A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16) | A7010 (8A Gearbox with Transmission Code: A7010 and installed 05/11-05/16) | A7011 (8A Gearbox with Transmission Code: A7011 and installed 05/13-05/16)
porsche 2010 (cayenne e1 9pa) tiptronic gearbox accessories parts diagram

320-015 - Tiptronic Gearbox Accessories

Porsche 2010 (Cayenne E1 9PA) Tiptronic Gearbox Accessories Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 95830154750
              BREATHER LINE 425 MM
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £38.46
              from £38.46
              breather line Genuine Porsche Part - New (to order)
              # 1
              MPN: 0C8301047H
              BREATHER LINE 175 MM
              A7010 (8A Gearbox with Transmission Code: A7010 and installed 05/11-05/16) | A7011 (8A Gearbox with Transmission Code: A7011 and installed 05/13-05/16)
              from £21.00
              from £21.00
              breather line Genuine Porsche Part - New (to order)
              # 2
              MPN: 99950719840
              HOSE BRACKET 13 / 19
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £2.62
              from £2.62
              BRACKET FOR HOSE Genuine Porsche Part - New (to order)
              # 3
              MPN: 95831756300
              CLAMP
              from £5.50
              from £5.50
              CLAMP Genuine Porsche Part - New (to order)
              # 4
              MPN: 95830138100
              CONNECTION PIECE
              from £16.18
              from £16.18
              ADAPTER Genuine Porsche Part - New (to order)
              # 5
              MPN: 95530157700
              O-RING 8,2 X 1,9
              from £6.40
              from £6.40
              O-RING Genuine Porsche Part - New (to order)
              # 6
              MPN: 95530156501
              CLIP
              from £0.99
              from £0.99
              CLIP Genuine Porsche Part - New (to order)
              # 7
              MPN: 97032145105
              GUARD PLATE
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £18.30
              from £18.30
              SHIELD Genuine Porsche Part - New (to order)
              # 8
              MPN: N 10082911
              HEXAGON HEAD BOLT (COMBI) M 6 X 16
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £0.53
              from £0.53
              BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
              HEXAGON HEAD BOLT M6X16-S1-N Genuine Lamborghini - New In stock
              # 9
              MPN: 95830130700
              GUARD PLATE
              from £26.69
              from £26.69
              SHIELD Genuine Porsche Part - New (to order)
              # 10
              MPN: N 10082911
              HEXAGON HEAD BOLT (COMBI) M 6 X 16
              from £0.53
              from £0.53
              BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
              HEXAGON HEAD BOLT M6X16-S1-N Genuine Lamborghini - New In stock
              # 11
              MPN: 95830154760
              BREATHER LINE 870 MM F >>97-FL040 943 F >>97-FL040 941
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £34.45
              from £34.45
              breather line Genuine Porsche Part - New (to order)
              # 11
              MPN: 95830154770
              BREATHER LINE 1220 MM F 97-FL040 944>>F 97-FL040 942>>
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £22.03
              from £22.03
              breather line Genuine Porsche Part - New (to order)
              # 12
              MPN: 95831756310
              CLAMP
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £3.01
              from £3.01
              CLAMP Genuine Porsche Part - New (to order)
              # 13
              MPN: 95830182100
              HEAT INSULATION BREATHER LINE
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £5.74
              from £5.74
              heat deflector Genuine Porsche Part - New (to order)
              # 14
              MPN: N 0206207
              CLAMP 13 X 15
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £2.04
              from £2.04
              CLAMP Genuine Porsche Part - New (to order)
              # 15
              MPN: N 10632003
              OVAL SOCKET HEAD BOLT WITH HEX DRIVE M 6 X 16
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £0.47
              from £0.47
              oval socket head bolt Genuine Porsche Part - New (to order)
              HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New In stock
              # 16
              MPN: N 10427801
              DOUBLE CLIP A 01-10 X C01-16 F >>97-FL040 943 F >>97-FL040 941
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £2.12
              from £2.12
              DOUBLE CLIP Genuine Porsche Part - New (to order)
              # 16
              MPN: N 10458502
              LINE HOLDER A 01-18 X C01-9,5 F 97-FL040 944>>F 97-FL040 942>>
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £1.15
              from £1.15
              LINE HOLDER Genuine Porsche Part - New (to order)
              # 16
              MPN: 8E0971818B
              CABLE TIES 4,5 X 210 F 97-FL040 944>>F 97-FL040 942>>
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £1.23
              from £1.23
              TIE WRAP Genuine Porsche Part - New (to order)
              CABLE TIE B4.5-4.7X210 Genuine Lamborghini - New (to order)
              # 17
              MPN: 97066061200
              HEAT INSULATION
              HEAT INSULATION
              heat deflector Genuine Porsche Part - New (to order)
              # 17
              MPN: 97066061201
              HEAT INSULATION
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £25.87
              from £25.87
              heat deflector Genuine Porsche Part - New (to order)
              # 18
              MPN: 99959114201
              CABLE FASTENER
              A7000 (8A Gearbox with Transmission Code: A7000 and installed 05/11-05/16)
              from £0.65
              from £0.65
              CABLE FASTENER Genuine Porsche Part - New (to order)
