New (to order)
                                                          # 3
                                                          MPN: 90038527001
                                                          HEXAGON HEAD BOLT M6X35
                                                          HEXAGON HEAD BOLT - M 6 X 35 Genuine Porsche Part - New (to order)
                                                          # 4
                                                          MPN: 90038500901
                                                          HEXAGON HEAD BOLT M6X16
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 4
                                                          MPN: 9A700812700
                                                          HEXAGON HEAD BOLT M6X25
                                                          from £0.85
                                                          from £0.85
                                                          This part replaces part number 90038507201
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 5
                                                          MPN: 9A110602631
                                                          WATER PIPE
                                                          A175, A176
                                                          from £55.29
                                                          from £55.29
                                                          WATER PIPE Genuine Porsche Part - New (to order)
                                                          # 5
                                                          MPN: 9A110602591
                                                          WATER PIPE
                                                          DGGA, DGGB,
                                                          from £174.88
                                                          from £174.88
                                                          WATER PIPE Genuine Porsche Part - New (to order)
                                                          # 6
                                                          MPN: 9A110632500
                                                          SEAL
                                                          A175, A176
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 7
                                                          MPN: 9A110632600
                                                          SEAL
                                                          A175, A176
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 7
                                                          MPN: 0PB121149
                                                          SEAL
                                                          DGGA, DGGB, DNSA, DNSH
                                                          from £6.96
                                                          from £6.96
                                                          This part replaces part number 9A110632600
                                                          GASKET Genuine Porsche Part - New In stock
                                                          # 8
                                                          MPN: 9A110655800
                                                          SEAL RING 48X57,4X6,5 THERMOSTAT
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 9
                                                          MPN: 99970762540
                                                          O-RING 59,00X2,50N THERMOSTAT
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 10
                                                          MPN: 99710680203
                                                          SPRING
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 11
                                                          MPN: 90038507001
                                                          TORX SCREW M6X50
                                                          A175, A176
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 11
                                                          MPN: 90038507001
                                                          TORX SCREW M6X50
                                                          DGGA, DGGB,
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 12
                                                          MPN: 90038507101
                                                          TORX SCREW BM8X50
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 13
                                                          MPN: 90038511501
                                                          TORX SCREW CM8X70
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 14
                                                          MPN: 9A110685190
                                                          PIPE FUEL FILLER NECK
                                                          from £93.25
                                                          from £93.25
                                                          TUBE Genuine Porsche Part - New (to order)
                                                          # 15
                                                          MPN: 9A110685290
                                                          HOSE
                                                          from £72.31
                                                          from £72.31
                                                          HOSE Genuine Porsche Part - New (to order)
                                                          # 16
                                                          MPN: 9A110604802
                                                          COOLANT PUMP HOUSING INCLUDED PULLEY
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 17
                                                          MPN: 9A110623800
                                                          WATER PIPE
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 18
                                                          MPN: 99970765840
                                                          O-RING 23X3
                                                          O-RING Genuine Porsche Part - New (to order)
                                                          # 19
                                                          MPN: 90038501901
                                                          TORX SCREW BM6X20
                                                          TORX SCREW BM6X20
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 19
                                                          MPN: PAF008126
                                                          HEXAGON HEAD BOLT BM6X20
                                                          from £0.85
                                                          from £0.85
                                                          This part replaces part number 90038501901
                                                          HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                                                          # 20
                                                          MPN: 90038509801
                                                          TORX SCREW BM8X25
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 21
                                                          MPN: 90038507201
                                                          TORX SCREW BM6X25
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 22
                                                          MPN: 9A110603190
                                                          COOLANT CONNECTION
                                                          COOLANT CONNECTION
                                                          COOLANT ADAPTER Genuine Porsche Part - New (to order)
                                                          # 22
                                                          MPN: 9A110603191
                                                          COOLANT CONNECTION
                                                          from £61.16
                                                          from £61.16
                                                          COOLANT ADAPTER Genuine Porsche Part - New (to order)
                                                          # 23
                                                          MPN: 9A110232200
                                                          SEAL
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 24
                                                          MPN: 99710680203
                                                          SPRING
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 25
                                                          MPN: 9A110653190
                                                          SEALING CAP
                                                          from £15.27
                                                          from £15.27
                                                          SEALING CAP Genuine Porsche Part - New (to order)
                                                          # 26
                                                          MPN: 99951265709
                                                          HOSE CLAMP B26X12
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 27
                                                          MPN: 9A110663100
                                                          BRACKET
                                                          A175
                                                          BRACKET Genuine Porsche Part - New (to order)
                                                          # 27
                                                          MPN: 9A110663101
                                                          BRACKET
                                                          A176
                                                          BRACKET Genuine Porsche Part - New (to order)
                                                          # 32
                                                          MPN: 99110641501
                                                          BRACKET WATER PIPE
                                                          A175
                                                          BRACKET Genuine Porsche Part - New (to order)
                                                          # 32
                                                          MPN: 99110641502
                                                          BRACKET WATER PIPE
                                                          A176, DGGA, DNSH, DGG
                                                          from £3.78
                                                          from £3.78
                                                          BRACKET Genuine Porsche Part - New (to order)
                                                          # 33
                                                          MPN: 99970760440
                                                          O-RING 34,00X3,00N
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 34
                                                          MPN: 9A110621500
                                                          SEAL
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 34
                                                          MPN: 0PB121437
                                                          SEAL
                                                          DGGA, DGGB, DNSA, DNSH
                                                          from £9.34
                                                          from £9.34
                                                          This part replaces part number 9A110621500
                                                          GASKET Genuine Porsche Part - New In stock
                                                          # 35
                                                          MPN: 9A110615001
                                                          thermostat housing D >>- 15.11.2016
                                                          thermostat housing D >>- 15.11.2016
                                                          from £205.88
                                                          from £205.88
                                                          THERMOSTAT HOUSING Genuine Porsche Part - New (to order)
                                                          # 35
                                                          MPN: 9A110615095
                                                          THERMOSTAT HOUSING USE ONLY IN CONJUNCTION WITH: 9A1.106.111.95 999.707.710.40
                                                          A176, DGGA, DGGB, DNSA, DNSH
                                                          THERMOSTAT HOUSING Genuine Porsche Part - New (to order)
                                                          # 36
                                                          MPN: 9A110622501
                                                          THERMOSTAT
                                                          THERMOSTAT
                                                          THERMOSTAT Genuine Porsche Part - New (to order)
                                                          # 36
                                                          MPN: 9A110622502
                                                          THERMOSTAT
                                                          THERMOSTAT
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 36
                                                          MPN: 9A110622597
                                                          THERMOSTAT WHEN USING: O-RING 999 707 710 40
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 37
                                                          MPN: 9A110630500
                                                          SEAL THERMOSTAT WHEN USING: 9A1.106.111.90 9A1.106.111.91 9A1.106.011.92 9A1.106.225.01 9A1.106.225.02 D >>- 15.11.2016
                                                          A175, A176
                                                          from £28.18
                                                          from £28.18
                                                          GASKET Genuine Porsche Part - New (to order)
                                                          # 37
                                                          MPN: 9A110630595
                                                          Seal thermostat when using: 9A1.106.111.95 9A1.106.111.96
                                                          Seal thermostat when using: 9A1.106.111.95 9A1.106.111.96
                                                          GASKET Genuine Porsche Part - New (to order)
                                                          # 37
                                                          MPN: 99970771040
                                                          O-RING THERMOSTAT WHEN USING: 9A1.106.111.95 9A1.106.111.96 9A1.106.225.97
                                                          from £25.74
                                                          from £25.74
                                                          O-RING Genuine Porsche Part - New (to order)
                                                          # 38
                                                          MPN: 90021901830
                                                          SEALING PLUG M14X1,5
                                                          SEALING PLUG M14X1,5
                                                          from £12.86
                                                          from £12.86
                                                          THREADED PLUG - M 14 X 1,5 Genuine Porsche Part - New (to order)
                                                          # 38
                                                          MPN: 99906303801
                                                          SEALING PLUG M14X1,5
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 39
                                                          MPN: 90012310430
                                                          SEAL RING A14X18
                                                          SEAL RING A14X18
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 39
                                                          MPN: 90012300730
                                                          SEAL RING A14X18
                                                          SEAL RING A14X18
                                                          from £0.59
                                                          from £0.59
                                                          This part replaces part number 90012310430
                                                          OIL INLET SEAL RING Genuine Porsche Part - New In stock
                                                          # 39
                                                          MPN: 90012317320
                                                          SEAL RING A14X18
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 41
                                                          MPN: 9A110201202
                                                          ASSEMBLY CARRIER
                                                          from £299.18
                                                          from £299.18
                                                          sub-frame Genuine Porsche Part - New (to order)
                                                          # 42
                                                          MPN: 9A110231200
                                                          SEAL
                                                          SEAL
                                                          from £17.12
                                                          from £17.12
                                                          GASKET Genuine Porsche Part - New (to order)
                                                          # 42
                                                          MPN: 0PB121228A
                                                          SEAL
                                                          from £18.96
                                                          from £18.96
                                                          SEAL Genuine Porsche Part - New (to order)
                                                          # 43
                                                          MPN: 9A110232200
                                                          SEAL
                                                          SEAL
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 43
                                                          MPN: 0PB121327C
                                                          SEAL
                                                          from £22.67
                                                          from £22.67
                                                          This part replaces part number 9A110232200
                                                          GASKET CYLINDER 4-6 Genuine Porsche Part - New (to order)
                                                          # 44
                                                          MPN: 99970758940
                                                          O-RING 31,00X3,00N
                                                          O-RING 31,00X3,00N
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 44
                                                          MPN: PAF008273
                                                          O-RING 31,00X3,00N
                                                          from £4.28
                                                          from £4.28
                                                          This part replaces part number 99970758940
                                                          O-RING Genuine Porsche Part - New In stock
                                                          # 45
                                                          MPN: 99909506303
                                                          DOWEL SLEEVE 6X10
                                                          from £3.33
                                                          from £3.33
                                                          SLEEVE Genuine Porsche Part - New (to order)
                                                          # 46
                                                          MPN: 90038511501
                                                          TORX SCREW CM8X70
                                                          TORX SCREW CM8X70
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 46
                                                          MPN: PAF008158
                                                          HEXAGON HEAD BOLT CM8X70
                                                          from £3.15
                                                          from £3.15
                                                          HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                          # 46
                                                          MPN: 90038507101
                                                          TORX SCREW BM8X50
                                                          TORX SCREW BM8X50
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 46
                                                          MPN: PAF008150
                                                          HEXAGON HEAD BOLT BM8X50
                                                          A175, A176
                                                          from £0.91
                                                          from £0.91
                                                          HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                          # 46
                                                          MPN: PAF008150
                                                          HEXAGON HEAD BOLT BM8X50
                                                          DGGA, DGGB, DNSA, DNSH
                                                          from £0.91
                                                          from £0.91
                                                          HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                                          # 47
                                                          MPN: 9A110621700
                                                          SEAL COOLANT PUMP
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 48
                                                          MPN: 9A110624800
                                                          PULLEY COOLANT PUMP
                                                          A175, A176
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 48
                                                          MPN: 0PB121031
                                                          PULLEY COOLANT PUMP
                                                          DGGA, DGGB, DNSA, DNSH
                                                          from £58.42
                                                          from £58.42
                                                          This part replaces part number 9A110624800
                                                          PULLEY Genuine Porsche Part - New (to order)
                                                          # 49
                                                          MPN: 99907310401
                                                          HEXAGON SOCKET HEAD BOLT M8X16
                                                          HEXAGON SOCKET HEAD BOLT M8X16
                                                          from £0.89
                                                          from £0.89
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 49
                                                          MPN: WHT001702
                                                          HEXAGON SOCKET HEAD BOLT M8X16
                                                          from £0.61
                                                          from £0.61
                                                          SCREW Genuine Porsche Part - New (to order)
                                                          # 50
                                                          MPN: 90021901830
                                                          SEALING PLUG M14X1,5
                                                          SEALING PLUG M14X1,5
                                                          from £12.86
                                                          from £12.86
                                                          THREADED PLUG - M 14 X 1,5 Genuine Porsche Part - New (to order)
                                                          # 50
                                                          MPN: 99906303801
                                                          SEALING PLUG M14X1,5
                                                          SEALING PLUG M14X1,5
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 50
                                                          MPN: 99992603001
                                                          BLEEDER SCREW M10X1 PLASTIC
                                                          from £0.95
                                                          from £0.95
                                                          BLEEDER SCREW Genuine Porsche Part - New (to order)
                                                          # 51
                                                          MPN: 90012310430
                                                          SEAL RING A14X18
                                                          SEAL RING A14X18
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 51
                                                          MPN: 90012317320
                                                          SEAL RING A14X18
                                                          SEAL RING A14X18
                                                          Supersession
                                                          Supersession
                                                          Genuine Porsche Part (no longer available to order)
                                                          # 52
                                                          MPN: 99951266109
                                                          HOSE CLAMP
                                                          from £0.59
                                                          from £0.59
                                                          Hose Clamp - B 30 X 12 Genuine Porsche Part - New (to order)
                                                          # 53
                                                          MPN: 99951265809
                                                          HOSE CLAMP
                                                          from £2.29
                                                          from £2.29
                                                          HOSE CLAMP Genuine Porsche Part - New (to order)
                                                          # 54
                                                          MPN: 9A110653500
                                                          COUPLING
                                                          from £15.43
                                                          from £15.43
                                                          clutch Genuine Porsche Part - New (to order)
                                                          # 55
                                                          MPN: 99970769140
                                                          O-RING 31,00X3,00N
                                                          from £6.15
                                                          from £6.15
                                                          O-RING Genuine Porsche Part - New (to order)
                                                          # 56
                                                          MPN: 94860642001
                                                          TEMPERATURE SENSOR
                                                          from £23.26
                                                          from £23.26
                                                          TEMPERATURE SENSOR Genuine Porsche Part - New (to order)
                                                          # 57
                                                          MPN: 90012311121
                                                          SEAL RING 14X20
                                                          from £0.91
                                                          from £0.91
                                                          SEAL RING Genuine Porsche Part - New (to order)
