porsche 2016 (981 boxster spyder) drive shaft parts diagram

501-005 - DRIVE SHAFT

Porsche 2016 (981 Boxster Spyder) Drive shaft Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 98133202410
                DRIVE SHAFT LEFT
                P480 (6-speed manual transmission)
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 1
                MPN: 98133202430
                DRIVE SHAFT RIGHT
                P480 (6-speed manual transmission)
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 2
                MPN: 99951004701
                SOCKET HEAD BOLT M10X46,5
                from £2.29
                from £2.29
                SCREW, CHEESE HD Genuine Porsche Part - New In stock
                # 3
                MPN: 9P1501375
                SPACER
                from £4.86
                from £4.86
                PLATE Genuine Porsche Part - New In stock
                # 4
                MPN: 99633295700
                TERMINAL
                from £7.38
                from £7.38
                CLIP - $ 73 MM Genuine Porsche Part - New (to order)
                # 5
                MPN: 90004101400
                SECURING RING 28X1,5
                P480 (6-speed manual transmission)
                from £2.29
                from £2.29
                lock ring - D - MJ 2000>> Genuine Porsche Part - New (to order)
                # 6
                MPN: WHT007021
                HEX. NUT, SELF-LOCKING WITH M22X1.5 WASHER
                from £6.68
                from £6.68
                HEX. NUT, SELF-LOCKING WITH WASHER, M22 X 1.5 Genuine Porsche Part - New (to order)
                HEX. NUT, SELF-LOCKING WITH WASHER Genuine Bentley Part - New (to order)
                # 7
                MPN: 00004311001
                HIGH TEMPERATURE GREASE 100 GRAM 1 TUBE
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 7
                MPN: 00004321008
                SEALANT 100 GRAM DRIVE SHAFT
                from £58.37
                from £58.37
                This part replaces part number 00004320536
                SEALANT Genuine Porsche Part - New In stock
                # 8
                MPN: 99733226700
                END CAP
                P480 (6-speed manual transmission)
                from £13.52
                from £13.52
                SEALING CAP Genuine Porsche Part - New (to order)
                # 9
                MPN: 99133203000
                CONSTANT VELOCITY JOINT
                P480 (6-speed manual transmission)
                from £246.44
                from £246.44
                CONSTANT VELOCITY JOINT Genuine Porsche Part - New (to order)
                # 10
                MPN: 99733295500
                BELLOWS INCLUDED CAP
                P480 (6-speed manual transmission)
                from £45.49
                from £45.49
                BELLOWS Genuine Porsche Part - New (to order)
                # 11
                MPN: 99633229300
                BELLOWS
                from £34.16
                from £34.16
                BELLOWS Genuine Porsche Part - New In stock
                # 12
                MPN: 99633225700
                TERMINAL
                from £2.05
                from £2.05
                clip - $ 41,5 MM Genuine Porsche Part - New (to order)
