022Y (3.2 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: 022Y and installed 05/2003-05/2006)
porsche 2004 (cayenne e1 9pa) secondary air pump d - mj 2004>> parts diagram

108-003 - SECONDARY AIR PUMP D - MJ 2004>>

Porsche 2004 (Cayenne E1 9PA) Secondary air pump D - MJ 2004>> Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                    #
                                    Part number
                                    Description
                                    Key
                                    Price
                                    # 1
                                    MPN: 95560560100
                                    Secondary Air Pump
                                    Supersession
                                    Supersession
                                    Genuine Porsche Part (no longer available to order)
                                    # 2
                                    MPN: 95511356700
                                    STOP BUFFER
                                    JOUNCE BUMPER Genuine Porsche Part - New (to order)
                                    # 3
                                    MPN: 95511328700
                                    BRACKET SECONDARY AIR PUMP
                                    from £30.28
                                    from £30.28
                                    BRACKET Genuine Porsche Part - New (to order)
                                    # 4
                                    MPN: N 01508213
                                    HEXAGON COLLAR NUT M6
                                    from £0.47
                                    from £0.47
                                    shouldered hex. nut Genuine Porsche Part - New In stock
                                    Genuine Bentley Part (no longer available to order)
                                    HEXAGON FLANGE NUT M6 Genuine Lamborghini - New In stock
                                    # 5
                                    MPN: 95511066900
                                    GROMMET
                                    from £3.32
                                    from £3.32
                                    GROMMET Genuine Porsche Part - New (to order)
                                    # 6
                                    MPN: 95511073400
                                    SPACER BUSH
                                    from £2.07
                                    from £2.07
                                    SPACER BUSHING Genuine Porsche Part - New (to order)
                                    # 7
                                    MPN: N 10528401
                                    HEX COLLARED BOLT M6X30 D >>- MJ 2005
                                    from £0.47
                                    from £0.47
                                    BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                    Genuine Bentley Part (no longer available to order)
                                    # 7
                                    MPN: N 10528402
                                    HEX COLLARED BOLT M6X30 D - MJ 2006>>
                                    from £0.47
                                    from £0.47
                                    BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                    HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                                    # 8
                                    MPN: 95511334300
                                    AIR FILTER WITH: INTAKE HOSE
                                    P1BK (Air suspension with levelling system and height adjustment (PASM))
                                    from £62.11
                                    from £62.11
                                    AIR CLEANER Genuine Porsche Part - New (to order)
                                    # 8
                                    MPN: 95511334310
                                    AIR FILTER WITH: INTAKE HOSE
                                    P1BA (Suspension/dampers, standard)
                                    from £62.11
                                    from £62.11
                                    AIR CLEANER Genuine Porsche Part - New (to order)
                                    # 9
                                    MPN: N 10157902
                                    HEXAGON BOLT M6X25
                                    from £0.72
                                    from £0.72
                                    SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                    SET SCREW M5X35MM LONG Genuine Bentley Part - New (to order)
                                    # 10
                                    MPN: 95511362600
                                    CONNECTING HOSE
                                    from £57.72
                                    from £57.72
                                    CONNECTING HOSE Genuine Porsche Part - New (to order)
                                    # 11
                                    MPN: N 90860201
                                    HOSE BRACKET B21
                                    from £1.58
                                    from £1.58
                                    BRACKET FOR HOSE Genuine Porsche Part - New (to order)
                                    # 12
                                    MPN: 95511311900
                                    ADAPTER
                                    from £29.14
                                    from £29.14
                                    ADAPTER Genuine Porsche Part - New (to order)
                                    # 13
                                    MPN: N 01470210
                                    SOCKET HEAD BOLT WITH M6X15 HEXAGON SOCKET HEAD D >>- MJ 2005
                                    from £0.47
                                    from £0.47
                                    BOLT, WITH HEX. SOCKET Genuine Porsche Part - New (to order)
                                    Genuine Bentley Part (no longer available to order)
                                    # 13
                                    MPN: N 10124408
                                    Hexagon socket head M6X20 bolt (combi) D - MJ 2006>>
                                    from £1.12
                                    from £1.12
                                    hexagon socket head Genuine Porsche Part - New (to order)
                                    HEXAGON SOCKET HEAD BOLT (COMBI) Genuine Bentley Part - New (to order)
                                    # 14
                                    MPN: 95511312000
                                    SEAL D >>- MJ 2005
                                    from £1.07
                                    from £1.07
                                    GASKET Genuine Porsche Part - New (to order)
                                    # 14
                                    MPN: 95511312001
                                    SEAL D - MJ 2006>>
                                    from £4.88
                                    from £4.88
                                    GASKET Genuine Porsche Part - New (to order)
                                    # 15
                                    MPN: 95511310100
                                    CUT-OFF VALVE
                                    CUT-OFF VALVE
                                    CUT-OFF VALVE Genuine Porsche Part - New (to order)
                                    # 15
                                    MPN: 95511310120
                                    CUT-OFF VALVE D >>- MJ 2005
                                    CUT-OFF VALVE Genuine Porsche Part - New (to order)
                                    # 15
                                    MPN: 95511310121
                                    CUT-OFF VALVE D - MJ 2006>>
                                    from £87.84
                                    from £87.84
                                    CUT-OFF VALVE Genuine Porsche Part - New (to order)
                                    # 16
                                    MPN: 95511312010
                                    SEAL
                                    from £7.38
                                    from £7.38
                                    GASKET Genuine Porsche Part - New (to order)
                                    # 17
                                    MPN: N 90500601
                                    SOCKET HEAD BOLT WITH M6X22 INNER MULTIPOINT HEAD D >>- MJ 2005
                                    from £1.78
                                    from £1.78
                                    SOCKET HD. SCREW WITH Genuine Porsche Part - New (to order)
                                    Genuine Bentley Part (no longer available to order)
                                    # 17
                                    MPN: N 91071701
                                    Hexagon socket flat M6X25 head bolt D - MJ 2006>>
                                    from £0.95
                                    from £0.95
                                    HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                    SCREW Genuine Lamborghini - New In stock
                                    # 18
                                    -
                                    VACUUM HOSE SEE ILLUSTRATION: 107-002
                                    # 19
                                    MPN: N 90263104
                                    RIVETTED CAP NUT M6/0,7-3
                                    from £0.79
                                    from £0.79
                                    RIVETTED CAP NUT Genuine Porsche Part - New (to order)
                                    RIVETTED CAP NUT Genuine Bentley Part - New (to order)
                                    RIVETTED CAP NUT Genuine Lamborghini - New (to order)
