porsche 2019 (992-1) chain tensioner timing chain parts diagram

103-110 - chain tensioner timing chain

Porsche 2019 (992-1) chain tensioner timing chain Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Key
                              Price
                              # 1
                              MPN: 0PB109252A
                              TIMING CHAIN CAMSHAFT CRANKSHAFT
                              from £122.54
                              from £122.54
                              TIMING CHAIN Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 9A700836500
                              SOCKET HEAD BOLT M6X10.8X38.2 TENSIONER BLADE
                              from £9.07
                              from £9.07
                              SCREW, CHEESE HD Genuine Porsche Part - New In stock
                              # 3
                              MPN: PAF008261
                              O-RING 15,0X3,0
                              from £2.29
                              from £2.29
                              This part replaces part number 99970734640
                              O-RING Genuine Porsche Part - New In stock
                              # 4
                              MPN: 0PB109507
                              CHAIN TENSIONER INCLUDED SEAL RING N 013.827.7
                              CHAIN TENSIONER INCLUDED SEAL RING N 013.827.7
                              from £68.86
                              from £68.86
                              CHAIN TENSIONER Genuine Porsche Part - New (to order)
                              # 4
                              MPN: 0PB109507B
                              CHAIN TENSIONER INCLUDED SEAL RING N 013.827.7
                              CHAIN TENSIONER INCLUDED SEAL RING N 013.827.7
                              from £71.49
                              from £71.49
                              CHAIN TENSIONER Genuine Porsche Part - New (to order)
                              # 4
                              MPN: 0PB109507D
                              CHAIN TENSIONER SEAL RING N 013.827.7
                              from £70.29
                              from £70.29
                              CHAIN TENSIONER Genuine Porsche Part - New (to order)
                              # 5
                              MPN: N 0138277
                              SEAL RING A22X27 FOR CHAIN TENSIONER
                              from £1.67
                              from £1.67
                              This part replaces part number 90012301121
                              SEAL RING Genuine Porsche Part - New In stock
                              # 6
                              MPN: PAF008646
                              O-RING 20,0X1,30 FOR CHAIN TENSIONER
                              from £7.43
                              from £7.43
                              This part replaces part number 99970106640
                              O-RING Genuine Porsche Part - New (to order)
                              # 7
                              MPN: PAA109513
                              SLIDE RAIL
                              from £22.98
                              from £22.98
                              SLIDE RAIL Genuine Porsche Part - New (to order)
                              # 8
                              MPN: 0PB109509
                              TENSIONER BLADE
                              from £25.40
                              from £25.40
                              TENSIONER BLADE Genuine Porsche Part - New (to order)
                              # 9
                              MPN: 9A700829800
                              SPACER SLEEVE
                              from £11.36
                              from £11.36
                              SPACER SLEEVE Genuine Porsche Part - New (to order)
                              # 10
                              MPN: 9A700836600
                              BOLT WITH WASHER INCLUDED O-RING
                              from £9.85
                              from £9.85
                              BOLT WITH WASHER Genuine Porsche Part - New (to order)
                              # 11
                              MPN: 0PB109514
                              SLIDE RAIL
                              from £11.65
                              from £11.65
                              SLIDE RAIL Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 0PB109229A
                              TIMING CHAIN OIL PUMP CRANKSHAFT
                              from £50.25
                              from £50.25
                              TIMING CHAIN Genuine Porsche Part - New (to order)
                              # 13
                              MPN: 0PB109508
                              TENSIONER BLADE
                              from £13.07
                              from £13.07
                              This part replaces part number 9A110523502
                              TENSIONER BLADE Genuine Porsche Part - New (to order)
                              # 14
                              -
                              CRANKSHAFT SEE ILLUSTRATION: 102-000
                              # 15
                              -
                              OIL PUMP SEE ILLUSTRATION: 104-000
