CURA (3.6 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CURA and installed 05/2014-05/2018) | CUR (3.6 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CUR and installed 05/2017-05/2018) | CXZA (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: CXZA and installed 05/2014-05/2018) | CXZ (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: CXZ and installed 05/2009-05/2018)
porsche 2013 (cayenne e2 92a) secondary air pump parts diagram

108-005 - Secondary Air Pump

Porsche 2013 (Cayenne E2 92A) Secondary air pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 95B131337
                                  BRACKET
                                  from £10.66
                                  from £10.66
                                  BRACKET Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: N 10473402
                                  ROUND HD. SCREW M6X20
                                  from £0.64
                                  from £0.64
                                  ROUND HD. SCREW Genuine Porsche Part - New (to order)
                                  ROUND HD. SCREW Genuine Bentley Part - New (to order)
                                  SCREW Genuine Lamborghini - New In stock
                                  # 3
                                  MPN: 95B959253
                                  Secondary Air Pump
                                  from £748.89
                                  from £748.89
                                  Secondary Air Pump Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 99950708540
                                  CLIP CONNECTOR HOUSING SECONDARY AIR PUMP
                                  from £0.59
                                  from £0.59
                                  CLIP Genuine Porsche Part - New (to order)
                                  # 4
                                  MPN: N 10451405
                                  OVAL HEXAGON SOCKET HEAD BOLT M6X16
                                  from £0.70
                                  from £0.70
                                  OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                                  OVAL HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
                                  HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                                  # 5
                                  MPN: 94811320351
                                  VALVE
                                  from £107.24
                                  from £107.24
                                  VALVE Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: 99311325851
                                  SEAL
                                  from £7.07
                                  from £7.07
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 7
                                  MPN: 97011314161
                                  PIPE LEFT
                                  from £208.60
                                  from £208.60
                                  TUBE Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 97011314261
                                  PIPE RIGHT
                                  from £208.60
                                  from £208.60
                                  TUBE Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 90038501901
                                  TORX SCREW BM6X20
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
                                  # 10
                                  MPN: N 10653302
                                  Hex collared bolt M6X20
                                  from £0.61
                                  from £0.61
                                  BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                  HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                                  # 11
                                  MPN: N 10718801
                                  Hex collared bolt M6X16
                                  from £0.48
                                  from £0.48
                                  BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New In stock
                                  Genuine Bentley Part (no longer available to order)
                                  HEXAGON BOLT M6 X 16 Genuine Lamborghini - New In stock
                                  # 12
                                  MPN: 95811303210
                                  Pipe assembly (complete)
                                  from £239.69
                                  from £239.69
                                  PIPE ASSEMBLY Genuine Porsche Part - New (to order)
                                  # 13
                                  MPN: 99951265809
                                  HOSE CLAMP B27X12X1,7
                                  from £2.29
                                  from £2.29
                                  HOSE CLAMP Genuine Porsche Part - New (to order)
                                  # 14
                                  MPN: 99951255201
                                  HOSE CLAMP A20-32
                                  from £2.29
                                  from £2.29
                                  This part replaces part number 99951250702 - and 1 more. Click to view details
                                  Hose Clamp - S25/9ZY Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: N 10759101
                                  Hex collared bolt M6X12
                                  from £0.47
                                  from £0.47
                                  BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                  HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                                  HEXAGON FLANGE M6X12 Genuine Lamborghini - New (to order)
                                  # 16
                                  MPN: 95811325800
                                  SEAL
                                  from £10.08
                                  from £10.08
                                  GASKET Genuine Porsche Part - New (to order)
