porsche 2016 (991-1) rear spoiler parts diagram

803-007 - REAR SPOILER

Porsche 2016 (991-1) Rear spoiler Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 99150404102
                          DRIVE UNIT REAR SPOILER (COMPLETE)
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 2
                          MPN: 99150462100
                          CENTRING JOURNAL CARRIER
                          from £45.98
                          from £45.98
                          CENTRING JOURNAL Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 99150424103
                          SPOILER PRIMED UPPER PART
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 4
                          MPN: 99150420502
                          SPOILER LOWER PART
                          C2
                          from £96.51
                          from £96.51
                          SPOILER Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 99150420502
                          SPOILER LOWER PART D >>- 31.12.2015
                          from £96.51
                          from £96.51
                          SPOILER Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 99150420503
                          SPOILER LOWER PART
                          C4
                          from £92.66
                          from £92.66
                          SPOILER Genuine Porsche Part - New In stock
                          # 5
                          MPN: 99150466101
                          COVER LEFT
                          from £8.14
                          from £8.14
                          COVER Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 99150466201
                          COVER RIGHT
                          from £8.14
                          from £8.14
                          COVER Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 99970388540
                          STOP BUFFER 6X14,5X20
                          from £1.32
                          from £1.32
                          JOUNCE BUMPER Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 99970327440
                          RUBBER BUSH 19X5X2
                          C2
                          from £2.14
                          from £2.14
                          RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 99970327640
                          RUBBER BUSH 19X2X2
                          C4
                          from £2.14
                          from £2.14
                          RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 99950778501
                          PANEL NUT ST 4,2
                          from £0.59
                          from £0.59
                          SPEED NUT Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 99161288100
                          WIRE SET REAR SPOILER
                          harness Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 99150499123
                          Rear spoiler Aerokit
                          PXAA (Aerokit Cup)
                          REAR SPOILER Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 99150498114
                          REAR SPOILER PRIMED SPORT DESIGN PACKAGE
                          PXAT (SportDesign package)
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 12
                          MPN: 99150498115
                          REAR SPOILER PRIMED AEROKIT
                          PXAA (Aerokit Cup)
                          from £1,581.74
                          from £1,581.74
                          REAR SPOILER Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 99150498304
                          REAR SPOILER UPPER PART AEROKIT
                          PXAA (Aerokit Cup)
                          from £1,214.45
                          from £1,214.45
                          REAR SPOILER Genuine Porsche Part - New (to order)
                          # 14
                          MPN: 99907353401
                          BOLT WITH WASHER M8X30
                          from £1.39
                          from £1.39
                          BOLT WITH WASHER Genuine Porsche Part - New (to order)
                          # 15
                          MPN: N 91165701
                          HEX SOCKET HEAD BOLT (COMBI) M6X35
                          from £0.61
                          from £0.61
                          HEX SOCKET HEAD BOLT (COMBI) Genuine Porsche Part - New (to order)
                          HEXALOBULAR SOCKETM6X35-S11 Genuine Lamborghini - New In stock
                          # 16
                          MPN: 991504965001E0
                          WATER COLLECTING TRAY LEFT - BLACK
                          from £27.31
                          from £27.31
                          This part replaces part number 99150496500
                          WATER CATCH PAN Black Genuine Porsche Part - New (to order)
                          # 16
                          MPN: 991504966001E0
                          WATER COLLECTING TRAY RIGHT - BLACK
                          from £27.31
                          from £27.31
                          This part replaces part number 99150496600
                          WATER CATCH PAN Black Genuine Porsche Part - New (to order)
                          # 17
                          MPN: 99150436700
                          THROTTLE CONTROL ELEMENT DRIVE UNIT REAR SPOILER
                          from £37.92
                          from £37.92
                          ACTUATOR Genuine Porsche Part - New (to order)
                          # 18
                          MPN: 99150499801
                          SUPPORT REAR SPOILER
                          PXAT (SportDesign package)
                          from £110.31
                          from £110.31
                          MOUNTING Genuine Porsche Part - New (to order)
                          # 19
                          MPN: N 90986803
                          HEXAGON SOCKET HEAD PANEL BOLT ST 4,2 X13 FOR SPOILER LOWER PART
                          from £0.61
                          from £0.61
                          HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New In stock
                          HEXAGON SOCKET HEAD PANEL BOLT, 4.2 X 13 Genuine Lamborghini - New In stock
