P0AW (Front and rear anti-roll bars with active Body control -PDCC-)
porsche 2008 (cayenne e1 9pa) anti-roll bar valve block junction pressure line parts diagram

402-007 - Anti-roll bar Valve block Junction Pressure line

Porsche 2008 (Cayenne E1 9PA) Anti-roll bar Valve block Junction Pressure line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 95535903000
                        VALVE BLOCK
                        VALVE BLOCK
                        VALVE BLOCK Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 95535903001
                        VALVE BLOCK
                        VALVE BLOCK
                        VALVE BLOCK Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 95835903000
                        VALVE BLOCK
                        VALVE BLOCK
                        VALVE BLOCK Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 95835903001
                        VALVE BLOCK
                        from £914.96
                        from £914.96
                        VALVE BLOCK Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 95561221400
                        WIRE SET
                        from £93.74
                        from £93.74
                        harness Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 96435663500
                        RUBBER BUSH
                        from £8.77
                        from £8.77
                        rubber isolator - D - MJ 2004>> Genuine Porsche Part - New (to order)
                        # 4
                        MPN: 95534363300
                        BEARING BUSH
                        from £1.65
                        from £1.65
                        BUSHING Genuine Porsche Part - New (to order)
                        # 5
                        MPN: N 90263104
                        RIVETTED CAP NUT M 6
                        from £0.79
                        from £0.79
                        RIVETTED CAP NUT Genuine Porsche Part - New (to order)
                        RIVETTED CAP NUT Genuine Bentley Part - New (to order)
                        RIVETTED CAP NUT Genuine Lamborghini - New (to order)
                        # 6
                        MPN: 96435663500
                        RUBBER BUSH
                        from £8.77
                        from £8.77
                        rubber isolator - D - MJ 2004>> Genuine Porsche Part - New (to order)
                        # 7
                        MPN: N 10699801
                        HEXAGON HEAD BOLT (COMBI) M 6 X 35
                        from £1.10
                        from £1.10
                        BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95535911500
                        PRESSURE LINE D >>- MJ 2008
                        PRESSURE LINE D >>- MJ 2008
                        PRESSURE LINE Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95535911501
                        PRESSURE LINE D - MJ 2009>>
                        PRESSURE LINE Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95535911500
                        Pressure line without: Shrinkable hose, waterproof weldable also use: N 107 225 01 D >>- MJ 2008
                        Pressure line without: Shrinkable hose, waterproof weldable also use: N 107 225 01 D >>- MJ 2008
                        PRESSURE LINE Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95535911501
                        Pressure line without: Shrinkable hose, waterproof weldable also use: N 107 225 01
                        Pressure line without: Shrinkable hose, waterproof weldable also use: N 107 225 01
                        PRESSURE LINE Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95535911502
                        PRESSURE LINE WITH: SHRINKABLE HOSE, WATERPROOF WELDABLE ALSO USE: N 107 623 01
                        from £119.76
                        from £119.76
                        PRESSURE LINE Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 95535911600
                        RETURN LINE D >>- MJ 2008
                        RETURN LINE Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 95535911601
                        return line D - MJ 2009>>
                        return line D - MJ 2009>>
                        RETURN LINE Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 95535911602
                        return line D - MJ 2009>>
                        from £80.27
                        from £80.27
                        RETURN LINE Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 95535923100
                        Junction alternatively, you can use: 955.359.231.01 1x 955.359.125.02 1x 955.359.125.12 1x D >>- MJ 2008
                        Junction alternatively, you can use: 955.359.231.01 1x 955.359.125.02 1x 955.359.125.12 1x D >>- MJ 2008
                        from £56.51
                        from £56.51
                        DISTRIBUTOR Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 95535923101
                        JUNCTION D - MJ 2009>>
                        from £147.52
                        from £147.52
                        DISTRIBUTOR Genuine Porsche Part - New (to order)
                        # 11
                        MPN: N 90440706
                        HEXAGON BOLT M 6 X 15
                        from £0.96
                        from £0.96
                        SCREW, HEX. HD Genuine Porsche Part - New (to order)
                        HEXAGON BOLT Genuine Bentley Part - New (to order)
                        SCREW Genuine Lamborghini - New (to order)
                        # 12
                        MPN: N 10722401
                        DISTANCE PIECE
                        from £2.38
                        from £2.38
                        SPACER Genuine Porsche Part - New (to order)
                        # 13
                        MPN: N 10722501
                        DISTANCE PIECE 10,5 MM FOR PRESSURE LINE WITHOUT: SHRINKABLE HOSE, WATERPROOF WELDABLE
                        from £11.77
                        from £11.77
                        SPACER Genuine Porsche Part - New (to order)
                        SPINED SLEEVE B10.5X22.5X30 Genuine Lamborghini - New (to order)
                        # 13
                        MPN: N 10762301
                        TOOTHED LOCK WASHER 11,5 MM FOR PRESSURE LINE WITH: SHRINKABLE HOSE, WATERPROOF WELDABLE
                        from £5.43
                        from £5.43
                        RING Genuine Porsche Part - New (to order)
                        SPLINED SLEEVE Genuine Lamborghini - New (to order)
                        # 16
                        -
                        PRESSURE LINE SEE ILLUSTRATION: 402-008
                        # 16
                        -
                        PRESSURE LINE
                        see illustration: 402-008
                        # 14
                        MPN: 95535951000
                        LINE HOLDER
                        from £5.87
                        from £5.87
                        LINE HOLDER Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 95535951300
                        LINE HOLDER
                        from £9.71
                        from £9.71
                        LINE HOLDER Genuine Porsche Part - New (to order)
