201-000 - FUEL TANK
Porsche 2011 (987 Boxster) Fuel tank Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 99720102105
Fuel tank lhd
P098 (Left-hand drive version)
from £2,050.48
from £2,050.48
# 1
MPN: 99720102206
Fuel tank rhd
P099 (Right-hand drive version)
from £2,050.48
from £2,050.48
# 2
MPN: 99720162300
UNION NUT
from £9.12
from £9.12
# 3
MPN: 1J0919133A
SEAL RING
Supersession
Supersession
# 4
MPN: 98762013200
fuel pump
A120 (2.9 Litre 6 Cyliner Engine (255 Horsepower / 188 Kilowatt with Engine Code: A120 and installed 08/2008-05/2012)
# 4
MPN: 99762014201
fuel pump
A121 (3.4 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: A121 and installed 08/2008-05/2012) A121 (3.4 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: A121 and installed 08/2010-05/2012)
Supersession
Supersession
# 5
MPN: 99762084200
SENDER FOR FUEL GAUGE WITH: FLANGE
Supersession
Supersession
# 6
MPN: 99720133102
BOTTOM PROTECTION FOR LHD FUEL TANK
P098 (Left-hand drive version)
from £74.29
from £74.29
# 6
MPN: 99720133103
BOTTOM PROTECTION FOR RHD FUEL TANK
P099 (Right-hand drive version)
from £74.29
from £74.29
# 7
MPN: 99720110601
TENSIONING STRAP RIGHT
from £35.41
from £35.41
# 8
MPN: 99720110501
TENSIONING STRAP LEFT
from £35.41
from £35.41
# 9
MPN: 99620110702
TENSIONING STRAP LHD
P098 (Left-hand drive version)
from £34.82
from £34.82
# 9
MPN: 99620110800
TENSIONING STRAP RHD
P099 (Right-hand drive version)
from £34.82
from £34.82
# 10
MPN: 90007547901
BOLT WITH WASHER M 8 X 40
from £10.72
from £10.72
This part replaces part number 90007547909
# 11
MPN: 99720104306
FUEL FILLER NECK
P without 150, P without 193
from £261.29
from £261.29
# 11
MPN: 99720104307
FUEL FILLER NECK
P150 (Operation with leaded gas)
from £261.29
from £261.29
# 11
MPN: 99720104307
FUEL FILLER NECK
P193 (japan version)
from £261.29
from £261.29
# 12
MPN: 99907334809
FILLISTER HD. BOLT M 6 X 12
from £0.91
from £0.91
# 13
MPN: 99720195102
BRACKET FOR FILLER NECK (COMPLETE)
from £85.75
from £85.75
# 14
MPN: 99620124103
CAP WITH RETAINING STRAP FOR FUEL TANK WITH: STRAP
from £11.90
from £11.90
# 14
MPN: 99950749940
SPREADER RIVET
from £0.65
from £0.65
# 15
MPN: 191201557
SEAL RING
from £12.37
from £12.37
# 16
MPN: 99620175500
SUPPORT WASHER
from £8.95
from £8.95
# 17
MPN: 99620175300
SEAL
from £8.95
from £8.95
# 17
MPN: 00004320689
Multi-purpose additive for Otto engine fuels 100 ML
Multi-purpose additive for Otto engine fuels 100 ML
# 17
MPN: 00004320902
Multi-purpose additive for Otto engine fuels 100 ML
from £10.04
from £10.04
