porsche 2021 (992-1 gt3/rs/st) air conditioning condenser parts diagram

814-810 - AIR CONDITIONING CONDENSER

Porsche 2021 (992-1 GT3/RS/ST) Air conditioning Condenser Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 9GT816411
            A/C CONDENSER
            from £682.22
            from £682.22
            A/C CONDENSER Genuine Porsche Part - New (to order)
            # 2
            MPN: PAB298403A
            DRYER INSERT WITH ATTACHMENT PARTS
            from £174.80
            from £174.80
            DRYER INSERT WITH ATTACHMENT PARTS Genuine Porsche Part - New (to order)
            # 3
            MPN: 9GT816529A
            REFRIGERANT LINE
            from £163.44
            from £163.44
            REFRIGERANT LINE Genuine Porsche Part - New (to order)
            # 4
            MPN: 9GT816531A
            REFRIGERANT LINE
            from £161.91
            from £161.91
            REFRIGERANT LINE Genuine Porsche Part - New (to order)
            # 5
            MPN: N 91071702
            Hexagon socket flat M6X25 head bolt
            from £0.56
            from £0.56
            HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
            SCREW Genuine Lamborghini - New In stock
