porsche 2011 (987 boxster) disc brake front axle parts diagram

602-000 - Disc Brake Front Axle

Porsche 2011 (987 Boxster) Disc brake Front axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # -
          -
          BRAKE DISC (USE IN PAIRS ONLY) SEE TECHNICAL MANUAL
          P450 (Ceramic brake (PCCB))
          # 1
          MPN: 99635140501
          BRAKE DISC LEFT FRONT ALSO USE: 1X 000 043 305 08 1X 996 351 406 01 4X 900 269 047 01 1X 997 351 939 07 1X 997 612 756 01 1X 997 612 759 01 1X 955 352 960 00 4X 999 073 402 01
          from £274.40
          from £274.40
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 99735103100
          BRAKE DISC left front
          BRAKE DISC left front
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 99735103101
          BRAKE DISC left front
          P450 (Ceramic brake (PCCB))
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 98135103101
          Brake disc left front also use: 1X 000 043 305 08 1X 981 351 032 01 1X 997 351 948 03 1X 997 612 675 02 1X 997 612 679 01 1X 996 351 959 30 4X 999 067 053 09
          P450 (Ceramic brake (PCCB))
          from £4,335.82
          from £4,335.82
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 99635140601
          brake disc right front
          from £274.40
          from £274.40
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 99735103200
          brake disc right front
          brake disc right front
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 1
          MPN: 99735103201
          brake disc right front
          P450 (Ceramic brake (PCCB))
          BRAKE DISC Genuine Porsche Part - New (to order)
          # 2
          MPN: 90026904701
          countersunk bolt M 6 X 12
          from £0.59
          from £0.59
          This part replaces part number 90026904709
          SCREW, COUNTERSUNK HD. - M 6 X 12 - D - MJ 2004>> Genuine Porsche Part - New In stock
          # 3
          MPN: 99735180102
          COVER PLATE LEFT
          from £29.42
          from £29.42
          COVER PLATE Genuine Porsche Part - New (to order)
          # 3
          MPN: 99735180202
          COVER PLATE RIGHT
          from £29.42
          from £29.42
          COVER PLATE Genuine Porsche Part - New (to order)
          # 3
          MPN: 99735180505
          COVER PLATE LEFT
          P450 (Ceramic brake (PCCB))
          from £29.42
          from £29.42
          COVER PLATE Genuine Porsche Part - New (to order)
          # 3
          MPN: 99735180605
          COVER PLATE RIGHT
          P450 (Ceramic brake (PCCB))
          from £29.42
          from £29.42
          COVER PLATE Genuine Porsche Part - New (to order)
          # 4
          MPN: 99921711601
          HEXAGON BOLT M 6 X 16
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 5
          MPN: 99735142100
          caliper without brake pads left
          Boxster
          from £795.24
          from £795.24
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 5
          MPN: 99635142511
          caliper without brake pads left
          BOXSTER S, SPYDER
          from £747.05
          from £747.05
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 5
          MPN: 99635143131
          caliper without brake pads left
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £1,153.82
          from £1,153.82
          This part replaces part number 99635143130
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 5
          MPN: 99735142200
          caliper without brake pads right
          Boxster
          from £795.24
          from £795.24
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 5
          MPN: 99635142611
          caliper without brake pads right
          BOXSTER S, SPYDER
          from £747.05
          from £747.05
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 5
          MPN: 99635143231
          caliper without brake pads right
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £1,153.82
          from £1,153.82
          CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
          # 6
          MPN: 99735193905
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE
          Boxster
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 99735193906
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE ALSO USE: FASTENERS D >>- MJ 2009
          Boxster S
          from £143.10
          from £143.10
          1 SET OF BRAKE PADS FOR DISC Genuine Porsche Part - New (to order)
          # 6
          MPN: 99735193908
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE FRONT AXLE ALSO USE: FASTENERS
          Boxster S
          from £204.76
          from £204.76
          1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
          # 6
          MPN: 99735193906
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE ALSO USE: FASTENERS
          SPYDER
          from £143.10
          from £143.10
          1 SET OF BRAKE PADS FOR DISC Genuine Porsche Part - New (to order)
          # 6
          MPN: 99735193908
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE FRONT AXLE ALSO USE: FASTENERS
          SPYDER
          from £204.76
          from £204.76
          1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
          # 6
          MPN: 99735193905
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE ALSO USE: FASTENERS D - MJ 2010>>
          Boxster S
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 99735193907
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE ALSO USE: FASTENERS D - MJ 2010>>
          Boxster S
          from £185.96
          from £185.96
          This part replaces part number 99735193905
          1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New In stock
          # 6
          MPN: 99735194801
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE 1X ALSO USE: FASTENERS
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 99735194803
          1 SET OF BRAKE PADS FOR FRONT DISK BRAKE 1X ALSO USE: FASTENERS
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £609.94
          from £609.94
          This part replaces part number 99735194801
          1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
          # 6
          MPN: 99635108802
          DAMPING PLATE BRAKE STEEL
          BOXSTER, BOXSTER S, SPYDER
          from £11.24
          from £11.24
          DAMPING PLATE Genuine Porsche Part - New (to order)
          # 7
          MPN: 99761275600
          SENDER WIRE LEFT (PAD WEAR INDICATOR)
          BOXSTER, BOXSTER S, SPYDER
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 7
          MPN: 99761275900
          SENDER WIRE RIGHT (PAD WEAR INDICATOR)
          BOXSTER, BOXSTER S, SPYDER
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 7
          MPN: 99761267501
          SENDER WIRE LEFT (PAD WEAR INDICATOR)
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £30.35
          from £30.35
          SENDER WIRE Genuine Porsche Part - New (to order)
          # 7
          MPN: 99761267900
          SENDER WIRE RIGHT (PAD WEAR INDICATOR)
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £30.35
          from £30.35
          SENDER WIRE Genuine Porsche Part - New (to order)
          # 8
          MPN: 99907340201
          SOCKET HEAD BOLT M 12 X 1,5 X 72
          BOXSTER, BOXSTER S, SPYDER
          from £4.52
          from £4.52
          SCREW, CHEESE HD Genuine Porsche Part - New (to order)
          # 8
          MPN: 99906705309
          SOCKET HEAD BOLT M 12 X 1;5 X 85
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 8
          MPN: 94461262700
          LINE HOLDER FOR SENDER WIRE (PAD WEAR INDICATOR)
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 10
          MPN: 99635196130
          connecting line
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £39.98
          from £39.98
          Connecting line - D - MJ 2004>> Genuine Porsche Part - New (to order)
          # 11
          MPN: 93035191900
          BREATHER VALVE
          from £13.16
          from £13.16
          bleeder valve - with: - dust cap Genuine Porsche Part - New (to order)
          # 12
          MPN: 93035192700
          DUST CAP
          DUST CAP
          dust cap - Discontinued part Genuine Porsche Part - New (to order)
          # 12
          MPN: 93035192701
          DUST CAP
          from £1.73
          from £1.73
          DUST CAP Genuine Porsche Part - New (to order)
          # 13
          MPN: 95135191701
          REPAIR SET PROTECTIVE CAP 40 MM $
          BOXSTER, BOXSTER S, SPYDER
          from £20.05
          from £20.05
          repair kit Genuine Porsche Part - New (to order)
          # 13
          MPN: 99635191501
          REPAIR SET PROTECTIVE CAP 38 MM $
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 14
          MPN: 95135191700
          REPAIR SET PROTECTIVE CAP 36 MM $
          BOXSTER, BOXSTER S, SPYDER
          from £20.05
          from £20.05
          repair kit - Protection caps - 36 MM $ - D >> - MJ 2002 Genuine Porsche Part - New (to order)
          # 14
          MPN: 99635191500
          REPAIR SET PROTECTIVE CAP 32 MM $
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £13.98
          from £13.98
          repair kit - Protection caps - 32 MM $ - D - MJ 2004>> Genuine Porsche Part - New (to order)
          # 15
          MPN: 95535296000
          REPAIR SET FOR REAR AXLE FASTENERS COMPRISING: PIN 2X CUP EXPANDER SPRING 2X SECURING BARS 2X
          BOXSTER, BOXSTER S, SPYDER
          from £44.78
          from £44.78
          Clip & pin repair set Genuine Porsche Part - New (to order)
          # 15
          MPN: 99635195930
          repair set Fasteners comprising: Pin 2X Cup expander spring 2X Fastening screw 2X
          BOXSTER S, SPYDER, P450 (Ceramic brake (PCCB))
          from £54.54
          from £54.54
          repair kit - fasteners - pin - screw - speader spring - D - MJ 2004>> Genuine Porsche Part - New (to order)
          # 16
          MPN: 00004311700
          BRAKE CYLINDER PASTE 50 G
          brake cylinder paste - Discontinued part Genuine Porsche Part - New (to order)
          # 16
          MPN: 00004302000
          ASSEMBLY PASTE 100 G
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
