porsche 2011 (997-2 gt3) cover parts diagram

803-006 - COVER

Porsche 2011 (997-2 GT3) COVER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 99751222594
              COVER
              PRIMED
              COVER Genuine Porsche Part - New (to order)
              # 1
              MPN: 997512227A1
              COVER
              primed |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £11,102.90
              from £11,102.90
              COVER Genuine Porsche Part - New (to order)
              # 1
              MPN: 997512227A5
              COVER
              primed |
              D - MJ 2011>> (RS 4,0 PR:006)
              from £12,262.13
              from £12,262.13
              COVER Genuine Porsche Part - New (to order)
              # 2
              MPN: 99751216592
              SPOILER
              Carbon |
              with: | Wing plate for rear spoiler | POSITION 3,4,5, | primed
              from £6,872.60
              from £6,872.60
              SPOILER Genuine Porsche Part - New (to order)
              # 2
              MPN: 99751216593
              SPOILER
              Carbon |
              with: | Wing plate for rear spoiler | POSITION 3,4,5, | primed (PR:193)
              from £7,800.92
              from £7,800.92
              SPOILER Genuine Porsche Part - New (to order)
              # 2
              MPN: 99751226597
              SPOILER
              Carbon |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £6,268.04
              from £6,268.04
              SPOILER Genuine Porsche Part - New (to order)
              # 2
              MPN: 997512265A3
              SPOILER
              primed |
              D - MJ 2011>> (RS 4,0 PR:006)
              from £4,867.91
              from £4,867.91
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246301
              SPOILER
              left | Wing plate for rear spoiler | primed |
              D >> - MJ 2009
              from £955.97
              from £955.97
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246302
              SPOILER
              left | Wing plate for rear spoiler | indian red |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £1,164.37
              from £1,164.37
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246303
              SPOILER
              left | Wing plate for rear spoiler | White gold metallic |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £1,264.88
              from £1,264.88
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246390
              SPOILER
              left | Wing plate for rear spoiler |
              D - MJ 2011>> (RS 4,0 PR:006)
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # -
              -
              GT SILVER METALLIC
              This part replaces part number 99751246390
              # 3
              MPN: 99751246401
              SPOILER
              right | Wing plate for rear spoiler | primed
              from £955.97
              from £955.97
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246402
              SPOILER
              right | Wing plate for rear spoiler | indian red |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £1,162.13
              from £1,162.13
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246403
              SPOILER
              right | Wing plate for rear spoiler | White gold metallic |
              D - MJ 2010>> (GT3RS PR:XAA)
              from £1,107.02
              from £1,107.02
              SPOILER Genuine Porsche Part - New (to order)
              # 3
              MPN: 99751246490
              SPOILER
              right | Wing plate for rear spoiler |
              D - MJ 2011>> (RS 4,0 PR:006)
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # -
              -
              GT SILVER METALLIC
              This part replaces part number 99751246490
              # 5
              MPN: 99907342701
              SCREW, ROUND HD.
              M6 X 25
              from £16.00
              from £16.00
              SCREW, ROUND HD Genuine Porsche Part - New (to order)
              # 6
              MPN: 99751243592
              AIR DUCT
              left | primed
              from £516.29
              from £516.29
              This part replaces part number 99751243593
              AIR DUCT Genuine Porsche Part - New (to order)
              # 6
              MPN: 99751243692
              AIR DUCT
              right | primed
              from £445.80
              from £445.80
              AIR DUCT Genuine Porsche Part - New (to order)
              # 7
              MPN: 99751262590
              INTAKE MESH
              LEFT
              INTAKE MESH Genuine Porsche Part - New (to order)
              # 7
              MPN: 99751262690
              INTAKE MESH
              RIGHT
              INTAKE MESH Genuine Porsche Part - New (to order)
              # 7
              MPN: 99751262591
              INTAKE MESH
              D - MJ 2010>> ( GT3RS PR:XAA)
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # -
              -
              PRIMED
              This part replaces part number 99751262591
              # 8
              MPN: 99907608240
              CAP
              T5/16 X 7,0
              from £0.81
              from £0.81
              CAP Genuine Porsche Part - New (to order)
              # 9
              MPN: 99751261101
              GASKET
              from £3.26
              from £3.26
              GASKET Genuine Porsche Part - New (to order)
              # 10
              MPN: 99970301940
              SEALING CAP
              25,5 X 37,0
              from £0.47
              from £0.47
              SEALING CAP Genuine Porsche Part - New (to order)
              # 11
              MPN: 99651298700
              ADJUSTING SCREW
              COVER
              from £3.69
              from £3.69
              adjusting screw - Adjustable Genuine Porsche Part - New (to order)
              # 12
              MPN: 99751244390
              END PLATE
              gasket | Air cleaner system
              from £45.33
              from £45.33
              END PLATE Genuine Porsche Part - New (to order)
              # 13
              MPN: 99751255190
              GAS-FILLED STRUT
              (PR:004)
              from £53.84
              from £53.84
              GAS-FILLED STRUT Genuine Porsche Part - New (to order)
              # 14
              MPN: 99916705103
              BALL PIN
              from £4.55
              from £4.55
              ball pin - M 8 Genuine Porsche Part - New (to order)
              # 15
              MPN: 99751215102
              HINGE
              LEFT
              from £66.60
              from £66.60
              HINGE Genuine Porsche Part - New (to order)
              # 15
              MPN: 99751215201
              HINGE
              RIGHT
              from £66.60
              from £66.60
              HINGE Genuine Porsche Part - New (to order)
              # 16
              MPN: 90037821401
              SCREW, HEX. HD.
              M 6 X 18
              from £0.74
              from £0.74
              SCREW, HEX. HD Genuine Porsche Part - New (to order)
              # 17
              MPN: 90007546609
              BOLT WITH WASHER
              M 6 X 16
              BOLT WITH WASHER - M 6 X 16 Genuine Porsche Part - New (to order)
              # 18
              MPN: 99751215300
              STOP
              HINGE
              from £2.76
              from £2.76
              STOP Genuine Porsche Part - New (to order)
              # 19
              MPN: 99762405601
              FAN
              Engine bay
              Supersession
              Supersession
              Genuine Porsche Part (no longer available to order)
              # 20
              MPN: 99970345140
              RUBBER GROMMET
              9,0 X 14,0 X 1,5
              from £1.25
              from £1.25
              RUBBER GROMMET Genuine Porsche Part - New (to order)
              # 21
              MPN: 99920909301
              SPACER SLEEVE
              7,0 X 1,0 X 12
              from £2.29
              from £2.29
              SPACER SLEEVE Genuine Porsche Part - New (to order)
              # 22
              MPN: 99907341701
              FILLISTER HD. SCREW
              M6 X 30
              FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
              # 23
              MPN: 90037821401
              SCREW, HEX. HD.
              M6 x 18
              from £0.74
              from £0.74
              SCREW, HEX. HD Genuine Porsche Part - New (to order)
              # 24
              MPN: 99751221301
              LOCK UPPER PART
              from £18.96
              from £18.96
              LOCK UPPER PART Genuine Porsche Part - New (to order)
              # 25
              MPN: 99751205300
              LOCK LOWER PART
              LOCK LOWER PART Genuine Porsche Part - New (to order)
              # 26
              MPN: N 91066401
              hexagon socket head
              bolt (combi) | M6 x 40
              from £0.69
              from £0.69
              hexagon socket head Genuine Porsche Part - New (to order)
              HEXAGON SOCKET HEAD BOLT (COMBI) Genuine Bentley Part - New (to order)
              # 27
              MPN: 99751252100
              BOWDEN CABLE
              EMERGENCY OPERATION
              from £16.16
              from £16.16
              BOWDEN CABLE Genuine Porsche Part - New (to order)
              # 28
              MPN: 90011600202
              LOCK WASHER
              3,2
              from £0.47
              from £0.47
              lock washer - D - MJ 2001>> Genuine Porsche Part - New (to order)
              # 29
              MPN: 99762411800
              ACTUATOR
              D >> - MJ 2008
              ACTUATOR Genuine Porsche Part - New (to order)
              # 29
              MPN: 99762411801
              ACTUATOR
              D - MJ 2009>>
              from £63.92
              from £63.92
              ACTUATOR Genuine Porsche Part - New (to order)
              # -
              -
              repair kit
              harness | actuator |
              D >> - MJ 2008
              # 30
              MPN: 99751244400
              PLUG
              PLUG Genuine Porsche Part - New (to order)
              # 31
              MPN: 99907343001
              SCREW, ROUND HD.
              m 8 x 18
              from £21.41
              from £21.41
              SCREW, ROUND HD Genuine Porsche Part - New (to order)
              # 32
              MPN: 90033600601
              WASHER
              from £6.62
              from £6.62
              WASHER Genuine Porsche Part - New (to order)
              # -
              -
              RETAINER FOR SPOILER
              left | |
              D - MJ 2010>> ( GT3RS PR:XAA)
              # -
              -
              RETAINER FOR SPOILER
              left | |
              D - MJ 2011>> (RS 4,0 PR:006)
              # -
              -
              RETAINER FOR SPOILER
              right | |
              D - MJ 2010>> ( GT3RS PR:XAA)
              # -
              -
              RETAINER FOR SPOILER
              right | |
              D - MJ 2011>> (RS 4,0 PR:006)
              # -
              -
              SPACER WASHER
              D - MJ 2010>> (GT3RS PR:XAA)
              # -
              -
              NUT
              M6 |
              D - MJ 2010>> (GT3RS PR:XAA)
              # -
              -
              SCREW, CSK. HD.
              M6 X 12 | Micro-self-locking | silver |
              D - MJ 2010>> (GT3RS PR:XAA)
              # -
              -
              SCREW, CSK. HD.
              M6 X 25 |
              D - MJ 2010>> ( GT3RS PR:XAA)
              # -
              -
              AIR DUCT
              left | air cleaner |
              D - MJ 2011>> (RS 4,0 PR:006)
              # -
              -
              AIR DUCT
              right | air cleaner |
              D - MJ 2011>> (RS 4,0 PR:006)
