06EC (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: 06EC and installed 05/2010-05/2011) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2018) | CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2018) | CGFA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGFA and installed 05/2011-05/2018) | CJT (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CJT and installed 05/2011-05/2018)
porsche 2015 (cayenne e2 92a) camshaft, valves parts diagram

103-065 - CAMSHAFT, VALVES

Porsche 2015 (Cayenne E2 92A) camshaft, valves Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                #
                                                Part number
                                                Description
                                                Key
                                                Price
                                                # 1
                                                MPN: 95810504100
                                                CAMSHAFT INLET CYLINDERS 1-3
                                                from £943.78
                                                from £943.78
                                                camshaft Genuine Porsche Part - New (to order)
                                                # 2
                                                MPN: 95810504300
                                                CAMSHAFT INLET CYLINDERS 4-6
                                                from £943.78
                                                from £943.78
                                                camshaft Genuine Porsche Part - New (to order)
                                                # 3
                                                MPN: 95810524210
                                                CAMSHAFT OUTLET CYLINDERS 1-3
                                                from £943.78
                                                from £943.78
                                                camshaft Genuine Porsche Part - New (to order)
                                                # 4
                                                MPN: 95810524410
                                                CAMSHAFT OUTLET CYLINDERS 4-6
                                                from £943.78
                                                from £943.78
                                                camshaft Genuine Porsche Part - New (to order)
                                                # 5
                                                MPN: 95810534520
                                                SEAL RING
                                                from £8.38
                                                from £8.38
                                                SEAL RING Genuine Porsche Part - New (to order)
                                                # 6
                                                MPN: 95810532100
                                                INLET VALVE
                                                from £39.24
                                                from £39.24
                                                INTAKE VALVE Genuine Porsche Part - New (to order)
                                                # 7
                                                MPN: 95810532220
                                                EXHAUST VALVE
                                                from £39.53
                                                from £39.53
                                                EXHAUST VALVE Genuine Porsche Part - New (to order)
                                                # 8
                                                MPN: 95510511510
                                                Valve stem seal Inlet 6MM also use: 955 105 501 00
                                                from £9.78
                                                from £9.78
                                                VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                                                # 8
                                                MPN: 95510567520
                                                VALVE STEM SEAL OUTLET 6MM ALSO USE: 955 105 501 00
                                                from £10.07
                                                from £10.07
                                                VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                                                # 8
                                                MPN: 95510550100
                                                SLEEVE 6X20 VALVE STEM SEAL
                                                from £1.82
                                                from £1.82
                                                SLEEVE Genuine Porsche Part - New (to order)
                                                # 9
                                                MPN: 95810511910
                                                VALVE SPRING
                                                from £9.37
                                                from £9.37
                                                VALVE SPRING Genuine Porsche Part - New (to order)
                                                # 10
                                                MPN: 95810564100
                                                SPRING DISC
                                                from £13.11
                                                from £13.11
                                                SPRING SEAT Genuine Porsche Part - New (to order)
                                                # 11
                                                MPN: 95510565120
                                                COTTER, SPLIT
                                                from £3.30
                                                from £3.30
                                                COTTER, SPLIT Genuine Porsche Part - New (to order)
                                                # 12
                                                MPN: 95810541710
                                                CAM LEVER
                                                CAM LEVER
                                                PULL LEVER Genuine Porsche Part - New (to order)
                                                # 12
                                                MPN: 95810541711
                                                CAM LEVER
                                                from £14.38
                                                from £14.38
                                                PULL LEVER Genuine Porsche Part - New (to order)
                                                # 13
                                                MPN: 95810542320
                                                DIFFERENTIAL HOUSING HYDRAULIC
                                                from £13.11
                                                from £13.11
                                                Differential Case Genuine Porsche Part - New (to order)
                                                # 14
                                                MPN: 95810530400
                                                throttle control element Camshaft
                                                06EC (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: 06EC and installed 05/2010-05/2011)
                                                ACTUATOR Genuine Porsche Part - New (to order)
                                                # 14
                                                MPN: 95810530400
                                                THROTTLE CONTROL ELEMENT CAMSHAFT M >>1 02073 M >>0 41375
                                                , CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2018) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2018) | CJT (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CJT and installed 05/2011-05/2018)
                                                ACTUATOR Genuine Porsche Part - New (to order)
                                                # 14
                                                MPN: 95810530401
                                                throttle control element Camshaft
                                                throttle control element Camshaft
                                                ACTUATOR Genuine Porsche Part - New (to order)
                                                # 14
                                                MPN: 95810530402
                                                throttle control element Camshaft
                                                throttle control element Camshaft
                                                ACTUATOR Genuine Porsche Part - New (to order)
                                                # 14
                                                MPN: 95810530403
                                                THROTTLE CONTROL ELEMENT CAMSHAFT M 1 02074 >>M 0 41376 >>
                                                , CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2018) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2018) | CJT (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CJT and installed 05/2011-05/2018)
                                                from £60.41
                                                from £60.41
                                                ACTUATOR Genuine Porsche Part - New (to order)
                                                # 15
                                                MPN: WHT002789
                                                O-RING 14,8X1,9
                                                from £1.82
                                                from £1.82
                                                O-RING Genuine Porsche Part - New In stock
                                                O-RING Genuine Bentley Part - New (to order)
                                                # 16
                                                MPN: N 10622503
                                                SOCKET HEAD BOLT WITH M5X12 HEX. SOCKET HEAD, SELF-LOCKING
                                                from £0.54
                                                from £0.54
                                                BOLT, WITH HEX. SOCKET HD., Genuine Porsche Part - New (to order)
                                                # 16
                                                MPN: N 10622503
                                                SOCKET HEAD BOLT WITH M5X12 HEX. SOCKET HEAD, SELF-LOCKING M >>1 02073 M >>0 41375
                                                , CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2018) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2018) | CJT (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CJT and installed 05/2011-05/2018)
                                                from £0.54
                                                from £0.54
                                                BOLT, WITH HEX. SOCKET HD., Genuine Porsche Part - New (to order)
                                                # 16
                                                MPN: N 91211101
                                                HEX SOCKET HEAD COLLARED BOLT M5X12 M 1 02074 >>M 0 41376 >>
                                                , CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2018) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2018) | CJT (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CJT and installed 05/2011-05/2018)
                                                from £0.49
                                                from £0.49
                                                HEX SOCKET HEAD COLLARED BOLT Genuine Porsche Part - New (to order)
                                                HEX SOCKET HEAD COLLARED BOLT Genuine Bentley Part - New (to order)
                                                # 17
                                                MPN: 95810578500
                                                COVER
                                                COVER
                                                COVER Genuine Porsche Part - New (to order)
                                                # 17
                                                MPN: 95810578501
                                                COVER ALSO USE: 1X 000 043 300 39
                                                from £32.78
                                                from £32.78
                                                COVER Genuine Porsche Part - New (to order)
                                                # 18
                                                MPN: 00004320749
                                                SEALANT 80ml 1 TUBE
                                                SEALANT 80ml 1 TUBE
                                                SEALANT Genuine Porsche Part - New (to order)
                                                # 18
                                                MPN: 00004330039
                                                SEALANT 50ML 1 TUBE
                                                Supersession
                                                Supersession
                                                Genuine Porsche Part (no longer available to order)
                                                # 19
                                                MPN: N 10082911
                                                HEXAGON HEAD BOLT (COMBI) M6X16
                                                from £0.49
                                                from £0.49
                                                BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                                                HEXAGON HEAD BOLT M6X16-S1-N Genuine Lamborghini - New In stock
                                                # 20
                                                MPN: N 91057302
                                                12-POINT SOCKET HEAD BOLT M6X16/M6X10 (COMBI)
                                                from £0.79
                                                from £0.79
                                                DOUBLE HEX BOLT Genuine Porsche Part - New (to order)
                                                12-POINT SOCKET HEAD BOLT (COMBI) Genuine Bentley Part - New (to order)
                                                # 21
                                                MPN: 95860650120
                                                BRACKET
                                                from £7.95
                                                from £7.95
                                                BRACKET Genuine Porsche Part - New (to order)
                                                # 22
                                                MPN: N 01100632
                                                HEXAGON NUT M6
                                                from £1.06
                                                from £1.06
                                                HEX. NUT Genuine Porsche Part - New (to order)
                                                HEXAGON NUT Genuine Bentley Part - New (to order)
                                                HEX.NUT Genuine Lamborghini - New In stock
                                                # 23
                                                MPN: 95860684500
                                                BRACKET
                                                from £4.62
                                                from £4.62
                                                BRACKET Genuine Porsche Part - New (to order)
                                                # 24
                                                MPN: 95811159700
                                                BRACKET FOR SHIELD LEFT
                                                from £4.26
                                                from £4.26
                                                BRACKET FOR SHIELD Genuine Porsche Part - New (to order)
                                                # 25
                                                MPN: 95811159800
                                                BRACKET FOR SHIELD RIGHT
                                                from £4.26
                                                from £4.26
                                                BRACKET FOR SHIELD Genuine Porsche Part - New (to order)
                                                # 26
                                                MPN: 95860630110
                                                BRACKET LEFT KNOCK SENSOR
                                                from £27.98
                                                from £27.98
                                                BRACKET Genuine Porsche Part - New (to order)
                                                # 27
                                                MPN: N 10451405
                                                OVAL HEXAGON SOCKET HEAD BOLT M6X16
                                                from £0.70
                                                from £0.70
                                                OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                                                OVAL HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
                                                HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                                                # 28
                                                MPN: 95860636110
                                                BRACKET RIGHT KNOCK SENSOR
                                                from £23.07
                                                from £23.07
                                                BRACKET Genuine Porsche Part - New (to order)
