107-005 - FUEL COLLECTION PIPE
Porsche 991R/GT3/RS (2018) FUEL COLLECTION PIPE Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 9A111085990
FUEL COLLECTION PIPE
(A175,A176)
from £308.72
from £308.72
# 1
MPN: 9A111084990
FUEL COLLECTION PIPE
cylinders 1-3 (DGGA,DGGB)
from £308.72
from £308.72
# 1
MPN: 9A111085991
FUEL COLLECTION PIPE
cylinders 4-6 (DGGA,DGGB)
from £537.05
from £537.05
# 2
MPN: 9A111031590
high pressure pump
Discontinued part (A175)
# 2
MPN: 9A111031592
high pressure pump
Discontinued part (A176)
# 2
MPN: 9A111031594
high pressure pump
Discontinued part (A176)
# 2
MPN: 9A111031595
high pressure pump
D >> - 05.08.2018 (DGGA,DGGB)
from £308.54
from £308.54
# 2
MPN: 9A111031596
high pressure pump
D - 06.08.2018>> (DGGA,DGGB)
from £460.44
from £460.44
# 2
MPN: 9GT127023A
high pressure pump
cylinders 1-3 (DNS,DSD)
from £670.99
from £670.99
# 2
MPN: 9GT127024A
high pressure pump
cylinders 4-6 (DNS,DSD)
from £539.87
from £539.87
# 3
MPN: 9A111033191
FUEL LINE
(A175,A176)
from £125.63
from £125.63
# 3
MPN: 9A111033192
FUEL LINE
(DGGA,DGGB)
from £125.63
from £125.63
# 3
MPN: 9GT127501
FUEL LINE
(DNS,DSD)
from £125.33
from £125.33
# 4
MPN: 9A111033291
FUEL LINE
(A175,A176, DGGA,DGGB)
from £125.63
from £125.63
# 4
MPN: 9GT127509
FUEL LINE
(DNS,DSD)
from £116.24
from £116.24
# 5
MPN: 06J906051F
PRESSURE SENSOR
(A175,A176, DGGA, DGGB)
from £60.77
from £60.77
# 5
MPN: 9P1906051A
PRESSURE SENSOR
(DNS,DSD)
from £131.06
from £131.06
# 7
MPN: 90038500901
TORX SCREW
M6X16 (A175,A176,)
Supersession
Supersession
# 7
MPN: PAF008126
HEXAGON HEAD BOLT
M6X20 (DNS,DSD)
from £0.87
from £0.87
This part replaces part number 90038501901
# 8
MPN: 9A111012890
HIGH-PRESSURE INJECTOR
also use: 9A1 110 759 91 (A175)
# 8
MPN: 9A111012891
HIGH-PRESSURE INJECTOR
also use: 9A1 110 759 91 (A176)
from £173.90
from £173.90
# 8
MPN: 9A111012892
HIGH-PRESSURE INJECTOR
also use: 9A1 110 759 91 (DGGA,DGGB)
from £231.16
from £231.16
# 8
MPN: 9A111092890
HIGH-PRESSURE INJECTOR
with: | retaining clip (A175,A176)
from £231.16
from £231.16
# 8
MPN: 9A111092892
HIGH-PRESSURE INJECTOR
with: | retaining clip (DGGA,DGGB)
# 9
MPN: 9A111075991
Retaining Clip
from £3.22
from £3.22
# 10
MPN: 9A111090691
FUEL LINE
(A175)
# 10
MPN: 9A111090692
FUEL LINE
(A176)
from £347.38
from £347.38
# 10
MPN: 9A111090696
FUEL LINE
(DGGA)
from £232.06
from £232.06
# 10
MPN: 9A111090697
FUEL LINE
(DGGA,DGGB)
from £383.30
from £383.30
# 10
MPN: 9GT127503
FUEL LINE
(DNS,DSD)
from £311.93
from £311.93
# 11
MPN: 9A111030690
BRACKET
fuel line (A175,A176)
from £11.73
from £11.73
# 12
MPN: 9A111032190
BRACKET
(A175,A176)
from £19.70
from £19.70
# 13
MPN: 9A110731300
TORX SCREW
M6X25 (A175,A176)
# 13
MPN: 9A110731301
TORX SCREW
M6X25 (DGGA)
from £0.63
from £0.63
# 17
MPN: 99907318901
SCREW, ROUND HD.
M6X12
from £0.91
from £0.91
# 19
MPN: 90038504101
HEXAGON HEAD BOLT
BM 6 X 12
Supersession
Supersession
# 20
MPN: 9A111051590
SUPPORT
high pressure pump (A175)
from £37.76
from £37.76
# 20
MPN: 9A111051591
SUPPORT
high pressure pump (A176,DGGA, DGGB)
from £67.71
from £67.71
# 22
MPN: 9A111053190
LINE HOLDER
(A175)
# 22
MPN: 9A111053191
LINE HOLDER
(A176 DGGA,DGGB)
from £30.94
from £30.94
# 22
MPN: 0PB129305
LINE HOLDER
(DGGA,DGGB, DNS,DSD)
from £23.01
from £23.01
# 23
MPN: 99959188201
SPEED NUT
M6
from £2.29
from £2.29
# 23
MPN: N 90627102
SPEED NUT, SELF-LOCKING
M6
from £2.21
from £2.21
# 24
MPN: 00004320735
GREASE
VP 881
from £10.10
from £10.10
# 25
MPN: 00004330327
SILICON LUBRICANT
OKS 1710 | 50ML | Discontinued part
# 25
MPN: 00004330590
SILICON LUBRICANT
OKS 1710 | 50ML
from £164.34
from £164.34
# 26
MPN: 00004320935
SPECIAL LUBRICANT
DF 977 S | 400ML
from £61.45
from £61.45
# 27
MPN: 9A111081595
SEAL RING
high pressure pump (A175,A176,)
from £5.84
from £5.84
# 27
MPN: 0PB129119A
SEAL RING
high pressure pump (DGGA,DGGB, DSD,DNS)
from £7.69
from £7.69
# 28
MPN: 9A111090890
repair kit
injector (A175,A176)
Supersession
Supersession
# 28
MPN: 9A111090891
repair kit
injector (DGGA,DGGB)
from £112.71
from £112.71
# 29
MPN: 06H906051J
PRESSURE SENSOR
low pressure switch (DGGA,DGGB DSD,DNS)
from £33.81
from £33.81
