porsche 2009 (997-2 gt3) camshaft housing parts diagram

103-011 - CAMSHAFT HOUSING

Porsche 2009 (997-2 GT3) CAMSHAFT HOUSING Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 99710590990
                CAMSHAFT HOUSING
                left | Cyl. 1 - 3
                from £4,374.32
                from £4,374.32
                CAMSHAFT HOUSING Genuine Porsche Part - New (to order)
                # 1
                MPN: 99710591090
                CAMSHAFT HOUSING
                right | Cyl. 4 - 6
                from £3,068.48
                from £3,068.48
                CAMSHAFT HOUSING Genuine Porsche Part - New (to order)
                # 2
                MPN: 90038504801
                TORX SCREW
                AM 6 X 30
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 3
                MPN: 94410436100
                SLEEVE
                from £2.93
                from £2.93
                sleeve - for - flange - seal - crankshaft Genuine Porsche Part - New (to order)
                # 4
                MPN: 90001207100
                DOWEL PIN
                A 4,0 X 8
                from £1.10
                from £1.10
                DOWEL PIN - A 4,0 X 8 Genuine Porsche Part - New (to order)
                # 5
                MPN: 99710523391
                oil-conducting housing
                from £109.08
                from £109.08
                oil-conducting housing Genuine Porsche Part - New (to order)
                # 6
                MPN: 90006705103
                SCREW, CHEESE HD.
                M 5 X 10
                from £2.29
                from £2.29
                SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                # 7
                MPN: 99610561393
                GASKET
                from £88.48
                from £88.48
                This part replaces part number 99610561391
                GASKET Genuine Porsche Part - New (to order)
                # 8
                MPN: 90038527001
                HEXAGON HEAD BOLT
                AM 6 X 35
                HEXAGON HEAD BOLT - M 6 X 35 Genuine Porsche Part - New (to order)
                # 9
                MPN: 90038507201
                TORX SCREW
                AM 6 X 25
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 10
                MPN: 90038511801
                HEXAGON HEAD BOLT
                M 6 X 75
                from £5.33
                from £5.33
                HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                # 11
                MPN: 90038507101
                TORX SCREW
                AM 8 X 50
                TORX SCREW Genuine Porsche Part - New (to order)
                # 12
                MPN: 99710443590
                SHIELD
                Cyl. 1 - 3
                from £45.08
                from £45.08
                SHIELD Genuine Porsche Part - New (to order)
                # 12
                MPN: 99710443690
                SHIELD
                Cyl. 4 - 6
                from £45.08
                from £45.08
                SHIELD Genuine Porsche Part - New (to order)
                # 13
                MPN: 90038504101
                HEXAGON HEAD BOLT
                M 6 X 12
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 14
                MPN: 99710531571
                COVER
                from £145.17
                from £145.17
                COVER Genuine Porsche Part - New (to order)
                # 15
                MPN: 99970748241
                O-RING
                90,00 X 2,50 | No longer use the part here
                from £7.97
                from £7.97
                O-Ring - 90,00 X 2,5 Genuine Porsche Part - New In stock
                # 15
                MPN: 99970120840
                O-RING
                88,57 x 2,62
                from £2.71
                from £2.71
                O-RING Genuine Porsche Part - New (to order)
                # 16
                MPN: 90038501901
                TORX SCREW
                M 6 X 20
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 17
                MPN: 99760610601
                HALL SENSOR
                Discontinued part
                HALL SENSOR Genuine Porsche Part - New (to order)
                # 17
                MPN: 99760610603
                HALL SENSOR
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 18
                MPN: 99970740440
                O-RING
                17,05 X 1,78 | To | Use | 997.606.106.03 | No longer use the part here
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 19
                MPN: 99907310301
                SCREW, ROUND HD.
                M 6 X 16
                from £0.91
                from £0.91
                SCREW, ROUND HD Genuine Porsche Part - New In stock
                # 20
                MPN: 99710530373
                ACTUATOR
                Intake
                from £235.43
                from £235.43
                ACTUATOR Genuine Porsche Part - New (to order)
                # 21
                MPN: 99710530575
                BRACKET F.THROTTLE CONTR.ELEM.
                from £46.13
                from £46.13
                BRACKET F.THROTTLE CONTR.ELEM Genuine Porsche Part - New (to order)
                # 22
                MPN: 99610590305
                O-RING
                18,72 x 2,62
                from £10.22
                from £10.22
                O-RING - FOR - ACTUATOR - CAMSHAFT Genuine Porsche Part - New (to order)
                # 23
                MPN: 90038527501
                TORX SCREW
                M 6 X 20
                from £2.92
                from £2.92
                TORX SCREW Genuine Porsche Part - New (to order)
                # 24
                MPN: 99610532970
                SEALING CAP
                from £23.19
                from £23.19
                SEALING CAP Genuine Porsche Part - New In stock
                # 25
                MPN: 99711059790
                RETAINING PLATE
                from £7.74
                from £7.74
                RETAINING PLATE Genuine Porsche Part - New (to order)
                # 26
                MPN: 99660711700
                SENSOR BRACKET
                (9777)
                Sensor bracket - for - Connector Genuine Porsche Part - New (to order)
                # 26
                MPN: 99660711701
                SENSOR BRACKET
                (9774)
                from £37.09
                from £37.09
                SENSOR BRACKET Genuine Porsche Part - New (to order)
                # 27
                -
                COVER
                Matching with: | Camshaft housing
                # 28
                MPN: 9A110530402
                ACTUATOR
                NVS | Discontinued part
                ACTUATOR Genuine Porsche Part - New (to order)
                # 28
                MPN: 9A110530403
                ACTUATOR
                NVS | Discontinued part
                ACTUATOR Genuine Porsche Part - New (to order)
                # 28
                MPN: 9A110530404
                ACTUATOR
                NVS
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 29
                MPN: 99970744640
                O-RING
                18 X 2,5 | No longer use the part here
                from £2.29
                from £2.29
                O-Ring - 18,00 X 2,5 Genuine Porsche Part - New In stock
                # 29
                MPN: 99970134240
                O-RING
                19 X 2,5
                from £1.04
                from £1.04
                O-RING Genuine Porsche Part - New (to order)
                # 30
                MPN: 90038511201
                TORX SCREW
                BM 5 X 12
                from £2.29
                from £2.29
                TORX SCREW Genuine Porsche Part - New (to order)
                # 31
                MPN: 99710560290
                SLEEVE
                for | ignition coil
                from £26.01
                from £26.01
                SLEEVE Genuine Porsche Part - New (to order)
                # 32
                MPN: 00004320458
                SEALANT
                DREI BOND 2210 | 30 GR. | No longer use the part here
                from £27.08
                from £27.08
                sealant - Silicon - FD 2210 - Container - 30 g Genuine Porsche Part - New (to order)
                # 32
                MPN: 99991557343
                SEALANT
                DOBOSEAL 224N | 75 ML
                SEALANT Genuine Porsche Part - New (to order)
                # 32
                MPN: 00004302400
                EXTREME-PRESSURE GREASE
                1 tube | 80 GR. | for | camshaft
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
