A120 (2.9 Litre 6 Cyliner Engine (255 Horsepower / 188 Kilowatt with Engine Code: A120 and installed 08/2008-05/2012) | A121 (3.4 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: A121 and installed 08/2008-05/2012) A121 (3.4 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: A121 and installed 08/2010-05/2012)
porsche 2012 (987 boxster) air filter parts diagram

106-000 - AIR FILTER

Porsche 2012 (987 Boxster) Air filter Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Key
                                Price
                                # 1
                                MPN: 98711002130
                                AIR FILTER
                                from £564.95
                                from £564.95
                                AIR CLEANER Genuine Porsche Part - New (to order)
                                # 2
                                MPN: 98711012200
                                INTAKE MANIFOLD
                                from £25.97
                                from £25.97
                                INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                # 3
                                MPN: 98711013100
                                HOUSING COVER
                                from £43.13
                                from £43.13
                                HOUSING COVER Genuine Porsche Part - New (to order)
                                # 4
                                MPN: 99950744209
                                PANEL NUT
                                from £1.06
                                from £1.06
                                SPEED NUT Genuine Porsche Part - New (to order)
                                # 5
                                MPN: 99907337901
                                PANEL SCREW
                                from £1.04
                                from £1.04
                                TAPPING SCREW Genuine Porsche Part - New (to order)
                                # 6
                                MPN: 98711014100
                                GROMMET
                                from £4.72
                                from £4.72
                                GROMMET Genuine Porsche Part - New (to order)
                                # 7
                                MPN: 99311011601
                                ANGLED BRACKET
                                from £3.49
                                from £3.49
                                BRACKET - ADAPTER - AIR CLEANER Genuine Porsche Part - New (to order)
                                # 8
                                MPN: 98711013300
                                AIR FILTER ELEMENT
                                AIR FILTER ELEMENT
                                Supersession
                                Supersession
                                Genuine Porsche Part (no longer available to order)
                                # 8
                                MPN: 98711013301
                                AIR FILTER ELEMENT
                                from £33.60
                                from £33.60
                                This part replaces part number 98711013300
                                AIR FILTER Genuine Porsche Part - New (to order)
                                AIR FILTER Bosch Original Parts - New In stock
                                # 9
                                MPN: 98711013400
                                SECURING PLATE
                                from £17.97
                                from £17.97
                                SECURING PLATE Genuine Porsche Part - New (to order)
                                # 10
                                MPN: 90009509909
                                SPRING PIN 12 X 14
                                from £1.97
                                from £1.97
                                PIN Genuine Porsche Part - New (to order)
                                # 11
                                MPN: 99991905009
                                FILLISTER HD. BOLT 4 X 12
                                from £0.78
                                from £0.78
                                FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
                                # 12
                                MPN: 90007533301
                                BOLT WITH WASHER M 6 X 25
                                from £9.41
                                from £9.41
                                Bolt with washer - M 6 X 25 Z2 Genuine Porsche Part - New (to order)
                                # 13
                                MPN: 99970705241
                                O-RING 91 X 6
                                from £12.16
                                from £12.16
                                O-RING - 91 X 6 - ADAPTER - AIR CLEANER Genuine Porsche Part - New (to order)
                                # 14
                                MPN: 98760616501
                                AIR MASS METER
                                AIR MASS METER
                                MASS AIR FLOW SENSOR Genuine Porsche Part - New (to order)
                                # 14
                                MPN: 98760616502
                                AIR MASS METER
                                from £607.01
                                from £607.01
                                MASS AIR FLOW SENSOR Genuine Porsche Part - New (to order)
                                # 15
                                MPN: 99951254200
                                HOSE CLAMP 80 - 100
                                from £5.33
                                from £5.33
                                Hose Clamp - 80 - 100/9 Genuine Porsche Part - New (to order)
                                # 16
                                MPN: 98711027030
                                AIR GUIDE
                                from £45.50
                                from £45.50
                                AIR DUCT Genuine Porsche Part - New (to order)
                                # 17
                                MPN: 99951262900
                                HOSE CLAMP 90 - 110
                                from £4.16
                                from £4.16
                                Hose Clamp - 90 - 100/9 Genuine Porsche Part - New (to order)
