DFKA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: DFKA and installed 01/2017-05/2023) | DFK (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: DFK and installed 01/2017-05/2023)
porsche 2022 (cayenne e3 9ya/9yb) cylinder head ignition coil parts diagram

103-020 - Cylinder head Ignition coil

Porsche 2022 (Cayenne E3 9YA/9YB) Cylinder head Ignition coil Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: PAC905110B
          IGNITION COIL WITH SPARK PLUG CONNECTOR
          from £70.98
          from £70.98
          IGNITION COIL WITH SPARK PLUG CONNECTOR Genuine Porsche Part - New (to order)
          # 2
          MPN: PAC905199
          spark plug connector
          from £33.60
          from £33.60
          spark plug connector Genuine Porsche Part - New (to order)
          # 3
          MPN: 95890560100
          SPARK PLUG
          P7CM (C6B emissions concept without RDE) | P7GR (Emission standard C5 stage 2)
          from £20.86
          from £20.86
          SPARK PLUG Genuine Porsche Part - New In stock
          # 3
          MPN: PAC905601
          SPARK PLUG
          P4BD (Emission standard C6b without Real Driving Emissions (RDE) (PN11)) | P7CR (Emissions concept C6B with RDE)
          from £20.88
          from £20.88
          SPARK PLUG Genuine Porsche Part - New (to order)
          # 4
          MPN: PAF912292
          DOUBLE STUD WITH HEXAGON DRIVE M6GFX45-M6X12
          from £3.74
          from £3.74
          DOUBLE HEX. HD. BOLT Genuine Porsche Part - New (to order)
          # 5
          MPN: 00004321083
          GREASE 20 GRAM
          from £22.74
          from £22.74
          GREASE Genuine Porsche Part - New (to order)
