P006 (Boxster/Cayman GTS 4.0)
porsche 2018 (718 boxster) bumper rear gts 4.0 parts diagram

802-025 - bumper rear GTS 4.0

Porsche 2018 (718 Boxster) bumper rear GTS 4.0 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 982898352K G2X
                          TRIM REAR - PRIMED
                          P638 (ParkAssist, front, rear and reversing camera)
                          from £798.00
                          from £798.00
                          TRIM PRIMED Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 982898352J G2X
                          TRIM REAR - PRIMED
                          P638 (ParkAssist, front, rear and reversing camera) without 553
                          from £755.71
                          from £755.71
                          TRIM PRIMED Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 982898352H G2X
                          TRIM REAR - PRIMED
                          P635 (Rear ParkAssist) | P536 (Alarm siren) | P without, P553 (Version for USA, Canada)
                          from £744.83
                          from £744.83
                          TRIM PRIMED Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 982807442 G2X
                          COVER FOR TOWING EYE - PRIMED
                          from £20.53
                          from £20.53
                          This part replaces part number 982807442
                          COVER FOR TOWING EYE (PR:-553) primed Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 982807417 OK1
                          COVER REAR UPPER - MATT BLACK
                          from £62.78
                          from £62.78
                          This part replaces part number 982807417
                          MATT BLACK Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 982807659 041
                          TRIM UPPER REAR INSCRIPTION CHROME - BLACK
                          P without 519
                          Supersession
                          Supersession
                          This part replaces part number 982807659
                          Genuine Porsche Part (no longer available to order)
                          # 4
                          MPN: 982807659A 041
                          Trim upper rear inscription black - Black
                          Trim upper rear inscription black - Black
                          from £177.36
                          from £177.36
                          This part replaces part number 982807659A
                          TRIM rear, upper - inscription black (PR:519) Black Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 982807659C 041
                          Trim upper rear inscription black - Black
                          P519 (Porsche logo in Black)
                          from £185.71
                          from £185.71
                          TRIM BLACK Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 982807983F G2X
                          COVER LOWER REAR - PRIMED
                          from £432.91
                          from £432.91
                          COVER PRIMED Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 982807125D OK1
                          BRACKET LOWER REAR - MATT BLACK
                          from £199.49
                          from £199.49
                          BRACKET MATT BLACK Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 99150589901OK1
                          BRACKET REVERSING CAMERA - MATT BLACK
                          P638 (ParkAssist, front, rear and reversing camera)
                          from £13.68
                          from £13.68
                          This part replaces part number 99150589901
                          BRACKET rear view camera (PR:638) matt black Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 99150590101
                          arm Reversing camera
                          P638 (ParkAssist, front, rear and reversing camera)
                          from £13.07
                          from £13.07
                          BOW Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 5Q0919275B G2X
                          SENSOR OUTER PARKING AID - PRIMED
                          from £104.43
                          from £104.43
                          This part replaces part number 5Q0919275 G2X which we have in stock - and 1 more. Click to view details
                          SENSOR inner - parking assist Primed Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 5Q0919275C G2X
                          SENSOR INNER PARKING AID - PRIMED
                          from £108.51
                          from £108.51
                          This part replaces part number 5Q0919275C
                          SENSOR outer parking assist (PR-7X2,7X8, 8A4) primed Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 5Q0919133 9B9
                          SEAL RING ULTRASOUND SENSOR PARKING AID - SATIN BLACK
                          from £0.64
                          from £0.64
                          This part replaces part number 5Q0919133
                          SEAL RING parking assist -Timing and Impulse Sensors (PR-7X2,7X8, 8A4) Genuine Porsche Part - New In stock
                          GASKET Genuine Lamborghini - New In stock
                          # 11
                          MPN: 982807833A OK1
                          TRIM FOR EXHAUST TAIL PIPE LEFT - MATT BLACK
                          from £76.75
                          from £76.75
                          TRIM FOR EXHAUST TAIL PIPE MATT BLACK Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 982807834A OK1
                          TRIM FOR EXHAUST TAIL PIPE RIGHT - MATT BLACK
                          from £76.75
                          from £76.75
                          TRIM FOR EXHAUST TAIL PIPE MATT BLACK Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 99950769600
                          U-CLIP 1,20-1,70
                          from £0.59
                          from £0.59
                          U-CLIP Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 99991924601
                          FILLISTER HD. BOLT 6,0X18,0-Q
                          from £6.90
                          from £6.90
                          FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
                          # 14
                          MPN: 99950785601
                          PANEL NUT M6
                          from £0.80
                          from £0.80
                          SPEED NUT Genuine Porsche Part - New (to order)
                          # 15
                          MPN: 99970327240
                          STOP BUFFER 5,0X8X13,0
                          from £2.14
                          from £2.14
                          JOUNCE BUMPER Genuine Porsche Part - New (to order)
                          # 16
                          MPN: 99970350340
                          STOP BUFFER 6,0X11,5X14
                          from £0.80
                          from £0.80
                          JOUNCE BUMPER Genuine Porsche Part - New (to order)
                          # 18
                          MPN: 9P1807287
                          LICENCE PLATE HOLDER REAR
                          P209 (Licence plate holder version 1)
                          from £111.18
                          from £111.18
                          LICENCE PLATE HOLDER Genuine Porsche Part - New (to order)
                          # 19
                          MPN: 9A700788200
                          Oval-head screw TP5X13
                          P209 (Licence plate holder version 1)
                          from £1.82
                          from £1.82
                          OVAL-HEAD SCREW Genuine Porsche Part - New (to order)
