DCUA (4.0 Litre 8 Cyliner Engine (549 Horsepower / 404 Kilowatt with Engine Code: DCUA and installed 05/2017-05/2023) | DCUD (4.0 Litre 8 Cyliner Engine (460 Horsepower / 338 Kilowatt with Engine Code: DCUD and installed 01/2017-05/2023) | DCU (4.0 Litre 8 Cyliner Engine (549 Horsepower / 404 Kilowatt with Engine Code: DCU and installed 05/2017-05/2023) | DWN (4.0 Litre 8 Cyliner Engine (640 Horsepower / 471 Kilowatt with Engine Code: DWN and installed 01/2017-05/2023) | DWNA (4.0 Litre 8 Cyliner Engine (640 Horsepower / 471 Kilowatt with Engine Code: DWNA and installed 01/2017-05/2023)
porsche 2021 (cayenne e3 9ya/9yb) poly-v-belt belt tensioner damper parts diagram

102-050 - Poly-V-belt Belt tensioner damper

Porsche 2021 (Cayenne E3 9YA/9YB) Poly-V-belt Belt tensioner damper Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 9A790313300
                          BELT TENSIONER DAMPER
                          BELT TENSIONER DAMPER
                          from £100.94
                          from £100.94
                          belt tensioning damper Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 9A790313301
                          BELT TENSIONER DAMPER
                          from £144.86
                          from £144.86
                          belt tensioning damper Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 9A700803500
                          Hexagon socket flat M8X60 head bolt
                          from £3.32
                          from £3.32
                          This part replaces part number 99907341101
                          HEXAGON SOCKET FLAT Genuine Porsche Part - New In stock
                          # 3
                          MPN: 9A700806600
                          Hexagon socket flat M8X33 head bolt
                          from £3.32
                          from £3.32
                          HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 9A790314300
                          BRACKET FOR ALTERNATOR
                          from £91.78
                          from £91.78
                          BRACKET FOR ALTERNATOR Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 95814750100
                          CENTRE SLEEVE 11,15X6,5
                          from £6.23
                          from £6.23
                          CENTERING SLEEVE Genuine Porsche Part - New (to order)
                          # 6
                          MPN: N 10673001
                          SOCKET HEAD BOLT WITH INNER M8X40 MULTIPOINT HEAD (KOMBI)
                          from £1.12
                          from £1.12
                          BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                          12-POINT SOCKET M8X40 Genuine Lamborghini - New (to order)
                          # 7
                          -
                          ALTERNATOR SEE ILLUSTRATION, ITEM: 902-005,6
                          # 8
                          MPN: 9A726093801
                          BELT TENSIONER DAMPER
                          BELT TENSIONER DAMPER
                          from £196.61
                          from £196.61
                          belt tensioning damper Genuine Porsche Part - New (to order)
                          # 8
                          MPN: PAB26093800
                          BELT TENSIONER DAMPER
                          BELT TENSIONER DAMPER
                          from £97.10
                          from £97.10
                          belt tensioning damper Genuine Porsche Part - New (to order)
                          # 9
                          MPN: N 91157202
                          SOCKET HEAD COLLARED BOLT WITH M8X30 INNER MULTIPOINT HEAD
                          from £2.04
                          from £2.04
                          SOCKET HD. SCREW WITH POLYGON Genuine Porsche Part - New (to order)
                          12-POINT SOCKET M8X30 Genuine Lamborghini - New In stock
                          # 10
                          MPN: 9A726088504
                          CONSOLE A/C COMPRESSOR
                          from £47.73
                          from £47.73
                          BRACKET Genuine Porsche Part - New (to order)
                          # 11
                          MPN: N 91157202
                          SOCKET HEAD COLLARED BOLT WITH M8X30 INNER MULTIPOINT HEAD
                          from £2.01
                          from £2.01
                          SOCKET HD. SCREW WITH POLYGON Genuine Porsche Part - New (to order)
                          12-POINT SOCKET M8X30 Genuine Lamborghini - New In stock
                          # 12
                          -
                          A/C COMPRESSOR SEE ILLUSTRATION, ITEM: 814-030,1
                          # 12
                          -
                          A/C COMPRESSOR SEE ILLUSTRATION, ITEM: 814-035,1
                          # 12
                          -
                          A/C COMPRESSOR SEE ILLUSTRATION, ITEM: 814-037,1
                          # 13
                          -
                          VIBRATION DAMPER SEE ILLUSTRATION, ITEM: 102-000,3
                          # 14
                          MPN: 9A790313700
                          Poly-V-belt Alternator
                          Poly-V-belt Alternator
                          from £31.09
                          from £31.09
                          v-ribbed belt Genuine Porsche Part - New (to order)
                          # 14
                          MPN: PAB90313700
                          Poly-V-belt Alternator
                          from £46.36
                          from £46.36
                          v-ribbed belt Genuine Porsche Part - New (to order)
                          # 15
                          MPN: 95826084901
                          POLY-V-BELT A/C COMPRESSOR
                          POLY-V-BELT A/C COMPRESSOR
                          from £19.78
                          from £19.78
                          v-ribbed belt Genuine Porsche Part - New (to order)
                          # 15
                          MPN: 9A726084900
                          POLY-V-BELT A/C COMPRESSOR
                          from £30.93
                          from £30.93
                          v-ribbed belt Genuine Porsche Part - New (to order)
                          # 16
                          MPN: 9A726093805
                          IDLER PULLEY WITH BOLT
                          IDLER PULLEY WITH BOLT
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 16
                          MPN: 9A726093806
                          IDLER PULLEY WITH BOLT
                          from £53.19
                          from £53.19
                          This part replaces part number 9A726093805
                          RELAY ROLLER Genuine Porsche Part - New (to order)
                          # 17
                          MPN: 95510283901
                          PROTECTIVE CAP
                          from £4.16
                          from £4.16
                          PROTECTIVE CAP Genuine Porsche Part - New (to order)
