porsche 2018 (cayenne e3 9ya/9yb) heater low-temperature circuit water box for vehicles with hybrid drive parts diagram

815-010 - heater Low-temperature circuit water box For vehicles with hybrid drive

Porsche 2018 (Cayenne E3 9YA/9YB) heater Low-temperature circuit water box For vehicles with hybrid drive Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: PAB12215700
                  COOLANT HOSE LHD
                  from £77.44
                  from £77.44
                  WATER HOSE Genuine Porsche Part - New (to order)
                  # 2
                  MPN: PAB12103600
                  COOLANT HOSE LHD
                  from £42.59
                  from £42.59
                  WATER HOSE Genuine Porsche Part - New (to order)
                  # 3
                  MPN: PAB12215710
                  COOLANT HOSE RHD
                  from £41.17
                  from £41.17
                  WATER HOSE Genuine Porsche Part - New (to order)
                  # 4
                  MPN: PAB12103610
                  COOLANT HOSE RHD
                  from £25.14
                  from £25.14
                  WATER HOSE Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 99951265809
                  HOSE CLAMP B27X12X1,7
                  from £2.29
                  from £2.29
                  HOSE CLAMP Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 95510612501
                  TEMPERATURE SENSOR THERMOSTAT HOUSING
                  from £53.39
                  from £53.39
                  TEMPERATURE SENDER Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 95510614300
                  RETAINING SPRING COOLANT REGULATOR HOUSING COOLANT COOLING SYSTEM
                  from £1.84
                  from £1.84
                  RETAINING SPRING Genuine Porsche Part - New (to order)
                  # 8
                  MPN: N 90316801
                  O-RING 19,6X3,65
                  from £2.48
                  from £2.48
                  O-RING Genuine Porsche Part - New In stock
                  O-RING Genuine Bentley Part - New (to order)
