103-000 - CYLINDER HEAD
Porsche 2007 (987 Cayman) Cylinder head Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 98710491300
CYLINDER HEAD CYLINDERS 1-3
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £2,957.62
from £2,957.62
# 1
MPN: 987104913AX
CYLINDER HEAD CYLINDERS 1-3
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £2,102.42
from £2,102.42
# 1
MPN: 98710491500
CYLINDER HEAD CYLINDERS 1-3 D - MJ 2007>>
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £2,779.68
from £2,779.68
# 1
MPN: 98710491400
CYLINDER HEAD CYLINDERS 4-6
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £2,957.62
from £2,957.62
# 1
MPN: 987104914AX
CYLINDER HEAD CYLINDERS 4-6
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £2,102.42
from £2,102.42
# 1
MPN: 98710491600
CYLINDER HEAD CYLINDERS 4-6 D - MJ 2007>>
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £2,779.68
from £2,779.68
# 2
-
BEARING COVER ALTERNATIVELY, YOU CAN USE: CYLINDER HEAD
# 3
MPN: 99610411750
DOWEL SLEEVE
from £2.76
from £2.76
# 4
-
COVER ALTERNATIVELY, YOU CAN USE: CYLINDER HEAD
# 5
MPN: 99610527100
INLET VALVE
INLET VALVE
# 5
MPN: 99610527102
INLET VALVE
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £66.75
from £66.75
# 5
MPN: 98710511500
INLET VALVE D - MJ 2007>>
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £84.44
from £84.44
# 6
MPN: 99610527303
EXHAUST VALVE
EXHAUST VALVE
# 6
MPN: 99610527304
EXHAUST VALVE
from £88.06
from £88.06
# 6
MPN: 98710511600
EXHAUST VALVE D - MJ 2007>>
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £99.94
from £99.94
# 7
MPN: 99610511552
VALVE STEM SEAL
Supersession
Supersession
# 8
MPN: 99610511751
SPRING DISC LOWER EXHAUST VALVE
from £11.72
from £11.72
# 9
MPN: 99610511801
Valve spring exhaust valve
from £16.57
from £16.57
# 10
MPN: 99610512154
SPRING DISC UPPER EXHAUST VALVE
from £3.55
from £3.55
# 11
MPN: 99610514700
SPRING DISC LOWER INLET VALVE
from £7.19
from £7.19
# 12
MPN: 99610593900
1 SET OF VALVE SPRINGS INLET VALVE
from £24.77
from £24.77
# 13
MPN: 99610514500
SPRING DISC UPPER INLET VALVE
from £7.19
from £7.19
# 14
MPN: 99610512351
COTTER, SPLIT
from £0.89
from £0.89
# 15
MPN: 99760610603
HALL SENSOR
from £81.07
from £81.07
# 16
MPN: 99970740440
O-RING 17,05 X 1,78
O-RING 17,05 X 1,78
Supersession
Supersession
# 17
MPN: 90038726401
SOCKET HEAD BOLT M 6 X 16
SOCKET HEAD BOLT M 6 X 16
# 17
MPN: N 10546403
HEXAGON SOCKET HEAD BOLT M 6 X 16
from £1.26
from £1.26
# 18
-
BEARING COVER INLET ALTERNATIVELY, YOU CAN USE: CYLINDER HEAD
# 19
MPN: 90038501709
TORX SCREW M 6 X 35
from £0.47
from £0.47
# 20
MPN: 90038502501
TORX SCREW M 6 X 40
from £0.59
from £0.59
# 21
MPN: 00004320446
SLEEVE FOR VALVE STEM SEAL
from £0.61
from £0.61
# 22
MPN: 99610420104
CYLINDER HEAD GASKET
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £67.10
from £67.10
# 22
MPN: 99610417010
CYLINDER HEAD GASKET
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £64.27
from £64.27
# 23
MPN: 99610418058
Screw M 10 X 230
Screw M 10 X 230
# 23
MPN: 99610418059
Screw M 10 X 230
from £15.47
from £15.47
This part replaces part number 99610418055 - and 1 more. Click to view details
# 24
MPN: 99950707540
CABLE HOLDER 3,0 - 12
Supersession
Supersession
# 25
MPN: 99903602602
END CAP 10 MM
END CAP 10 MM
# 25
MPN: 99903602601
END CAP 10 MM
from £2.75
from £2.75
# 26
MPN: 90038504801
TORX SCREW M 6 X 30 FOR CYLINDER HEAD CRANKCASE HOUSING
Supersession
Supersession
# 27
MPN: 90003602302
End Cap B 18
End Cap B 18
# 27
MPN: 90003602301
End Cap B 18
from £1.84
from £1.84
# 28
MPN: 99710404300
HOUSING HYDRAULIC TAPPET
9721 (3.4 Litre 6 Cyliner Engine (295 Horsepower / 217 Kilowatt with Engine Code: 9721 and installed 08/2005-07/2008) | 9722 (3.4 Litre 6 Cyliner Engine (303 Horsepower / 223 Kilowatt with Engine Code: 9722 and installed 08/2007-07/2008)
from £576.42
from £576.42
# 28
MPN: 98710404500
HOUSING HYDRAULIC TAPPET
9720 (2.7 Litre 6 Cyliner Engine (244 Horsepower / 180 Kilowatt with Engine Code: 9720 and installed 08/2006-07/2008)
from £548.85
from £548.85
# 29
MPN: 90038501709
TORX SCREW M 6 X 35
from £0.47
from £0.47
# 30
MPN: 99610420300
SEAL
from £13.08
from £13.08
# 31
MPN: 99610421554
END CAP
from £13.45
from £13.45
# 32
MPN: 99610421602
END CAP
from £13.45
from £13.45
# 33
MPN: 99970176141
O-RING 28 X 2
from £2.68
from £2.68
# 34
MPN: 99938500301
TORX SCREW M 6 X 30
from £2.68
from £2.68
# 35
MPN: 90038504801
TORX SCREW M 6 X 30
Supersession
Supersession
# 36
MPN: 90021901830
SEALING PLUG M 14 X 1,5
SEALING PLUG M 14 X 1,5
from £12.86
from £12.86
# 36
MPN: 99906303801
SEALING PLUG M 14 X 1,5
Supersession
Supersession
# 37
MPN: 90012310430
SEAL RING A 14 X 18
SEAL RING A 14 X 18
Supersession
Supersession
# 37
MPN: 90012317320
SEAL RING A 14 X 18
Supersession
Supersession
# 38
MPN: 99710570100
OIL STRAINER
from £54.61
from £54.61
# 39
MPN: 99610530305
throttle control element Camshaft
throttle control element Camshaft
Supersession
Supersession
# 40
MPN: 99610590305
O-ring throttle control element Camshaft
from £10.22
from £10.22
# 41
MPN: 99610524403
END CAP THROTTLE CONTROL ELEMENT
from £10.16
from £10.16
# 42
MPN: 99610525601
BRACKET F.THROTTLE CONTR.ELEM.
from £5.53
from £5.53
# 43
MPN: 99965138602
CABLE HOLDER 5,5 - 9,0
CABLE HOLDER 5,5 - 9,0
# 43
MPN: 99965138601
CABLE HOLDER 5,5 - 9,0
# 44
MPN: 90038700601
SOCKET HEAD BOLT M 6 X 20
from £0.59
from £0.59
# 45
MPN: 99710530100
THROTTLE CONTROL ELEMENT
from £142.38
from £142.38
# 46
MPN: 99970747940
O-RING 22,00 X 1,50
from £5.33
from £5.33
# 47
MPN: 99970744140
O-RING 18,00 X 1,50
from £5.33
from £5.33
# 48
MPN: 99610531003
BRACKET
from £25.69
from £25.69
# 49
MPN: 98660620303
OIL PRESSURE SWITCH
from £13.26
from £13.26
# 50
MPN: 98710444500
GUARD PLATE CYLINDERS 1-3
from £17.62
from £17.62
# 51
MPN: 90038500909
TORX SCREW M 6 X 16
# 52
MPN: 00004320435
SEALANT 50 ML
Supersession
Supersession
# 52
MPN: 00004302400
EXTREME-PRESSURE GREASE 1 TUBE 80 GR. FOR CAMSHAFT
Supersession
Supersession
-part-diagram-103-010.webp "PORSCHE 2007 (987 CAYMAN) CAMSHAFT TIMING CHAIN W/ TENSION RAIL PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 2007 (987 CAYMAN) OIL PUMP TANDEM VANE PUMP PARTS DIAGRAM")
-part-diagram-104-005.webp "PORSCHE 2007 (987 CAYMAN) ENGINE (OIL PRESS./LUBRICA.) PARTS DIAGRAM")
-part-diagram-104-010.webp "PORSCHE 2007 (987 CAYMAN) CRANKCASE HOUSING VENTILATION PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 2007 (987 CAYMAN) COOLANT PUMP THERMOSTAT HOUSING PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 2007 (987 CAYMAN) COOLANT COOLING SYSTEM 1 PARTS DIAGRAM")
-part-diagram-105-010.webp "PORSCHE 2007 (987 CAYMAN) COOLANT COOLING SYSTEM 2 PARTS DIAGRAM")
-part-diagram-105-015.webp "PORSCHE 2007 (987 CAYMAN) COOLANT COOLING SYSTEM 3 PARTS DIAGRAM")
-part-diagram-105-017.webp "PORSCHE 2007 (987 CAYMAN) COOLER FOR COOLANT CENTER PARTS DIAGRAM")
-part-diagram-105-020.webp "PORSCHE 2007 (987 CAYMAN) COOLANT COOLING SYSTEM 4 PARTS DIAGRAM")
-part-diagram-105-021.webp "PORSCHE 2007 (987 CAYMAN) COOLANT COOLING SYSTEM 4 FUEL FILLER NECK PARTS DIAGRAM")
-part-diagram-106-000.webp "PORSCHE 2007 (987 CAYMAN) AIR FILTER PARTS DIAGRAM")
-part-diagram-107-000.webp "PORSCHE 2007 (987 CAYMAN) THROTTLE VALVE ADAPTER PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 2007 (987 CAYMAN) FUEL COLLECTION PIPE PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 2007 (987 CAYMAN) INTAKE AIR DISTRIBUTOR PARTS DIAGRAM")
-part-diagram-108-005.webp "PORSCHE 2007 (987 CAYMAN) VENTILATION COMPONENT PARTS DIAGRAM")
-part-diagram-109-000.webp "PORSCHE 2007 (987 CAYMAN) ENGINE LIFTING TACKLE PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 2007 (987 CAYMAN) FUEL TANK PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 2007 (987 CAYMAN) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-201-020.webp "PORSCHE 2007 (987 CAYMAN) ACTIVATED CHARCOAL CONTAINER PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 2007 (987 CAYMAN) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 2007 (987 CAYMAN) COUPLING FOR 5-SPEED MANUAL TRANSMISSION D - MJ 2007>> PARTS DIAGRAM")
-part-diagram-801-080.webp "PORSCHE 2007 (987 CAYMAN) AIR GUIDE FAN ENGINE BAY PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 2007 (987 CAYMAN) BUMPER FRONT PARTS DIAGRAM")
-part-diagram-301-001.webp "PORSCHE 2007 (987 CAYMAN) COUPLING FOR 6-SPEED MANUAL TRANSMISSION PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 2007 (987 CAYMAN) CLUTCH SLAVE CYLINDER FOR 5-SPEED MANUAL TRANSMISSION PARTS DIAGRAM")
-part-diagram-301-006.webp "PORSCHE 2007 (987 CAYMAN) CLUTCH SLAVE CYLINDER FOR 6-SPEED MANUAL TRANSMISSION PARTS DIAGRAM")
-part-diagram-302-000.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION GEAR HOUSING PARTS DIAGRAM")
-part-diagram-302-001.webp "PORSCHE 2007 (987 CAYMAN) 6-SPEED MANUAL TRANSMISSION READY FOR INSTALLATION PARTS DIAGRAM")
-part-diagram-302-005.webp "PORSCHE 2007 (987 CAYMAN) 6-SPEED MANUAL TRANSMISSION INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-303-000.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION GEARS AND SHAFTS PARTS DIAGRAM")
-part-diagram-303-005.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION GEARS AND SHAFTS PARTS DIAGRAM")
-part-diagram-304-000.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION SELECTOR SHAFT SELECTOR FORK PARTS DIAGRAM")
-part-diagram-305-000.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION DIFFERENTIAL PARTS DIAGRAM")
-part-diagram-306-000.webp "PORSCHE 2007 (987 CAYMAN) 5-SPEED MANUAL TRANSMISSION GEARBOX MOUNTING FASTENING SCREW ENGINE PARTS DIAGRAM")
-part-diagram-306-001.webp "PORSCHE 2007 (987 CAYMAN) 6-SPEED MANUAL TRANSMISSION GEARBOX MOUNTING CONNECTION ELEMENTS ENGINE PARTS DIAGRAM")
-part-diagram-320-000.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC GEARBOX READY FOR INSTALLATION PARTS DIAGRAM")
-part-diagram-320-003.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC DIFFERENTIAL DIFFERENTIAL HOUSING PARTS DIAGRAM")
-part-diagram-320-005.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC MULTI-FUNCTION SWITCH FOR AUTOMATIC GEARBOX PARTS DIAGRAM")
-part-diagram-330-000.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC CONVERTER PARTS DIAGRAM")
-part-diagram-330-001.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC OIL PUMP PARTS DIAGRAM")
-part-diagram-340-001.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC OIL FILTER OIL SUMP PARTS DIAGRAM")
-part-diagram-340-002.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC VALVE BODY SOLENOID VALVE PRESSURE REGULATOR PARTS DIAGRAM")
-part-diagram-360-000.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC GEAR OIL COOLER OIL PRESSURE LINE FOR GEARBOX OIL COOLING PARTS DIAGRAM")
-part-diagram-370-000.webp "PORSCHE 2007 (987 CAYMAN) TIPTRONIC GEARBOX MOUNTING FASTENING SCREW ENGINE PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 2007 (987 CAYMAN) CROSS MEMBER WISHBONE PARTS DIAGRAM")
-part-diagram-401-005.webp "PORSCHE 2007 (987 CAYMAN) WHEEL CARRIER WHEEL HUB PARTS DIAGRAM")
-part-diagram-402-000.webp "PORSCHE 2007 (987 CAYMAN) SUSPENSION SUSPENSION STRUT, COMPLETE PARTS DIAGRAM")
-part-diagram-402-005.webp "PORSCHE 2007 (987 CAYMAN) ANTI-ROLL BAR PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 2007 (987 CAYMAN) POWER STEERING STEERING GEAR PARTS DIAGRAM")
-part-diagram-403-001.webp "PORSCHE 2007 (987 CAYMAN) POWER STEERING HYDRAULIC LINE PARTS DIAGRAM")
-part-diagram-403-003.webp "PORSCHE 2007 (987 CAYMAN) POWER STEERING VANE PUMP CONTAINER PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 2007 (987 CAYMAN) STEERING PROTECTIVE PIPE INTERMEDIATE STEERING SHAFT STEERING WHEEL PARTS DIAGRAM")
-part-diagram-403-006.webp "PORSCHE 2007 (987 CAYMAN) AIRBAG PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 2007 (987 CAYMAN) REAR AXLE WHEEL CARRIER GUIDE WHEEL HUB PARTS DIAGRAM")
-part-diagram-501-001.webp "PORSCHE 2007 (987 CAYMAN) REAR AXLE SIDE PART CARRIER PARTS DIAGRAM")
-part-diagram-501-003.webp "PORSCHE 2007 (987 CAYMAN) ANTI-ROLL BAR PARTS DIAGRAM")
-part-diagram-501-005.webp "PORSCHE 2007 (987 CAYMAN) DRIVE SHAFT WHEEL HUB PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 2007 (987 CAYMAN) SHOCK ABSORBERS COIL SPRING PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 2007 (987 CAYMAN) WHEELS/TYRES PARTS DIAGRAM")
-part-diagram-601-005.webp "PORSCHE 2007 (987 CAYMAN) TYRE PRESSURE CONTROL SYSTEM PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 2007 (987 CAYMAN) DISC BRAKE FRONT AXLE PARTS DIAGRAM")
-part-diagram-603-000.webp "PORSCHE 2007 (987 CAYMAN) DISC BRAKE REAR AXLE PARTS DIAGRAM")
-part-diagram-603-005.webp "PORSCHE 2007 (987 CAYMAN) HANDBRAKE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 2007 (987 CAYMAN) BRAKE MASTER CYLINDER BRAKE SERVO PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 2007 (987 CAYMAN) BRAKE LINE FRONT END PARTS DIAGRAM")
-part-diagram-604-010.webp "PORSCHE 2007 (987 CAYMAN) BRAKE LINE UNDERBODY VACUUM LINE PARTS DIAGRAM")
-part-diagram-604-015.webp "PORSCHE 2007 (987 CAYMAN) BRAKE LINE UNDERBODY REAR AXLE VACUUM LINE PARTS DIAGRAM")
-part-diagram-605-000.webp "PORSCHE 2007 (987 CAYMAN) HYDRAULIC UNIT ANTI-LOCKING BRAKE SYST. -ABS- PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 2007 (987 CAYMAN) SELECTOR MECHANISM MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-701-001.webp "PORSCHE 2007 (987 CAYMAN) SELECTOR LEVER TIPTRONIC PARTS DIAGRAM")
-part-diagram-701-005.webp "PORSCHE 2007 (987 CAYMAN) BRAKE LEVER PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 2007 (987 CAYMAN) BRAKE AND CLUTCH PEDALS CLUSTER PARTS DIAGRAM")
-part-diagram-702-008.webp "PORSCHE 2007 (987 CAYMAN) HYDRAULIC COUPLING ACTUATION CLUTCH MASTER CYLINDER HYDRAULIC CLUTCH PIPE PARTS DIAGRAM")
-part-diagram-702-010.webp "PORSCHE 2007 (987 CAYMAN) ACCELERATOR PEDAL PARTS DIAGRAM")
-part-diagram-801-000.webp "PORSCHE 2007 (987 CAYMAN) CAR BODY PARTS DIAGRAM")
-part-diagram-801-002.webp "PORSCHE 2007 (987 CAYMAN) BUNGS SEE WORKSHOP MANUAL PARTS DIAGRAM")
-part-diagram-801-005.webp "PORSCHE 2007 (987 CAYMAN) FRONT END PARTS DIAGRAM")
-part-diagram-801-010.webp "PORSCHE 2007 (987 CAYMAN) FRONT END INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-801-020.webp "PORSCHE 2007 (987 CAYMAN) FLOOR ASSEMBLY CENTER PARTS DIAGRAM")
-part-diagram-801-035.webp "PORSCHE 2007 (987 CAYMAN) REAR END INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-801-040.webp "PORSCHE 2007 (987 CAYMAN) WING PARTS DIAGRAM")
-part-diagram-801-045.webp "PORSCHE 2007 (987 CAYMAN) ROOF SCUTTLE PARTS DIAGRAM")
-part-diagram-801-050.webp "PORSCHE 2007 (987 CAYMAN) SIDE PART PARTS DIAGRAM")
-part-diagram-801-070.webp "PORSCHE 2007 (987 CAYMAN) TRIMS UNDERBODY PARTS DIAGRAM")
-part-diagram-801-075.webp "PORSCHE 2007 (987 CAYMAN) TRIMS FOR WHEEL HOUSING PARTS DIAGRAM")
-part-diagram-802-005.webp "PORSCHE 2007 (987 CAYMAN) BUMPER REAR PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 2007 (987 CAYMAN) COVER FRONT PARTS DIAGRAM")
-part-diagram-803-005.webp "PORSCHE 2007 (987 CAYMAN) COVER REAR PARTS DIAGRAM")
-part-diagram-803-007.webp "PORSCHE 2007 (987 CAYMAN) REAR SPOILER PARTS DIAGRAM")
-part-diagram-803-008.webp "PORSCHE 2007 (987 CAYMAN) REAR SPOILER AEROKIT PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 2007 (987 CAYMAN) DOOR SHELL WITH INSTALLATION PARTS DOOR LOCK PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 2007 (987 CAYMAN) DOOR SEAL SEAL WINDSHIELD FRAME PARTS DIAGRAM")
-part-diagram-804-020.webp "PORSCHE 2007 (987 CAYMAN) DOOR HANDLES PARTS DIAGRAM")
-part-diagram-804-030.webp "PORSCHE 2007 (987 CAYMAN) WINDOW REGULATOR PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 2007 (987 CAYMAN) WINDSCREEN SIDE WINDOW REAR WINDOW PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 2007 (987 CAYMAN) LUGGAGE BOOT TRIMS FRONT PARTS DIAGRAM")
-part-diagram-807-001.webp "PORSCHE 2007 (987 CAYMAN) LUGGAGE COMPARTMENT REAR PARTS DIAGRAM")
-part-diagram-807-002.webp "PORSCHE 2007 (987 CAYMAN) INTERIOR EQUIPMENT FLOORING TRIMS PARTS DIAGRAM")
-part-diagram-807-003.webp "PORSCHE 2007 (987 CAYMAN) TRIM SILL PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 2007 (987 CAYMAN) TRIMS ENGINE BAY PARTS DIAGRAM")
-part-diagram-807-008.webp "PORSCHE 2007 (987 CAYMAN) ROOF TRIM SUN VIZORS A-PILLAR C-PILLAR PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 2007 (987 CAYMAN) DOOR PANEL ACCESSORIES PARTS DIAGRAM")
-part-diagram-807-015.webp "PORSCHE 2007 (987 CAYMAN) BODY NOISE INSULATION PARTS DIAGRAM")
-part-diagram-807-020.webp "PORSCHE 2007 (987 CAYMAN) TRIMS REAR LID PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 2007 (987 CAYMAN) INSTRUMENT PANEL TRIM UPPER PART WITH: FASTENERS PARTS DIAGRAM")
-part-diagram-809-001.webp "PORSCHE 2007 (987 CAYMAN) INSTRUMENT PANEL TRIM UPPER PART WITH: ACCESSORIES PARTS DIAGRAM")
-part-diagram-809-003.webp "PORSCHE 2007 (987 CAYMAN) GLOVE BOX COVER AND TRIM (DRIVERS SIDE) PARTS DIAGRAM")
-part-diagram-809-004.webp "PORSCHE 2007 (987 CAYMAN) RETAINING FRAME DASHBOARD PARTS DIAGRAM")
-part-diagram-809-010.webp "PORSCHE 2007 (987 CAYMAN) INTERIOR MIRROR EXTERIOR MIRROR PARTS DIAGRAM")
-part-diagram-809-015.webp "PORSCHE 2007 (987 CAYMAN) CENTRE CONSOLE FRONT PARTS DIAGRAM")
-part-diagram-809-020.webp "PORSCHE 2007 (987 CAYMAN) CENTRE CONSOLE REAR PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 2007 (987 CAYMAN) INSCRIPTIONS/LETTERING MOLDINGS STONE GUARD FILM PARTS DIAGRAM")
-part-diagram-812-000.webp "PORSCHE 2007 (987 CAYMAN) THREE-POINT SAFETY BELT PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 2007 (987 CAYMAN) HEATER 1 SUPPLY PIPE RETURN LINE PARTS DIAGRAM")
-part-diagram-813-001.webp "PORSCHE 2007 (987 CAYMAN) HEATER AIR GUIDE PARTS DIAGRAM")
-part-diagram-813-002.webp "PORSCHE 2007 (987 CAYMAN) LUGGAGE COMPARTMENT AIR GUIDE PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 2007 (987 CAYMAN) AIR DISTRIBUTION HOUSING INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 2007 (987 CAYMAN) WATER DRAIN PIPE FOR ATTACHMENT TO: AIR DISTRIBUTION HOUSING PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 2007 (987 CAYMAN) COMPRESSOR PARTS DIAGRAM")
-part-diagram-813-020.webp "PORSCHE 2007 (987 CAYMAN) PARTICULATE FILTER COVER FOR SCUTTLE PARTS DIAGRAM")
-part-diagram-813-025.webp "PORSCHE 2007 (987 CAYMAN) REFRIGERANT CIRCUIT PARTS DIAGRAM")
-part-diagram-813-045.webp "PORSCHE 2007 (987 CAYMAN) CONTROL SWITCH PARTS DIAGRAM")
-part-diagram-817-000.webp "PORSCHE 2007 (987 CAYMAN) FRONT SEATS STANDARD SEAT COMFORT SEAT (COMPLETE) NO LONGER AVAILABLE PARTS DIAGRAM")
-part-diagram-817-002.webp "PORSCHE 2007 (987 CAYMAN) FOAM PART SEAT AND BACKREST COVER STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-004.webp "PORSCHE 2007 (987 CAYMAN) BACKREST SHELL STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-006.webp "PORSCHE 2007 (987 CAYMAN) BACKREST FRAME STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-008.webp "PORSCHE 2007 (987 CAYMAN) SEAT FRAME STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-009.webp "PORSCHE 2007 (987 CAYMAN) FRAME SEAT CUSHION STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-010.webp "PORSCHE 2007 (987 CAYMAN) WIRING LOOMS CONTROL UNIT SWITCH STANDARD SEAT COMFORT SEAT PARTS DIAGRAM")
-part-diagram-817-015.webp "PORSCHE 2007 (987 CAYMAN) FRONT SEATS SPORTS SEAT (COMPLETE) NO LONGER AVAILABLE PARTS DIAGRAM")
-part-diagram-817-017.webp "PORSCHE 2007 (987 CAYMAN) FOAM PART SEAT AND BACKREST COVER SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-018.webp "PORSCHE 2007 (987 CAYMAN) SEAT HEATER PARTS DIAGRAM")
-part-diagram-817-019.webp "PORSCHE 2007 (987 CAYMAN) BACKREST SHELL SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-021.webp "PORSCHE 2007 (987 CAYMAN) BACKREST FRAME SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-022.webp "PORSCHE 2007 (987 CAYMAN) LUMBAR SUPPORT SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-023.webp "PORSCHE 2007 (987 CAYMAN) SEAT FRAME SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-024.webp "PORSCHE 2007 (987 CAYMAN) FRAME SEAT CUSHION SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-025.webp "PORSCHE 2007 (987 CAYMAN) WIRING LOOMS CONTROL UNIT SWITCH SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-030.webp "PORSCHE 2007 (987 CAYMAN) BUCKET SEAT FOLDING (COMPLETE) NO LONGER AVAILABLE D - MJ 2008>> PARTS DIAGRAM")
-part-diagram-817-032.webp "PORSCHE 2007 (987 CAYMAN) FOAM PART SEAT AND BACKREST COVER SEAT AND BACKREST SURFACE BUCKET SEAT FOLDING D - MJ 2008>> PARTS DIAGRAM")
-part-diagram-817-034.webp "PORSCHE 2007 (987 CAYMAN) BUCKET SEAT FOLDING SEAT FRAME ACCESSORIES D - MJ 2008>> PARTS DIAGRAM")
-part-diagram-817-036.webp "PORSCHE 2007 (987 CAYMAN) BACKREST SHELL FOLDING BUCKET SEAT ACCESSORIES D - MJ 2008>> PARTS DIAGRAM")
-part-diagram-898-000.webp "PORSCHE 2007 (987 CAYMAN) REPAIR KITS 1 SET OF LOCK CYLINDERS COMPRISING: BRACKET DOOR HANDLE, EXTERIOR LOCK FOR GLOVE BOX KEY KEY FOB PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 2007 (987 CAYMAN) IGNITION SYSTEM PARTS DIAGRAM")
-part-diagram-901-003.webp "PORSCHE 2007 (987 CAYMAN) CONTROL UNITS PARTS DIAGRAM")
-part-diagram-901-004.webp "PORSCHE 2007 (987 CAYMAN) CONTROL UNITS IMMOBILISER CENTRAL LOCKING SYSTEM IGNITION/STARTER SWITCH PORSCHE ACCESS SYSTEM PARTS DIAGRAM")
-part-diagram-902-000.webp "PORSCHE 2007 (987 CAYMAN) CENTRAL ELECTRICS DASHBOARD PARTS DIAGRAM")
-part-diagram-902-001.webp "PORSCHE 2007 (987 CAYMAN) CENTRAL ELECTRICS REAR END PARTS DIAGRAM")
-part-diagram-902-005.webp "PORSCHE 2007 (987 CAYMAN) BATTERY POTENTIAL DISTRIBUTOR STARTER ALTERNATOR PARTS DIAGRAM")
-part-diagram-902-010.webp "PORSCHE 2007 (987 CAYMAN) WIRING LOOMS FRONT PASSENGER COMPARTMENT FRONT END TRIM AIRBAG SEAT BELT TENSIONER REPAIR KITS SHOCK ABSORBERS ANTI-LOCKING BRAKE SYST. -ABS- BRAKE PAD WEAR DISPLAY FRONT AXLE PARTS DIAGRAM")
-part-diagram-902-015.webp "PORSCHE 2007 (987 CAYMAN) WIRING LOOMS DOORS AIRBAG CENTRE CONSOLE GLOVE BOX REAR LID PARTS DIAGRAM")
-part-diagram-902-020.webp "PORSCHE 2007 (987 CAYMAN) WIRING LOOMS ENGINE REAR END LICENCE PLATE LIGHT PARKING AID REPAIR KITS FOR SHOCK ABSORBERS ANTI-LOCKING BRAKE SYST. -ABS- BRAKE PAD WEAR DISPLAY REAR AXLE PARTS DIAGRAM")
-part-diagram-902-050.webp "PORSCHE 2007 (987 CAYMAN) FIBRE OPTIC WAVE CONDUCTOR PARTS DIAGRAM")
-part-diagram-903-000.webp "PORSCHE 2007 (987 CAYMAN) FANFARE SIGNAL HORN ALARM SYSTEM PARTS DIAGRAM")
-part-diagram-903-004.webp "PORSCHE 2007 (987 CAYMAN) INTERIOR LIGHTING LUGGAGE COMPARTMENT LAMP ENGINE COMPARTMENT LIGHT GLOVE BOX LIGHT FOOTWELL LIGHT PARTS DIAGRAM")
-part-diagram-903-005.webp "PORSCHE 2007 (987 CAYMAN) SWITCH PARTS DIAGRAM")
-part-diagram-903-010.webp "PORSCHE 2007 (987 CAYMAN) STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 2007 (987 CAYMAN) WINDSCREEN WIPER SYSTEM, COMPL RAIN SENSOR PARTS DIAGRAM")
-part-diagram-904-005.webp "PORSCHE 2007 (987 CAYMAN) REAR WINDOW WIPER PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 2007 (987 CAYMAN) WINDSCREEN WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-904-020.webp "PORSCHE 2007 (987 CAYMAN) HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 2007 (987 CAYMAN) HEADLIGHTS ADDITIONAL HEADLIGHT TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-905-001.webp "PORSCHE 2007 (987 CAYMAN) HEADLIGHTS ADDITIONAL HEADLIGHT TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-905-005.webp "PORSCHE 2007 (987 CAYMAN) REAR LIGHT LICENCE PLATE LIGHT ADDITIONAL BRAKE LIGHT PARTS DIAGRAM")
-part-diagram-906-001.webp "PORSCHE 2007 (987 CAYMAN) COMBI-INSTRUMENT STOPWATCH PARTS DIAGRAM")
-part-diagram-906-002.webp "PORSCHE 2007 (987 CAYMAN) COMBI-INSTRUMENT EXCLUSIVE PROGRAMME PARTS DIAGRAM")
-part-diagram-911-000.webp "PORSCHE 2007 (987 CAYMAN) RADIO UNIT AMPLIFIERS NAVIGATION SYSTEM PARTS DIAGRAM")
-part-diagram-911-003.webp "PORSCHE 2007 (987 CAYMAN) PORSCHE CLASSIC COMMUNICATION 997, 987 MANAGEMENT PLUS 05-08 SEE TECHNICAL INFORMATION 28/22 9112 PARTS DIAGRAM")
-part-diagram-911-004.webp "PORSCHE 2007 (987 CAYMAN) PORSCHE CLASSIC COMMUNICATION 05-08 MANAGEMENT PLUS SEE TECHNICAL INFORMATION 28/22 9112 FURTHER GENUINE PARTS FOR THIS ASSEMBLY GROUP/MODEL SEE ILLUSTRATION: 902-020 OTHER COLOURS AVAILABLE PARTS DIAGRAM")
-part-diagram-911-005.webp "PORSCHE 2007 (987 CAYMAN) LOUDSPEAKER PARTS DIAGRAM")
-part-diagram-911-010.webp "PORSCHE 2007 (987 CAYMAN) TELEPHONE PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 2007 (987 CAYMAN) TOOL JACK PARTS DIAGRAM")
-part-diagram-003-010.webp "PORSCHE 2007 (987 CAYMAN) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-003-020.webp "PORSCHE 2007 (987 CAYMAN) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-003-030.webp "PORSCHE 2007 (987 CAYMAN) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-004-000.webp "PORSCHE 2007 (987 CAYMAN) PAINT TOUCH-UP APPLICATOR PAINTS PARTS DIAGRAM")
-part-diagram-004-005.webp "PORSCHE 2007 (987 CAYMAN) GLOVE ACCESSORIES PARTS DIAGRAM")
-part-diagram-004-010.webp "PORSCHE 2007 (987 CAYMAN) ACCESSORIES PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-004-015.webp "PORSCHE 2007 (987 CAYMAN) POLISH PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-004-020.webp "PORSCHE 2007 (987 CAYMAN) HOLDER FOR PT I OF REG. CERT. PARTS DIAGRAM")
-part-diagram-004-025.webp "PORSCHE 2007 (987 CAYMAN) CHARGER 6V/12V (5A) PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-004-030.webp "PORSCHE 2007 (987 CAYMAN) AROMA DISPENSER PARTS DIAGRAM")
-part-diagram-101-000.webp "PORSCHE 2007 (987 CAYMAN) REPLACEMENT ENGINE PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 2007 (987 CAYMAN) CRANKCASE HOUSING INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-101-010.webp "PORSCHE 2007 (987 CAYMAN) BELT TENSIONER DAMPER PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 2007 (987 CAYMAN) CRANKSHAFT PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 2007 (987 CAYMAN) PISTON PARTS DIAGRAM")
