porsche 2022 (992-1 gt3/rs/st) electrics bucket seat parts diagram

817-530 - Electrics bucket seat

Porsche 2022 (992-1 GT3/RS/ST) Electrics bucket seat Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 9GT971385
    WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
    PAV1 (Driving on the right) | PAV2 (Driving on the right (NAR)) | PQ1K (Racing shell seats in front)
    from £17.57
    from £17.57
    LOOM Genuine Porsche Part - New (to order)
    # 1
    MPN: 9GT971385A
    WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
    PAV0 (Driving on the left) | PQ1K (Racing shell seats in front)
    from £18.66
    from £18.66
    LOOM Genuine Porsche Part - New (to order)
    # 1
    MPN: 9GT971386
    WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
    PAV1 (Driving on the right) | PQ1K (Racing shell seats in front) | P4UE (Driver/passenger airbag) | P4UF (Driver/passenger airbag (passenger deactivatable))
    from £18.66
    from £18.66
    LOOM Genuine Porsche Part - New (to order)
    # 1
    MPN: 9GT971386A
    WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
    PAV2 (Driving on the right (NAR)) | PQ1K (Racing shell seats in front) | P4UB (Airbag for NAR)
    from £17.42
    from £17.42
    LOOM Genuine Porsche Part - New (to order)
    # 1
    MPN: 9GT971386B
    WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
    PAV0 (Driving on the left) | PQ1K (Racing shell seats in front)
    from £18.66
    from £18.66
    LOOM Genuine Porsche Part - New (to order)
    # 2
    MPN: 9GT971502
    BRACKET CONNECTION POINT
    from £13.28
    from £13.28
    BRACKET Genuine Porsche Part - New (to order)
