PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo) | P0AW (Front and rear anti-roll bars with active Body control -PDCC-)
porsche 2010 (cayenne e1 9pa) power steering pressure line oil container further genuine parts for this assembly group/model see illustration: 403-001 parts diagram

403-010 - Power steering Pressure line oil container further genuine parts for this assembly group/model see illustration: 403-001

Porsche 2010 (Cayenne E1 9PA) Power steering Pressure line oil container further genuine parts for this assembly group/model see illustration: 403-001 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # 1
                                      MPN: 95534745130
                                      PRESSURE LINE LHD STEERING GEAR TANDEM VANE PUMP
                                      PL0L (Left-hand drive version)
                                      from £214.78
                                      from £214.78
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: 95534745240
                                      PRESSURE LINE RHD STEERING GEAR TANDEM VANE PUMP
                                      PL0R (Right-hand drive version)
                                      from £131.24
                                      from £131.24
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: N 10727801
                                      DISTANCE PIECE RHD FOR PRESSURE LINE
                                      PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo) | PL0R (Right-hand drive version)
                                      from £1.51
                                      from £1.51
                                      SPACER Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 95534754200
                                      O-RING 9,25 X 1,78
                                      from £4.10
                                      from £4.10
                                      O-RING Genuine Porsche Part - New (to order)
                                      # 3
                                      MPN: 95534754300
                                      O-RING 7,65 X 1,63
                                      from £4.10
                                      from £4.10
                                      O-RING Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: N 0206515
                                      CLAMP 10 X 15 D >>- MJ 2008
                                      CLAMP Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: N 0206517
                                      Clamp 10 X 15 D - MJ 2009>>
                                      from £0.88
                                      from £0.88
                                      CLAMP Genuine Porsche Part - New (to order)
                                      CLAMP Genuine Bentley Part - New (to order)
                                      HOLDING CLIP Genuine Lamborghini - New In stock
                                      # 5
                                      MPN: N 10156307
                                      HEX COLLARED BOLT M 6 X 12
                                      from £0.64
                                      from £0.64
                                      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                      HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                                      HEXAGON FLANGE Genuine Lamborghini - New In stock
                                      # 6
                                      MPN: 95531401520
                                      OIL CONTAINER
                                      from £65.77
                                      from £65.77
                                      This part replaces part number 95531401500
                                      OIL CONTAINER Genuine Porsche Part - New (to order)
                                      # 7
                                      MPN: 95531414500
                                      SCREW CATCH
                                      from £8.04
                                      from £8.04
                                      SCREW CAP Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 95535974000
                                      SPREADER RIVET
                                      from £1.02
                                      from £1.02
                                      RIVET Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 95535911850
                                      SUCTION LINE (COMPLETE) OIL CONTAINER TANDEM VANE PUMP F >>9P-8LA53 012 F >>9P-8LA73 883 F >>9P-8LA96 526
                                      SUCTION PIPE Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 95535911852
                                      SUCTION LINE (COMPLETE) OIL CONTAINER TANDEM VANE PUMP F 9P-8LA53 013>>F 9P-8LA73 884>>F 9P-8LA96 527>>D >>- MJ 2009
                                      SUCTION PIPE Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 95535911851
                                      SUCTION LINE (COMPLETE) OIL CONTAINER TANDEM VANE PUMP D - MJ 2010>>
                                      from £172.34
                                      from £172.34
                                      SUCTION PIPE Genuine Porsche Part - New (to order)
                                      # 10
                                      MPN: WHT003695
                                      O-RING 16 X 2
                                      from £4.52
                                      from £4.52
                                      O-RING Genuine Porsche Part - New (to order)
                                      # 11
                                      MPN: N 90687001
                                      SPRING BAND CLAMP B 27 X 12
                                      from £4.75
                                      from £4.75
                                      SPRING CLIP Genuine Porsche Part - New (to order)
                                      Genuine Bentley Part (no longer available to order)
                                      SPRING CLAMP B27X12 Genuine Lamborghini - New In stock
                                      # 12
                                      MPN: N 90842402
                                      HEXAGON HEAD BOLT (COMBI) M 6 X 22 F >>9P-8LA53 012 F >>9P-8LA73 883 F >>9P-8LA96 526
                                      from £0.78
                                      from £0.78
                                      BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: N 02214812
                                      HEXAGON NUT, SELF-LOCKING M 6 F 9P-8LA53 013>>F 9P-8LA73 884>>F 9P-8LA96 527>>
                                      from £0.88
                                      from £0.88
                                      hex. nut, self-locking - M6 Genuine Porsche Part - New In stock
                                      HEXAGON NUT, SELF-LOCKING Genuine Bentley Part - New (to order)
                                      HEX.HEAD CLAMPING Genuine Lamborghini - New In stock
                                      # 13
                                      MPN: 95535912510
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 95535912511
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION D >>- MJ 2008
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 95535912512
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION D - MJ 2009>>- MJ 2009
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION D - MJ 2009>>- MJ 2009
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 95535912513
                                      PRESSURE LINE TANDEM VANE PUMP JUNCTION D - MJ 2010>>
                                      from £437.23
                                      from £437.23
                                      PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: N 0210747
                                      BANJO BOLT M 14 X 1,5
                                      from £8.68
                                      from £8.68
                                      banjo bolt - LL10 Genuine Porsche Part - New (to order)
                                      Genuine Bentley Part (no longer available to order)
                                      # 15
                                      MPN: N 0138494
                                      SEAL RING A 14 X 20
                                      SEAL RING A 14 X 20
                                      from £0.53
                                      from £0.53
                                      SEAL RING Genuine Porsche Part - New In stock
                                      SEAL RING Genuine Bentley Part - New (to order)
                                      WASHER Genuine Lamborghini - New In stock
                                      # 15
                                      MPN: N 0138495
                                      SEAL RING A 14 X 20
                                      from £1.73
                                      from £1.73
                                      SEAL RING Genuine Porsche Part - New (to order)
                                      SEAL RING Genuine Bentley Part - New (to order)
                                      SEALING RING A14X20 DIN7603-A Genuine Lamborghini - New In stock
                                      # 16
                                      MPN: 95535931010
                                      BRACKET FOR PRESSURE LINE
                                      from £56.32
                                      from £56.32
                                      BRACKET FOR PRESSURE LINE Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: N 10285602
                                      HEXAGON HEAD BOLT (COMBI) M 6 X 25
                                      from £1.03
                                      from £1.03
                                      BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                                      6-POINT FLANGE BOLT Genuine Lamborghini - New In stock
                                      # 18
                                      MPN: 95534363810
                                      BONDED RUBBER BUSH
                                      from £5.87
                                      from £5.87
                                      BONDED RUBBER BUFFER Genuine Porsche Part - New In stock
                                      # 19
                                      MPN: 95534363810
                                      BONDED RUBBER BUSH
                                      from £5.87
                                      from £5.87
                                      BONDED RUBBER BUFFER Genuine Porsche Part - New In stock
                                      # 20
                                      MPN: N 01508213
                                      HEXAGON COLLAR NUT M 6
                                      from £0.47
                                      from £0.47
                                      shouldered hex. nut Genuine Porsche Part - New In stock
                                      Genuine Bentley Part (no longer available to order)
                                      HEXAGON FLANGE NUT M6 Genuine Lamborghini - New In stock
                                      # 21
                                      -
                                      JUNCTION SEE ILLUSTRATION: 402-007
