porsche 1997 (986 boxster) roll bar parts diagram

812-000 - ROLL BAR

Porsche 1997 (986 Boxster) roll bar Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                            #
                                            Part number
                                            Description
                                            Key
                                            Price
                                            # -
                                            -
                                            THREE-POINT SAFETY BELT
                                            # 1
                                            MPN: 9865800110170C
                                            ROLL BAR - BLACK
                                            from £1,286.73
                                            from £1,286.73
                                            SAFETY ROLL BAR Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680303302
                                            THREE-POINT SAFETY BELT LEFT D >>- MJ 2001
                                            from £212.60
                                            from £212.60
                                            three-point seat belt - D >> - MJ 2001 Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680303303
                                            THREE-POINT SAFETY BELT LEFT D - MJ 2002>>
                                            three-point seat belt - D - MJ 2002>> Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398201V02
                                            THREE-POINT SAFETY BELT LEFT D - MJ 2002>>- SPEED YELLOW
                                            from £413.59
                                            from £413.59
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398201H03
                                            THREE-POINT SAFETY BELT LEFT D - MJ 2002>>- MARITIME BLUE
                                            from £289.15
                                            from £289.15
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398201N13
                                            THREE-POINT SAFETY BELT LEFT D - MJ 2002>>- GUARDS RED (Porsche)
                                            from £289.15
                                            from £289.15
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680303402
                                            THREE-POINT SEAT BELT WITH RIGHT INERTIA REEL D >>- MJ 2001
                                            from £212.60
                                            from £212.60
                                            three-point seat belt with - inertia reel - D >> - MJ 2001 Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680303404
                                            THREE-POINT SAFETY BELT RIGHT D - MJ 2002>>
                                            three-point seat belt - D - MJ 2002>> Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398302V02
                                            THREE-POINT SAFETY BELT RIGHT D - MJ 2002>>- SPEED YELLOW
                                            from £413.59
                                            from £413.59
                                            3-POINT BELT SPEED YELLOW RHS Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398302H03
                                            THREE-POINT SAFETY BELT RIGHT D - MJ 2002>>- MARITIME BLUE
                                            from £413.59
                                            from £413.59
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398302N13
                                            THREE-POINT SAFETY BELT RIGHT D - MJ 2002>>- GUARDS RED (Porsche)
                                            Porsche PART 98680398302N13 Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680303405
                                            THREE-POINT SAFETY BELT RIGHT FOR CHILD SEAT D - MJ 2002>>
                                            three-point seat belt - for - child seat - D - MJ 2002>> Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398303V02
                                            ADDITIONAL SAFETY BELT FOR RIGHT CHILD CAR SEAT D - MJ 2002>>- SPEED YELLOW
                                            from £413.59
                                            from £413.59
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398303H03
                                            ADDITIONAL SAFETY BELT FOR RIGHT CHILD CAR SEAT D - MJ 2002>>- MARITIME BLUE
                                            from £413.59
                                            from £413.59
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 98680398303N13
                                            ADDITIONAL SAFETY BELT FOR RIGHT CHILD CAR SEAT D - MJ 2002>>- GUARDS RED (Porsche)
                                            from £465.54
                                            from £465.54
                                            AS 3-POINT BELT Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 91180315000
                                            HEXAGON BOLT
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 4
                                            MPN: 99680318304
                                            Belt latch (drivers side)
                                            from £254.92
                                            from £254.92
                                            PRESS BUTTON BUCKLE - (DRIVERS SIDE) - D >>- MJ 2001 Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 99680318307
                                            BELT LATCH (DRIVERS SIDE) D - MJ 2002>>
                                            from £248.83
                                            from £248.83
                                            press button buckle - D - MJ 2002>> Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 99680318301
                                            BELT LATCH (PASSENGER SIDE) D >>- MJ 2001
                                            from £248.83
                                            from £248.83
                                            press button buckle - D >> - MJ 2001 Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 99680318308
                                            BELT LATCH (PASSENGER SIDE) D - MJ 2002>>
                                            from £248.83
                                            from £248.83
                                            This part replaces part number 99780318303
                                            press button buckle - D - MJ 2002>> Genuine Porsche Part - New (to order)
                                            # 5
                                            MPN: 99921810102
                                            HEXAGON BOLT
                                            from £1.67
                                            from £1.67
                                            SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                            # 6
                                            MPN: 9868035410001C
                                            COVER - BLACK
                                            from £3.56
                                            from £3.56
                                            COVERING Genuine Porsche Part - New (to order)
                                            # 7
                                            MPN: 91480346810
                                            SCREW
                                            from £6.65
                                            from £6.65
                                            SCREW - F >>94-KN401 291 - F >>95-KN100 776 Genuine Porsche Part - New (to order)
                                            # 8
                                            MPN: 99992406402
                                            SPACER SLEEVE
                                            SPACER SLEEVE
                                            SPACER SLEEVE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                            # 8
                                            MPN: 99992406401
                                            SPACER SLEEVE
                                            from £3.05
                                            from £3.05
                                            SPACER SLEEVE - 12 X 18 X 14 - F 96-LS400 426>>- F 96-LS410 070>> Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 211857771
                                            WASHER
                                            from £2.20
                                            from £2.20
                                            Washer - for - flexible lock - Movable Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 803019811B
                                            HEXAGON BOLT
                                            from £11.78
                                            from £11.78
                                            screw, hex. hd. - Discontinued part Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: 811857845 01C
                                            COVER CAP - SATIN BLACK
                                            from £1.36
                                            from £1.36
                                            This part replaces part number 811857845
                                            cap - F >>96-LS400 425 - F >>96-LS410 069 satin black Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 98656180503
                                            WATER COLLECTING TRAY LEFT
                                            from £110.69
                                            from £110.69
                                            WATER COLLECTING TRAY Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 98656180603
                                            WATER COLLECTING TRAY RIGHT
                                            from £110.69
                                            from £110.69
                                            WATER COLLECTING TRAY Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 98656183302
                                            WATER DRAINAGE HOSE
                                            from £31.22
                                            from £31.22
                                            WATER DRAIN HOSE Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 98656183402
                                            WATER DRAINAGE HOSE
                                            from £31.22
                                            from £31.22
                                            WATER DRAIN HOSE Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: N 90068501
                                            PRESS STUD
                                            from £3.05
                                            from £3.05
                                            Pushbutton - D - MJ 1995>> Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 98756148700
                                            FILTER ELEMENT WATER COLLECTING TRAY
                                            from £7.10
                                            from £7.10
                                            FILTER ELEMENT - WATER COLLECTING TRAY Genuine Porsche Part - New (to order)
                                            # 16
                                            MPN: 98656158903
                                            FRICTION WASHER
                                            FRICTION WASHER Genuine Porsche Part - New (to order)
                                            # 17
                                            MPN: 98656119102
                                            tension wire
                                            from £65.28
                                            from £65.28
                                            tension wire Genuine Porsche Part - New (to order)
                                            # 19
                                            MPN: 98656191700
                                            THREADED PLATE
                                            from £28.24
                                            from £28.24
                                            TAPPING PLATE Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: 98658013101
                                            CONSOLE LEFT
                                            from £24.99
                                            from £24.99
                                            BRACKET Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: 98658013201
                                            CONSOLE RIGHT
                                            from £24.99
                                            from £24.99
                                            BRACKET Genuine Porsche Part - New (to order)
                                            # 21
                                            MPN: 99907306002
                                            PANEL SCREW
                                            from £0.65
                                            from £0.65
                                            TAPPING SCREW - ST 4,8 X 18 Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: N 90068501
                                            PRESS STUD
                                            from £3.05
                                            from £3.05
                                            Pushbutton - D - MJ 1995>> Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 98658051300
                                            SPACER ROLL BAR 1 MM
                                            from £7.80
                                            from £7.80
                                            PLATE - ROLL BAR - 1 MM Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 98658061300
                                            SPACER ROLL BAR 1 MM
                                            from £1.16
                                            from £1.16
                                            PLATE - ROLL BAR - 1 MM Genuine Porsche Part - New (to order)
                                            # 22
                                            MPN: 00004330007
                                            PAINT SET METAL GREY 1L
                                            PAINT SET - METAL GREY - 1L Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: 99661299110
                                            CONNECTION CABLE (DRIVERS SIDE) FOR SEAT BELT TENSIONER
                                            from £18.14
                                            from £18.14
                                            CONNECTION CABLE - (DRIVERS SIDE) - FOR - SEAT BELT TENSIONER Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: 99761279301
                                            WIRE SET SEAT BELT TENSIONER (DRIVERS SIDE) FOR SEAT BELT TENSIONER
                                            from £31.10
                                            from £31.10
                                            This part replaces part number 99661299100
                                            harness Genuine Porsche Part - New (to order)
                                            # 23
                                            MPN: 99661299100
                                            CONNECTION CABLE (PASSENGER SIDE) FOR SEAT BELT TENSIONER
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 23
                                            MPN: 99761279301
                                            WIRE SET SEAT BELT TENSIONER (PASSENGER SIDE) FOR SEAT BELT TENSIONER
                                            from £31.10
                                            from £31.10
                                            This part replaces part number 99661299100
                                            harness Genuine Porsche Part - New (to order)
                                            # 25
                                            MPN: 95580305600HCP
                                            KNOB - BLACK
                                            This part replaces part number 95580305600
                                            Black Genuine Porsche Part - New (to order)
                                            # 26
                                            MPN: 99907606502
                                            COLLAR NUT
                                            from £0.91
                                            from £0.91
                                            SHOULDERED NUT Genuine Porsche Part - New (to order)
