porsche 2019 (992-1) rear window wiper parts diagram

904-050 - REAR WINDOW WIPER

Porsche 2019 (992-1) REAR WINDOW WIPER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 992955711A
    wiper motor
    REAR WINDOW WIPER
    wiper motor Genuine Porsche Part - New (to order)
    # 2
    MPN: N 90570802
    HEX. NUT WITH WASHER
    M6
    from £1.15
    from £1.15
    HEX. NUT WITH WASHER Genuine Porsche Part - New (to order)
    # 3
    MPN: 992955273A
    GROMMET
    REAR WINDOW WIPER
    from £9.31
    from £9.31
    GROMMET Genuine Porsche Part - New (to order)
    # 4
    MPN: 9P1955707
    WIPER ARM
    REAR WINDOW WIPER
    from £84.58
    from £84.58
    WIPER ARM Genuine Porsche Part - New (to order)
    # 5
    MPN: 9P1955427
    WIPER BLADE
    rear | Rear window wiper
    from £42.60
    from £42.60
    This part replaces part number 99162818900
    WIPER BLADE Genuine Porsche Part - New (to order)
    # 6
    MPN: N 10609204
    shouldered hex. nut
    M8 | hex. nut
    from £1.15
    from £1.15
    shouldered hex. nut Genuine Porsche Part - New (to order)
    HEXAGON FLANGE NUT M8 Genuine Lamborghini - New In stock
    # 7
    MPN: 9P1955435
    CAP
    wiper arm | Rear window wiper
    from £5.84
    from £5.84
    This part replaces part number 99762812200
    CAP Genuine Porsche Part - New (to order)
    # 8
    MPN: 992955465
    GASKET
    from £3.74
    from £3.74
    GASKET Genuine Porsche Part - New (to order)
